PEX1000MMSC2

PCI Express Gigabit Ethernet Multi Mode

SC Fiber Network Card

*actual product may vary from photos

Instruction Manual

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates,

uses and can radiate radio frequency energy and, if not installed and used in accordance with

the instructions, may cause harmful interference to radio communications. However, there

is no guarantee that interference will not occur in a particular installation. If this equipment

does cause harmful interference to radio or television reception, which can be determined by

turning the equipment o and on, the user is encouraged to try to correct the interference by

one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver

is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other

protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and do not

represent an endorsement of a product or service by StarTech.com, or an endorsement of the

product(s) to which this manual applies by the third-party company in question. Regardless

of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby

acknowledges that all trademarks, registered trademarks, service marks, and other protected

names and/or symbols contained in this manual and related documents are the property of

their respective holders.

Instruction Manual

Table of Contents

Introduction ............................................................................................ 1

Packaging Contents 1 .................................................................................................................................

System Requirements 1 ..............................................................................................................................

Product Overview ..................................................................................2

Card ................................................................................................................................................................ 2

Jumper 2 ..........................................................................................................................................................

Installation .............................................................................................3

Hardware Installation 3 ..............................................................................................................................

Driver Installation 4 ......................................................................................................................................

Verifying Installation 6 ................................................................................................................................

Software Utility ......................................................................................9

Connecting to a Network ......................................................................9

Network Conguration 9 ...........................................................................................................................

Card to Card Direct Conguration 10 ......................................................................................................

LEDs 11 ..........................................................................................................

Specications 12 ..........................................................................................

Technical Support ..................................................................................13

Warranty Information ............................................................................ 13

Produktspecifikationer

Varumärke:	StarTech.com
Kategori:	Nätverkskort/adapter
Modell:	PEX1000MMSC2
Vikt:	66 g
Bredd:	118 mm
Djup:	120 mm
Höjd:	18 mm
Förpackningens bredd:	171 mm
Strömförsörjning:	3.2 W
LED-indikatorer:	Activity, Link
Gränssnitt:	Ethernet / Fiber
Maximal räckvidd:	550 m
Värdgränssnitt:	PCI Express
Maximal dataöverföringshastighet:	2000 Mbit/s
Serveroperativsystem som stöds:	Windows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Full duplex:	Ja
Komponent för:	PC
Buffertstorlek:	48 KB
bruksanvisning:	Ja
Låddjup:	218 mm
Vikt inkl. förpackning:	208 g
Mac-operativsystem som stöds:	Mac OS X 10.5 Leopard, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks
Temperatur vid drift:	0 - 45 ° C
Temperaturintervall (förvaring):	-20 - 70 ° C
Intervall för relativ operativ luftfuktighet:	5 - 95 %
Hållbarhetscertifiering:	RoHS
Anslutningsteknologi:	Kabel
LAN-styrenhet:	Realtek RTL8168E
Wake-on-LAN förberedd:	Ja
Kommunikationsstandarder:	IEEE 802.1p, IEEE 802.1Q, IEEE 802.3x, IEEE 802.3z
Linux operativsystem som stöds:	Ja
Harmonized System (HS)-kod:	85176990
Intern:	Ja
Kretsar:	RTL8168E
Jumbo Frames stöd:	Ja
Fiberoptiska kontakten:	SC
Fiber Ethernet-kablar teknik:	1000BASE‑SX
