Sida 1/147

C7Z97-M

C7Z97-MF

USER’S MANUAL

Revision 1.0b

The information in this User’s Manual has been carefully reviewed and is believed to be accurate. The

vendor assumes no responsibility for any inaccuracies that may be contained in this document, makes

no commitment to update or to keep current the information in this manual, or to notify any person

or organization of the updates. Please Note: For the most up-to-date version of this manual,

please see our web site at www.supermicro.com.

Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product de-

scribed in this manual at any time and without notice. This product, including software and documenta-

tion, is the property of Supermicro and/or its licensors, and is supplied only under a license. Any use or

reproduction of this product is not allowed, except as expressly permitted by the terms of said license.

IN NO EVENT WILL SUPERMICRO BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDEN-

TAL, SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE OR INABILITY

TO USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF THE POSSIBILITY OF

SUCH DAMAGES. IN PARTICULAR, SUPERMICRO SHALL NOT HAVE LIABILITY FOR ANY

HARDWARE, SOFTWARE, OR DATA STORED OR USED WITH THE PRODUCT, INCLUDING THE

COSTS OF REPAIRING, REPLACING, INTEGRATING, INSTALLING OR RECOVERING SUCH

HARDWARE, SOFTWARE, OR DATA.

Any disputes arising between manufacturer and customer shall be governed by the laws of Santa

Clara County in the State of California, USA. The State of California, County of Santa Clara shall be

the exclusive venue for the resolution of any such disputes. Super Micro's total liability for all claims

will not exceed the price paid for the hardware product.

FCC Statement: This equipment has been tested and found to comply with the limits for a class B

digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference in a residential installation. This equipment generates, uses,

and can radiate radio frequency energy and, if not installed and used in accordance with the instruc-

tions, may cause harmful interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause harmful interfer-

ence to radio or television reception, which can be determined by turning the equipment off and on,

the user is encouraged to try to correct the interference by one or more of the following measures:

•Reorient or relocate the receiving antenna.

•Increase the separation between the equipment and receiver.

•Connect the equipment to an outlet on a circuit different from that to which the

receiver is connected.

•Consult the authorized dealer or an experienced radio/TV technician for help.

California Best Management Practices Regulations for Perchlorate Materials: This Perchlorate warning

applies only to products containing CR (Manganese Dioxide) Lithium coin cells. “Perchlorate Material-

special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate”

WARNING: Handling of lead solder materials used

in this product may expose you to lead, a chemi-

cal known to the State of California to cause birth

defects and other reproductive harm.

Manual Revision 1.0b

Release Date: August 4, 2015

Unless you request and receive written permission from Super Micro Computer, Inc., you may not

copy any part of this document.

Information in this document is subject to change without notice. Other products and companies

referred to herein are trademarks or registered trademarks of their respective companies or mark

holders.

Printed in the United States of America

Produktspecifikationer

Varumärke:	Supermicro
Kategori:	moderkort
Modell:	C7Z97-M
Bredd:	244 mm
Djup:	244 mm
Wi-Fi:	Nej
Antal HDMI-portar:	1
USB-version:	2.0/3.2 Gen 1 (3.1 Gen 1)
Maximalt internminne:	32 GB
Ljudutgångskanaler:	7.1 kanaler
Komponent för:	PC
Minnesspänning:	1.35, 1.5 V
Kompatibla processorer:	Intel Core i3, Intel Core i5, Intel Core i7
Minnestyper som stöds:	DDR3-SDRAM
Antal minnesplatser:	4
BIOS-typ:	UEFI AMI
ACPI-version:	5.0
Obuffrat minne:	Ja
Antal USB-portar:	12
Antal displayportar:	1
processortillverkare:	Intel
Typ av ethernet-gränssnitt:	Fast Ethernet, Gigabit Ethernet
Antal LAN (RJ-45) anslutningar:	1
processorsockel:	LGA 1150 (uttag H3)
Antal PS/2-portar:	1
Nätverksansluten (Ethernet):	Ja
Strömkälla av typen:	ATX
Antal USB 2.0 anslutningar:	2
RAID-nivåer:	0, 1,5, 10
Minnesplatser, typ:	DIMM
Minnets hastigheter:	1600 MHz
Max antal processorer:	1
USB 2.0 anslutning:	4
TPM-anslutning:	Ja
Antal USB 3.2 Gen 1 (3.1 Gen 1) typ A-portar:	4
BIOS minnesstorlek:	16 mbit
LAN-styrenhet:	Intel® I210-AT
Moderkort, chipsetfamilj:	Intel
Moderkortets chipset:	Intel® Z97
Moderkort formfaktor:	micro ATX
PCI Express x16 (Gen 3.x)-kortplatser:	1
Medföljande programvara:	SuperDoctor® III\nWatch Dog
Värmeavledningseffekt (TDP):	150 W
Lagringsenhetsgränssnitt som stöds:	SATA III
Trusted Platform Module (TPM)-version:	1.2
USB 3.2 Gen 1 (3.1 Gen 1)-anslutningar:	2
Antal SATA III kontakter:	6
PCI Express x4 (Gen 2.x)-kortplatser:	1
Stöd för UDIMM klockfrekvenser:	1600 MHz
Antal COM portar:	1
PC hälsoövervakning:	FAN, LED, Temperature, Voltage
Chassits genomgångsanslutning:	Ja
Intel® Core i3/i5/i7/i9 serien:	i3-4xxx, i3-5xxx, i5-4xxx, i5-5xxx, i7-4xxx, i7-5xxx
Stödda kapaciteter hos minnesmodul:	1GB, 2GB, 4GB, 8GB
Serieport via intern header:	Ja
Serieport headers:	1
Processor värmekraft (max):	150 W
PCI Express x8 (Gen 3.x)-kortplatser:	1
Maximalt UDIMM minne:	32 GB
Stöd för UDIMM modulkapacitet:	1GB, 2GB, 4GB, 8GB
Vakthund funktion:	Ja
