Sida 1/8

- 1 -

Exit Stopper

STI-6400 Series

Features

· Helps prevent unauthorized exits/entries through doors.

· Easy to install. Warning sound when turning on (two ﬂashes/beeps) and off

(one ﬂash/beep).

· Add warning in second language with provided labels (21 languages).

· Select volume, alarm duration and delay settings.

· Mount on top, right, left or next to almost any door.

· Select on-site whether to use an alarm or annunciator.

· Low battery detection, beep and ﬂashes.

· Alarm sounds and high power LED light ﬂashes when activated.

· Dry contact Form C relay.

· Protect anything such as cabinet, extinguisher, etc. with an external reed or

any mechanical switch.

Rely on STI

- 2 -

Warnings

All units are recommended for indoor use only. Unit must be tested periodically to verify the life

of battery. STI recommends you change the 9 Volt battery twice a year. To hear alarm when

normal work environment is loud, may need to purchase remote horns. When purchasing a

remote unit (STI-6403 or STI-6404) you will need to periodically test the connections to make

sure audibles function at a sound level to alert staff. Maximum of three remote alarms may be

used in parallel.

All speciﬁcations and information shown are current as of publication and subject to change

without notice.

Warranty Information

· Three year guarantee against breakage of polycarbonate in normal use (one year on electro

mechanical and electronic components).

· Electronic warranty form at www.sti-usa.com/wc14

- 3 -

Specications

Polycarbonate Enclosure

Dimensions 5.375” W x 5.375” H x 2 “ D (137mm x 137mm x 51mm)

Flammability UL94 V-2

Wall Thickness 0.12 in (3.05mm)

Electronics: STI-6403 and STI-6404 - Remote Horn Unit

Power Source 9 VDC operating power* only

Horn Volume at 1 ft. 95 dB low / 105 dB high

Stand by Current 0 A

Alarm Current 50mA at 95 dB/ 200 mA at 105 dB

* Power source for the STI-6403 and STI-6404 Remote Horn uses a separate power

source from the STI-6400 alarm. The Remote Horn contains an internal 9 volt battery.

Horn operates when the Form C contact at main unit is activated on alarm.

9 VDC battery

If not using, slide switch 6 “on”

12VDC - 24VDC, 300mA

Installed battery will act as backup power if switch 6 is “off”

30 cm high volume 112dB; low volume 97dB

100 cm high volume 102dB; low volume 88dB

Flash 1x / minute; beep 1x / 3 minutes

0.5A 125VAC / 1A 30VDC

Battery <15μA (Battery Life approx. 2 years dependent on use)

12VDC <0.15mA

24VDC <1mA

<286mA @12VDC <149mA @24VDC

14°F to 122°F (-10°C to 50°C)

2 ﬂashes and 2 beeps

1 ﬂash and 1 beep

Power source

Remote power input

Low battery detection

Relay contacts

Stand by current

Alarm current (volume high + relay)

Operating temperature

Power “on” notiﬁcation

Power “off” notiﬁcation

Horn volume

Electronics
