Quick Start Guide

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

I T: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

P T: Guia do usuário - pt.startech.com

Manual Revision: 01/02/2015

For the most up-to-date information, please visit: www.startech.com

Packaging Contents

• 1x USB 3.0 Hub w/ GbE Adapter

• 1x Universal Power Adapter (NA/UK/EU)

• 1x Driver CD

• 1x Instruction Manual

System Requirements

• USB enabled computer system with an available USB 3.0 port

• Windows® 8 / 8.1 (32/64bit), 7 (32/64), Vista (32/64), XP (32/64),

Windows Server® 2012, 2008 R2, 2003, Mac OS 10.6 and up (Tested

up to 10.9), Linux 2.6.x and up (Tested up to 3.5)

ST3300GU3B

3 Port Portable Aluminum USB 3.0 Hub with Gigabit Ethernet Adapter

*actual product may vary from photos

DC Input Port

Rear View

USB 3.0 Upstream

Cable (attached)

USB 3.0 Ports Gigabit RJ-45 Port

Front View

Installation

Driver Installation

Depending on your Operating System version and whether or

not you have an active network connection, the USB 3.0 Hub may

auto-install once connected to an available USB 3.0 port on the host

system.

If the USB 3.0 Hub does not auto-install, follow the steps below to

complete the Driver Installation process.

Windows / Mac

1. Download the latest drivers from the www.startech.com website

(recommended) applicable to the Operating System on the host

computer that you are connecting the USB 3.0 Hub to, or insert

the included Driver CD into your computer’s CD/DVD-ROM drive.

2. If AutoPlay is enabled, select the “Open folder to view les” option

when the dialog appears and run the Setup/Install “.exe” or “.dmg”

application.

3. If AutoPlay is disabled, browse to your CD/DVD drive location (or

to where the driver was downloaded) and run the Setup/Install

“.exe” or “.dmg” application.

4. Follow any on-screen instructions to complete the driver

installation.

Note: You may be prompted to restart your system.

Hardware Installation

1. Connect the included Power Adapter from an AC electrical outlet

to the DC Input Port on the USB 3.0 Hub.

2. Connect the USB 3.0 Hub to an available USB 3.0 port on the host

system via the attached USB 3.0 Upstream Cable.

Note: If connected to a USB 2.0 host port, performance may

be limited.

3. Connect your Cat 5e/6 network connection to the Gigabit RJ-45

port on the adapter.

4. Connect any USB 3.0 peripherals to the USB 3.0 Hub as desired.

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against

harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause

harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of third-party companies not related in any way to

StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s)

to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby acknowledges that all

trademarks, registered trademarks, service marks, and other protected names and/or symbols contained in this manual and related documents are the property of their respective holders.

Technical Support

StarTech.com’s lifetime technical support is an integral part of our commitment to provide industry-leading solutions. If you ever need help with your product, visit www.startech.com/support and access

our comprehensive selection of online tools, documentation, and downloads.

For the latest drivers/software, please visit www.startech.com/downloads

Warranty Information

This product is backed by a two year warranty.

In addition, StarTech.com warrants its products against defects in materials and workmanship for the periods noted, following the initial date of purchase. During this period, the products may be returned

for repair, or replacement with equivalent products at our discretion. The warranty covers parts and labor costs only. StarTech.com does not warrant its products from defects or damages arising from

misuse, abuse, alteration, or normal wear and tear.

Limitation of Liability

In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their ocers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental,

consequential, or otherwise), loss of prots, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product. Some states do not allow

the exclusion or limitation of incidental or consequential damages. If such laws apply, the limitations or exclusions contained in this statement may not apply to you.

Produktspecifikationer

Varumärke:	StarTech.com
Kategori:	Nätverkskort/adapter
Modell:	ST3300GU3B
Färg på produkten:	Zwart
Vikt:	2500 g
Bredd:	222 mm
Djup:	170 mm
Höjd:	1192 mm
Förpackningens vikt:	3450 g
Förpackningens bredd:	217 mm
Användarmanual:	Ja
LED-indikatorer:	Activity, Link
Justerbar i höjdled:	Ja
Monteringsverktyg:	Ja
Monteringsmetod:	Plafond
Förpackningsmått (BxDxH):	603 x 241 x 184 mm
Maximal viktkapacitet:	25 kg
Certifiering:	CE, FCC
USB-version:	3.2 Gen 1 (3.1 Gen 1)
Gränssnitt:	Ethernet
Panelmonteringsgränssnitt:	100 x 100,200 x 100,200 x 200 mm
Kabelteknik:	10/100/1000BaseT(X)
Uteffekt:	2 A
Värdgränssnitt:	USB
Maximal dataöverföringshastighet:	5000 Mbit/s
Rotationsvinkel:	360 °
Serveroperativsystem som stöds:	Windows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019
Full duplex:	Ja
Kompatibilitet med monteringsgränssnitt (min):	100 x 100 mm
Kompatibilitet med monteringsgränssnitt (max):	200 x 200 mm
Antal skärmar som stöds:	1
Förbättrad kabelhantering:	Ja
Tiltvinkelområde:	-5 - 15 °
Maximal skärmstorlek:	40 "
Minsta skärmstorlek:	22 "
Höjdjusteringsområde:	757 - 1192 mm
Kabellängd:	0.148 m
Produktens färg:	Svart
bruksanvisning:	Ja
Låddjup:	152 mm
Vikt inkl. förpackning:	374 g
Ytterförpackningens höjd:	580 mm
Produkter per ytterförpackning:	40 styck
Ytterförpackningens längd:	452 mm
Ytterförpackningens bredd:	323 mm
Typ av strömkontakt:	Typ H
Mac-operativsystem som stöds:	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks, Mac OS X 13.0 Ventura
Andra operativsystem som stöds:	ChromeOS
Datahastighet för Ethernet-LAN:	10,100,1000 Mbit/s
Antal LAN (RJ-45) anslutningar:	1
Strömförbrukning (vanlig):	10 W
Temperatur vid drift:	0 - 50 ° C
Temperaturintervall (förvaring):	-10 - 75 ° C
Intervall för relativ operativ luftfuktighet:	0 - 85 %
Hållbarhetscertifiering:	RoHS
Utgångsspänning:	5 V
AC-inspänning:	100-240 V
Material, hölje:	Gjuten aluminium
Anslutningsteknologi:	Kabel
Nätverksansluten (Ethernet):	Ja
AC-adapter inkluderad:	Ja
Automatisk MDIX IEEE:	Ja
Wake-on-LAN förberedd:	Ja
Kommunikationsstandarder:	IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u
Linux operativsystem som stöds:	Ja
Harmonized System (HS)-kod:	85176990
Intern:	Nej
Ingående ström:	0.3 A
Kretsar:	Genesys Logic - GL3522, ASIX - AX88179
Jumboramar:	4000
Jumbo Frames stöd:	Ja
Flödeskontroll:	Ja
Autonegotiation:	Ja
Typer av nätkontakter som ingår:	AU, EU, NA, UK
Drivrutiner medföljer:	Ja
Antal USB 3.2 Gen 1 (3.1 Gen 1)typ A-hubbportar:	3
USB dataöverföring:	12,480,5000 Mbit/s
