Please Do Not Return This Product To The Store!
Contact Escalade
®
Sports customer service department at:
Phone: 1-866-873-3528 Toll – Free !
Fax: 1-866-873-3533 Toll – Free !
E-mail: tabletennis@escaladesports.com
Mailing Address (correspondence only):
Escalade Sports
PO Box 889
Evansville, IN 47706
Please visit our World Wide Web site at: www.escaladesports.com
ON-LINE TROUBLE SHOOTING TECHNICAL ASSISTANCE
ON-LINE PARTS REQUESTS FREQUENTLY ASKED QUESTIONS
ADDITIONAL ESCALADE
®
SPORTS PRODUCT INFORMATION
2L-4136-00
Ó
ÒÒ
TABLE TENNIS TABLE
MODEL NO.
T8521
1. Read this manual carefully before starting assembly. Read each step completely before beginning
each step.
2. Some smaller parts may be shipped inside larger parts. Check inside all parts and cartons
before assembling or ordering parts.
5. Tools required for assembly: Phillips Screwdriver, Two 9/16” Wrenches, Two 7/16” Wrenches.
Note: Adjustable wrenches can be substituted for wrenches.
6. Save this instruction manual and your proof of purchase (receipt) in the event that the
manufacturer has to be contacted for replacement parts.
Escalade® Sports products may be manufactured and/or licensed under the following patents.
6120397, 5816957, 5769744, 5119741, 4911085, 4717157, D460140, D420563
Additional patents may be pending. One or more of the listed patents and/or pending patents may cover specific product.
2012 Escalade Sports
O W N E R ' S M A N U A L
3. To make assembly easier, use the Hardware Identifier on page 2 to identify and sort all
fasteners. Check all cartons for kits. All hardware may not be located in one kit.
4. Do not tighten hardware until instructed to do so. If hardware is tightened too soon, mounting holes
may not align and parts may not easily fit together. Leave locknuts slightly loose until you are instructed to
tighten them.
2
1/4"
Plastic
Washer
Washer
Plastic
3/8"
28
30
31
32
5
34
35
37
1/4-20 X 3 1/4 Carriage Bolt
#8 X 9/16
SMS
#8-32 X 1 1/4
Sheet Metal Screw
3/8" Long Spacer
3/4" Long Spacer
39
36
1/4-20 X 2 3/4 Hex Head Bolt
29
HARDWARE IDENTIFIER
3/8-16
Nyloc
Locknut
1/4-20 X 1 1/2 Phillips
Truss Head Screw
1/4-20 Nyloc
Locknut
27
3/8-16 x 3 1/2 Hex Head Bolt
3/8-16X2 3/4 Hex Head Bolt
1/4-20 X 2 1/2” Hex Head Bolt
3/8 Push Nut
13
24 11
(Qty. 4)
(Qty. 20)
(Qty. 4)
(Qty. 12)
(Qty. 4)
(Qty. 4)
(Qty. 154)
(Qty. 4)
(Qty. 4)
(Qty. 4)
(Qty. 8)
(Qty. 8)
(Qty. 8)
(Qty. 12 )
(Qty. 4)
38
(Qty. 4)
1/4-20 Wing Nut
