The information in this User’s Manual has been carefully reviewed and is believed to be accurate. The vendor assumes

no responsibility for any inaccuracies that may be contained in this document, and makes no commitment to update

or to keep current the information in this manual, or to notify any person or organization of the updates. Please Note:

For the most up-to-date version of this manual, please see our website at www.supermicro.com.

Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product described in this manual

at any time and without notice. This product, including software and documentation, is the property of Supermicro and/

or its licensors, and is supplied only under a license. Any use or reproduction of this product is not allowed, except

as expressly permitted by the terms of said license.

IN NO EVENT WILL Super Micro Computer, Inc. BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL,

SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE OR INABILITY TO USE THIS PRODUCT

OR DOCUMENTATION, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. IN PARTICULAR, SUPER

MICRO COMPUTER, INC. SHALL NOT HAVE LIABILITY FOR ANY HARDWARE, SOFTWARE, OR DATA STORED

OR USED WITH THE PRODUCT, INCLUDING THE COSTS OF REPAIRING, REPLACING, INTEGRATING,

INSTALLING OR RECOVERING SUCH HARDWARE, SOFTWARE, OR DATA.

Any disputes arising between manufacturer and customer shall be governed by the laws of Santa Clara County in the

State of California, USA. The State of California, County of Santa Clara shall be the exclusive venue for the resolution

of any such disputes. Supermicro's total liability for all claims will not exceed the price paid for the hardware product.

FCC Statement: This equipment has been tested and found to comply with the limits for a Class A digital device

pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful

interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can

radiate radio frequency energy and, if not installed and used in accordance with the manufacturer’s instruction manual,

may cause harmful interference with radio communications. Operation of this equipment in a residential area is likely

to cause harmful interference, in which case you will be required to correct the interference at your own expense.

California Best Management Practices Regulations for Perchlorate Materials: This Perchlorate warning applies only

to products containing CR (Manganese Dioxide) Lithium coin cells. “Perchlorate Material-special handling may apply.

See www.dtsc.ca.gov/hazardouswaste/perchlorate”.

The products sold by Supermicro are not intended for and will not be used in life support systems, medical equipment,

nuclear facilities or systems, aircraft, aircraft devices, aircraft/emergency communication devices or other critical

systems whose failure to perform be reasonably expected to result in signicant injury or loss of life or catastrophic

property damage. Accordingly, Supermicro disclaims any and all liability, and should buyer use or sell such products

for use in such ultra-hazardous applications, it does so entirely at its own risk. Furthermore, buyer agrees to fully

indemnify, defend and hold Supermicro harmless for and against any and all claims, demands, actions, litigation, and

proceedings of any kind arising out of or related to such ultra-hazardous use or sale.

Manual Revision 1.0a

Release Date: August 14, 2019

Unless you request and receive written permission from Super Micro Computer, Inc., you may not copy any part of this

document. Information in this document is subject to change without notice. Other products and companies referred

to herein are trademarks or registered trademarks of their respective companies or mark holders.

Printed in the United States of America

WARNING: This product can expose you to chemicals including

lead, known to the State of California to cause cancer and birth

defects or other reproductive harm. For more information, go

to www.P65Warnings.ca.gov.

Produktspecifikationer

Varumärke:	Supermicro
Kategori:	Server
Modell:	SuperStorage 5019D8-TR12P
Vikt:	14500 g
Bredd:	813 mm
Djup:	437 mm
Höjd:	43 mm
Strömförsörjning:	400 W
LED-indikatorer:	HDD, LAN, Power, Status, Temperature
Processorfrekvens:	2.3 GHz
Processorfamilj:	Intel® Xeon®
Certifiering:	RoHS, 80 Plus Platinum
Processor:	D-2146NT
Maximalt internminne:	512 GB
Intel® Virtualization Technology for Directed I/O (VT-d):	Ja
Återställningsknapp:	Ja
Trusted Platform Module (TPM):	Ja
Minnesspänning:	1.2 V
Antal processorer som stöds:	1
Antal lagringsenheter som stöds:	12
Minnestyper som stöds:	DDR4-SDRAM, DDR4L-SDRAM
Typer av lagringsenheter som stöds:	HDD & SSD
BIOS-typ:	UEFI AMI
ACPI-version:	5.0
Maximal cache:	11 MB
Produktens färg:	Svart
Inbyggd processor:	Ja
Typ av ethernet-gränssnitt:	10 Gigabit Ethernet, Gigabit Ethernet
Datahastighet för Ethernet-LAN:	10,100,1000,1200,2500,5000,10000 Mbit/s
Antal LAN (RJ-45) anslutningar:	8
Temperatur vid drift:	10 - 35 ° C
Temperaturintervall (förvaring):	-40 - 70 ° C
Intervall för relativ operativ luftfuktighet:	8 - 90 %
Fuktighet (förvaring):	5 - 95 %
processorsockel:	BGA 2518
Processorns kodnamn:	Skylake
Hållbarhetscertifiering:	RoHS
AC-inspänning:	100 - 240 V
Fläktdiameter:	40 mm
Nätverksansluten (Ethernet):	Ja
Växelström Frekvens:	50 - 60 hz
BIOS-funktioner:	PCI 3.0, SMBIOS 2.8, UEFI
På / av-knapp:	Ja
Antal USB 3.2 Gen 1 (3.1 Gen 1) typ A-portar:	2
BIOS minnesstorlek:	128000 mbit
LAN-styrenhet:	Intel I350-AM4, Intel X557
Moderkortets chipset:	Intel® SoC
Antal M.2 (M)-platser:	1
Harmonized System (HS)-kod:	84714100
Ingående ström:	6 A
Antal fläktar:	6 fläkt/-ar
Kvalitet på VGA (D-Sub) porten:	1
Processor med ECC-stöd:	Ja
Värmeavledningseffekt (TDP):	80 W
PCI Express-kortplatser version:	3.0
Ombord grafikkort modell:	Aspeed AST2500
CPU konfiguration (max):	1
Inbäddade alternativ:	Ja
Högsta internminne som stöds av processorn:	512 GB
Storlekar som stöds på lagringsenhet:	2.5, 3.5 "
Kylning typ:	Aktiv
Koppar Ethernet-kablar teknik:	10GBASE-T
Lagringsenhetsgränssnitt som stöds:	M.2, Serial ATA III
ECC:	Ja
Trusted Platform Module (TPM)-version:	2.0
Chassityp:	Rack (1U)
Antalet DIMM-platser:	4
Som stöds DIMM-modul kapacitet:	16GB, 32GB, 64GB, 128GB
Hårddisk hot swap:	Ja
Antal 3,5 "vikar:	12
80 plus-certifiering:	80 PLUS Platinum
Systemhantering BIOS (SMBIOS)-version:	2.8
Redundanta fläktar stöd:	Ja
PCI Express x8 (Gen 3.x)-kortplatser:	1
Maximalt RDIMM minne:	512 GB
Stöd för RDIMM klockfrekvenser:	2133,2400,2666 MHz
IPMI LAN (RJ-45)-port:	Ja
Likspänning ut (+12 V):	33 A
Likspänning ut (+5 V):	3 A
Strömförsörjningsenhetens mått (BxDxH):	54.5 x 40 x 220 mm
UEFI-version:	2.4
PCI Express-platser med låg profil (Micro):	1
