Sida 1/27
GROCERANT™ REMOTE SELF-SERVICE INLINE COLD WELL FOOD MERCHANDISERS WITH
DROP-IN PANS ||| NOTE: UNITS MAY INCLUDE CERTAIN FEATURES OR OPTIONS LISTED BELOW:
REV D DATE: 12/20/2022
USER MANUALS\20-96491_GROCERANT_USER MANUAL_FB(L)SS-(L)R_REF_RMT_SELF-SVC_CANOPY_FOOD PREP V2 CASE
Models Shown on This Cover May Not Reflect
Every Feature Or Option of Your Particular Case
Nor Other Models Illustrated In This Manual.
> ADJUSTABLE SNEEZE GUARD GLASS DESIGN
> STAINLESS STEEL SUPPORT POSTS
> REFRIGERATED INSULATED WELLS
> REFRIGERATED WELLS WITH “SHARED AIR” PLENUMS
(SEE “SHARED AIR” SECTION IN MANUAL FOR
SPECIFICS)
> REAR REFRIGERATED STORAGE VIA SLIDING DOORS,
HINGED DOOR OR DRAWERS
> OPTIONAL OPEN/AMBIENT REAR STORAGE
> ADJUSTABLE SIDE SPLASH BRACKETS
> REMOVABLE FRONT PANEL (FOR ADJOINMENT
PURPOSES)
> GUSSETS AND TABS (FOR ADJOINMENT PURPOSES)
> REMOVABLE REAR PLATE (FOR ADJOINMENT PURPOSES)
Model FB8SS-6R
Shown With
Drop-In Pans
Model FB6SS-4R
With Cubby
SCC P/N
20-96491
USER
MANUAL
GROCERANT
CAREFULLY FOLLOW THESE INSTRUCTIONS
Structural Concepts Corp. ∙ 888 E. Porter Rd ∙ Muskegon, MI 49441 Phone: 231.798.8888 Fax: 231.798.4960 ∙ www.structuralconcepts.com
2
TABLE OF CONTENTS
TABLE OF CONTENTS …...………………………………………………………………………….………...
OVERVIEW / CONDITION “TYPE” / COMPLIANCE / WARNINGS / PRECAUTIONS .…....................
CASE REMOVAL FROM SKID / POSITIONING / FORK LIFT / J-BAR or DOLLY .…..……..….…..….
ADJOINMENT GUIDE: LOWERING FRONT PANEL FOR END PANEL ADJOINMENT .....……..…....
ADJOINMENT GUIDE, CONT’D: REAR ADJOINMENT ACCESS (VIA COVER PLATE REMOVAL)..
ADJOINMENT GUIDE, CONT’D: BASE FRAME / GUSSET / BREAKOFF ADJOINMENT BRACKET
SPLASH GUARD BRACKETS: INSERTION AT CASE FRONT / ADJUSTABILITY / SEALING TO
FLOOR ……………………………………………………………………………………………………
FRAME SUPPORT RAILS / REMOVABLE FRONT AND REAR TOE-KICKS …………………………..
ELECTRICAL OVERVIEW: FIELD ACCESS / DRIVERS / FIELD SENSOR / T-STRIP …..……...........
ELECTRICAL OVERVIEW, CONT’D: THERMOMETERS ………………………………………………….
START-UP & OPERATION - REFRIGERATED UPPER SECTION …..…………………………………...
REFRIGERATED REAR SECTION WITH SLIDING DOORS ………………………………………………
REFRIGERATED REAR SECTION WITH DRAWERS ……………………………………………….……..
REFRIGERATED REAR SECTION WITH HINGED DOOR …………………………………………….…..
REAR REFRIGERATED “SHARED AIR” SECTION / SLIDING DOORS / THERMOMETERS ………..
CLEANING SCHEDULE: DAILY “D” / WEEKLY “W”....…………………………………………………...
CLEANING & MAINTENANCE of NATURAL QUARTZ SURFACES …..………………………………...
CLEANING SCHEDULE: CAESARSTONE® SOLID SURFACE ………………………………………….
CLEANING SCHEDULE: GRANITE, MARBLE & STONE SURFACE CLEANING, CARE &
MAINTENANCE ….……………………………………………………………………………………...
CLEANING SCHEDULE: STAINLESS STEEL ……………………………………………………………….
CLEANING SCHEDULE: DAILY / WEEKLY: DECK PANS / DIVIDERS / PRODUCT PANS / TUB .....
TROUBLESHOOTING (TO BE PERFORMED BY STORE PERSONNEL) ……………………………...
TROUBLESHOOTING (TO BE PERFORMED BY TRAINED SERVICE PROVIDERS ONLY) ………..
SERIAL LABEL LOCATION & INFORMATION LISTED / TECH INFO & SERVICE …………………...
TECHNICAL SERVICE CONTACT INFORMATION / WARRANTY INFORMATION …………………...
2
3-4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
