REV C DATE: 03/14/2023
USER MANUALS\21-27948_BLEND_USER MANUAL_NM(L)(H)DSSV_AMBIENT_SELF-SVC_CASE
SCC P/N
21-27948
BLEND® SELF-SERVICE DRY (AMBIENT) MERCHANDISERS
> THIS USER GUIDE IS APPLICABLE TO MODEL NM4855DSSV and NM7255DSSV
> SOLID REAR PLENUM / PRESSURIZED FAN SYSTEM TO PREVENT INSECT INFILTRATION
> HINGED FRONT GLASS DOORS WITH CENTER HANDLES /
> FRONT CUBBIES / FRONT NAPKIN DISPENSER INSIDE UNIT / TRASH DOOR
> CAUTION! DO NOT PUSH OR PULL ON GLASS UPRIGHTS!
> ONLY USE HANDLES (AT EACH END OF CASE) TO PUSH OR PULL CASE INTO POSITION!
Model NM7255DSSV Ambient
Merchandiser Shown At Left
Note: See Blend® Case-To-Case
Adjoinment Guide P/N 21-26284
For Lineup Options As Well As
Step-By-Step Lineup Instructions.
Structural Concepts Corp. ∙ 888 E. Porter Rd ∙ Muskegon, MI 49441 Phone: 231.798.8888 Fax: 231.798.4960 ∙ www.structuralconcepts.com
User
Manual
®
BLEND
READ AND SAVE THESE INSTRUCTIONS
Model NM4855DSSV Ambient
Merchandiser With Optional
Tray Feature Shown At Right
2
TABLE OF CONTENTS
TABLE OF CONTENTS ………………………………………………………………………………….....…...
OVERVIEW / COMPLIANCE / LED LIGHTS PRECAUTION / ELECTRICAL HAZARD WARNING /
WIRING DIAGRAM ……………………………………………………………………..……..………...
BLEND® FREE STANDING REFRIGERATED SELF-SERVICE MODEL APPLICABILITY AND
INDIVIDUAL MODEL DIMENSIONS ……………...………………………………………….…..…...
INSTALLATION: TOE-KICK & REAR PANEL REMOVAL / REMOVING SKID BRACKETS AND
BLOCKS ……………………………………………………………………………………………..…...
INSTALLATION, CONT’D.: CASTER ADJUSTMENT / LOCK / UNLOCK / CASE REMOVAL FROM
SKID ……………………………………………………………………………………………………....
INSTALLATION, CONT’D: TOE-KICK REATTACHMENT ……………………………………………..…..
INSTALLATION, CONT’D: SHELVING ASSEMBLY COMPONENTS ………………………………..…..
INSTALLATION, CONT’D: FIELD WIRE (OR PLUG IN) CASE / TURN ON LED LIGHTS .……...…….
CASE DESIGN: TOP SIDE VIEW OF AMBIENT, SELF-SERVICE MERCHANDISERS .……………....
CASE DESIGN, CONT’D: UNDERSIDE VIEW OF AMBIENT SELF-SERVICE MERCHANDISERS …
CASE DESIGN, CONT’D: LED STYLE LIGHT FIXTURES …………………………………………………
CASE DESIGN, CONT’D: PRESSURIZED FAN SYSTEM TO PREVENT INSECT INFILTRATION …...
CLEANING SCHEDULE (TO BE PERFORMED BY STORE PERSONNEL) ……………….……..……..
TROUBLESHOOTING (TO BE PERFORMED BY STORE PERSONNEL) ...………………...................
TROUBLESHOOTING (TO BE PERFORMED BY TRAINED SERVICE PROVIDERS ONLY) …..…….
SERIAL LABEL LOCATION & INFORMATION LISTED / TECH INFORMATION & SERVICE ….…....…
STRUCTURAL CONCEPTS TECHNICAL SERVICE CONTACT INFORMATION & LIMITED
WARRANTY …………………………………………………………………………....…...…...….......
