Information for Lot 9 of ErP (Ecodesign)

This addendum addresses European Union (EU) Ecodesign requirements for servers and storage

products. All data and ratings within this addendum are in reference only to the Supermicro product(s) in

the manual. The below information conforms to requirements laid down in Annex II of the Commission

Regulation 2019/424.

3(1)(a): See Section 1.1 of the system manual for the product type.

3(1)(b): See the title page and preface of the system manual for the trademark and

manufacturer’s address.

3(1)(c): See the title page of the system manual for product model number(s).

3(1)(d): See the serial number on the physical system to determine the year of manufacture.

3(1)(e-j): PSU Efficiency and Power Factor Value (Table) (From 80 Plus report)

PSU Model #: PWS-1K22A-1R

Watts: 1200W

PSU Efficiency

Power Factor

% of Rated Load

10 % 20 % 50 % 100 %

50 %

Single Output (AC-DC)

90.70%

95.20%

96.01%

93.74%

0.99

System (EUT) Efficiency in Idle State Power (Table)

Representative

Configurations

Measured Idle State

Power (W)

Calculated Idle Power

Allowance (W)

High-End Performance

Configuration

242.9

499.03

Typical Configuration

N/A

Low-End Performance

Configuration

121.6

309.43

System (EUT) Efficiency in Active State Power (Table)

Representative

Configurations

Active State

Efficiency Score

(Effserver)

Minimum Active State

Efficiency for 2-Socket

Server

High-End Performance

Configuration

56.9

Typical Configuration

N/A

9.5

Low-End Performance

Configuration

37.8

3(1)(k): The operating condition class is A2.

Dry bulb temp °C

Humidity range, non-condensing

Operati

conditi

Allowab

range

Reco

m

mend

Allowable range

Recommended

range

Max

dew

point (°

Maximu

m rate

change

15- 32

18-27

–

12 °C Dew Point (DP)

and

8 % relative

humidity (RH) to

17 °C DP and 80 % RH

–

9 °C DP to

15 °C DP

and

60 %

5/20

10-35

18-27

–

12 °C DP and 8 % RH

21 °C DP and 80 %

Same as A1

5/20

5-40

18-27

–

12 °C DP and 8 % RH

24 °C DP and 85 %

Same as A1

5/20

5-45

18-27

–

12 °C DP and 8 % RH

24 °C DP and 90 %

Same as A1

5/20

3(1)(l): The idle state power at the higher boundary temperature of the operating conditions

class is 286.62W.

3(1)(m): The active state efficiency and performance is

56.9.

3(1)(n): There are two methods by which a user can securely delete data from this system. The

user performing secure data deletion should be an IT professional.

The first is with a Unified Extensible Firmware Interface (UEFI) shell utility. This utility

works on X10/X11/H11/H12/M11 motherboard series with onboard SATA/NVMe devices.

Any user may access and download this utility through following link:

https://www.supermicro.com/about/policies/disclaimer.cfm?url=/wftp/utility/Lot9_Secure

_Data_Deletion_Utility/

Download the shell utility package and extract it to a USB flash drive, then plug the drive

into the server for which secure data deletion is necessary. Then turn the system on.

Navigate to the BIOS setup menu, then place the server system into the UEFI shell

environment. Follow the instructions in the README file to invoke the utility and

complete the deletion.

The second method is through the secure data deletion tool provided by the original

manufacturer of the hard drive. This should be used in a scenario where the shell utility

is not applicable. Each manufacturer should have the tool available on their website. If

needed, please look on the hard drive label for the name of the manufacturer and model

information.

3(1)(o): List of recommended combinations of blade servers with chassis: N/A.

3(1)(p): List of all current SKUs within this product family: N/A.

3(3)(a): There is no use of cobalt in batteries in this product.

Produktspecifikationer

Varumärke:	Supermicro
Kategori:	Server
Modell:	AS-1124US-TNRP
Vikt:	21800 g
Bredd:	73.5 mm
Djup:	203 mm
Höjd:	40 mm
Förpackningens bredd:	600.964 mm
Strömförsörjning:	1200 W
Processorfrekvens:	- GHz
Processorfamilj:	AMD EPYC
Wi-Fi:	Nej
Certifiering:	80 PLUS Titanium Level
Internminne:	- GB
Processor:	7000
Maximalt internminne:	8000 GB
Total lagringskapacitet:	- GB
Rackmontering:	Ja
Minnesplatser:	32
Trusted Platform Module (TPM):	Ja
RAID-stöd:	Nej
Maximal lagringskapacitet:	- TB
NVMe:	Ja
BIOS-typ:	EEPROM
SSD-storlekar som stöds:	2.5"
Produktens färg:	Svart
Låddjup:	943.102 mm
processortillverkare:	AMD
Installerat operativsystem:	Nej
Typ av ethernet-gränssnitt:	10 Gigabit Ethernet
Antal LAN (RJ-45) anslutningar:	1
Temperatur vid drift:	10 - 35 ° C
Temperaturintervall (förvaring):	-40 - 70 ° C
Intervall för relativ operativ luftfuktighet:	8 - 90 %
Fuktighet (förvaring):	5 - 95 %
Typ av internminne:	DDR4-SDRAM
Nätverksansluten (Ethernet):	Ja
Antal USB 3.2 Gen 1 (3.1 Gen 1) typ A-portar:	4
LAN-styrenhet:	Intel X710-AT2
Harmonized System (HS)-kod:	84714100
Kvalitet på VGA (D-Sub) porten:	1
Minne klockhastighet:	3200 MHz
Optisk enhetstyp:	Nej
Ombord grafikkort modell:	Aspeed AST2500
Ombord grafikkort:	Ja
Byte under drift (hotswap):	Ja
Stöd för redundant strömförsörjning (RPS):	Ja
ECC:	Ja
Solid-state drive-gränssnitt:	NVMe, Serial Attached SCSI (SAS), SATA III
Trusted Platform Module (TPM)-version:	2.0
Chassityp:	Rack (1U)
PCI Express x16 platser:	4
Intelligent Platform Management Interface (IPMI) stöd:	Ja
Antal SSD-minnen som stöds:	12
SSD-storlek:	2.5"
