USER’S MANUAL
Revision 1.1a
SuperStorage Server
6039P-E1CR16H
6039P-E1CR16L
The information in this User’s Manual has been carefully reviewed and is believed to be accurate. The vendor assumes
no responsibility for any inaccuracies that may be contained in this document, and makes no commitment to update
or to keep current the information in this manual, or to notify any person or organization of the updates. Please Note:
For the most up-to-date version of this manual, please see our website at www.supermicro.com.
Super Micro Computer, Inc. ("Supermicro") reserves the right to make changes to the product described in this manual
at any time and without notice. This product, including software and documentation, is the property of Supermicro and/
or its licensors, and is supplied only under a license. Any use or reproduction of this product is not allowed, except
as expressly permitted by the terms of said license.
IN NO EVENT WILL Super Micro Computer, Inc. BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL,
SPECULATIVE OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE OR INABILITY TO USE THIS PRODUCT
OR DOCUMENTATION, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. IN PARTICULAR, SUPER
MICRO COMPUTER, INC. SHALL NOT HAVE LIABILITY FOR ANY HARDWARE, SOFTWARE, OR DATA STORED
OR USED WITH THE PRODUCT, INCLUDING THE COSTS OF REPAIRING, REPLACING, INTEGRATING,
INSTALLING OR RECOVERING SUCH HARDWARE, SOFTWARE, OR DATA.
Any disputes arising between manufacturer and customer shall be governed by the laws of Santa Clara County in the
State of California, USA. The State of California, County of Santa Clara shall be the exclusive venue for the resolution
of any such disputes. Supermicro's total liability for all claims will not exceed the price paid for the hardware product.
FCC Statement: This equipment has been tested and found to comply with the limits for a Class A digital device
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the manufacturer’s instruction manual,
may cause harmful interference with radio communications. Operation of this equipment in a residential area is likely
to cause harmful interference, in which case you will be required to correct the interference at your own expense.
California Best Management Practices Regulations for Perchlorate Materials: This Perchlorate warning applies only
to products containing CR (Manganese Dioxide) Lithium coin cells. “Perchlorate Material-special handling may apply.
See ”.www.dtsc.ca.gov/hazardouswaste/perchlorate
WARNING: This product can expose you to chemicals including
lead, known to the State of California to cause cancer and birth
defects or other reproductive harm. For more information, go
to www.P65Warnings.ca.gov.
!
The products sold by Supermicro are not intended for and will not be used in life support systems, medical equipment,
nuclear facilities or systems, aircraft, aircraft devices, aircraft/emergency communication devices or other critical
systems whose failure to perform be reasonably expected to result in signicant injury or loss of life or catastrophic
property damage. Accordingly, Supermicro disclaims any and all liability, and should buyer use or sell such products
for use in such ultra-hazardous applications, it does so entirely at its own risk. Furthermore, buyer agrees to fully
indemnify, defend and hold Supermicro harmless for and against any and all claims, demands, actions, litigation, and
proceedings of any kind arising out of or related to such ultra-hazardous use or sale.
Manual Revision 1.1a
Release Date: May 17, 2019
Unless you request and receive written permission from Super Micro Computer, Inc., you may not copy any part of this
document. Information in this document is subject to change without notice. Other products and companies referred
to herein are trademarks or registered trademarks of their respective companies or mark holders.
Copyright © 2019 by Super Micro Computer, Inc.
All rights reserved.
Printed in the United States of America
3
3
Preface
About this Manual
This manual is written for professional system integrators and PC technicians. It provides
information for the installation and use of the server. Installation and maintenance should be
performed by experienced technicians only.
Please refer to the 6039P-E1CR16H/L server specications page on our website for updates
on supported memory, processors and operating systems (http://www.supermicro.com).
Notes
For your system to work properly, please follow the links below to download all necessary
drivers/utilities and the user’s manual for your server.
• Supermicro product manuals: http://www.supermicro.com/support/manuals/
• Product drivers and utilities: https://www.supermicro.com/wftp
• Product safety info: http://www.supermicro.com/about/policies/safety_information.cfm
If you have any questions, please contact our support team at:
support@supermicro.com
This manual may be periodically updated without notice. Please check the Supermicro website
for possible updates to the manual revision level.
Warnings
Special attention should be given to the following symbols used in this manual.
Warning! Indicates high voltage may be encountered when performing a procedure.
Warning! Indicates important information given to prevent equipment/property damage
or personal injury.
4
SuperStorage Server 6039P-E1CR16H/L User's Manual
Contents
Chapter 1 Introduction
1.1 Overview ...............................................................................................................................8
1.2 Unpacking the System .........................................................................................................8
1.3 System Features ..................................................................................................................9
1.4 Server Chassis Features ....................................................................................................10
Control Panel ....................................................................................................................10
Front Features ...................................................................................................................11
Rear Features ...................................................................................................................12
1.5 Motherboard Layout ...........................................................................................................13
Quick Reference Table ......................................................................................................14
Chapter 2 Server Installation
2.1 Overview .............................................................................................................................17
2.2 Preparing for Setup ............................................................................................................17
Choosing a Setup Location ...............................................................................................17
Rack Precautions ..............................................................................................................17
Server Precautions ............................................................................................................18
Rack Mounting Considerations .........................................................................................18
Ambient Operating Temperature ....................................................................................18
Airow ............................................................................................................................18
Mechanical Loading .......................................................................................................18
Circuit Overloading ........................................................................................................19
Reliable Ground .............................................................................................................19
2.3 Installing the System into a Rack.......................................................................................20
Identifying the Sections of the Rack Rails ........................................................................20
Releasing the Inner Rails ..................................................................................................20
Installing The Inner Rails on the Chassis .........................................................................21
Installing the Outer Rails on the Rack ..............................................................................22
Installing the System into a Rack .....................................................................................23
6
SuperStorage Server 6039P-E1CR16H/L User's Manual
Chapter 4 Motherboard Connections
4.1 Power Connections ............................................................................................................48
4.2 Headers and Connectors ...................................................................................................49
Control Panel ....................................................................................................................53
4.3 Ports ...................................................................................................................................56
4.4 Jumpers ..............................................................................................................................58
Explanation of Jumpers.....................................................................................................58
4.5 LED Indicators ....................................................................................................................61
Chapter 5 Software
5.1 Microsoft Windows OS Installation .....................................................................................64
5.2 Driver Installation ................................................................................................................66
5.3 SuperDoctor® 5 ...................................................................................................................67
5.4 IPMI ....................................................................................................................................68
Chapter 6 BIOS
6.1 Introduction .........................................................................................................................69
6.2 Main Setup .........................................................................................................................70
6.3 Advanced Setup Congurations .........................................................................................72
6.4 Event Logs .........................................................................................................................98
6.5 IPMI ..................................................................................................................................100
6.6 Security .............................................................................................................................103
6.7 Boot ..................................................................................................................................107
6.8 Save & Exit .......................................................................................................................110
Appendix A BIOS Error Codes
Appendix B Standardized Warning Statements for AC Systems
Appendix C System Specications
Appendix D UEFI BIOS Recovery
Appendix E IPMI Crash Dump
Appendix F CPU-Based RAID for NVMe
7
Contacting Supermicro
Headquarters
Address: Super Micro Computer, Inc.
980 Rock Ave.
San Jose, CA 95131 U.S.A.
Tel: +1 (408) 503-8000
Fax: +1 (408) 503-8008
Email: marketing@supermicro.com (General Information)
support@supermicro.com (Technical Support)
Website: www.supermicro.com
Europe
Address: Super Micro Computer B.V.
Het Sterrenbeeld 28, 5215 ML
's-Hertogenbosch, The Netherlands
Tel: +31 (0) 73-6400390
Fax: +31 (0) 73-6416525
Email: sales@supermicro.nl (General Information)
support@supermicro.nl (Technical Support)
rma@supermicro.nl (Customer Support)
Website: www.supermicro.nl
Asia-Pacic
Address: Super Micro Computer, Inc.
3F, No. 150, Jian 1st Rd.
Zhonghe Dist., New Taipei City 235
Taiwan (R.O.C)
Tel: +886-(2) 8226-3990
Fax: +886-(2) 8226-3992
Email: support@supermicro.com.tw
Website: www.supermicro.com.tw
8
SuperStorage Server 6039P-E1CR16H/L User's Manual
Chapter 1
Introduction
1.1 Overview
This chapter provides a brief outline of the functions and features of the 6039P-E1CR16H/L.
The 6039P-E1CR16H/L is based on the X11DPH-T motherboard and the SC836BE1C-R1K23B
chassis.
• 6039P-E1CR16H includes the Broadcom 3108 SAS3 controller.
• 6039P-E1CR16L includes the Broadcom 3008 SAS3 controller.
In addition to the motherboard and chassis, several important parts that are included with
the system are listed below.
Main Parts List
Description QuantityPart Number
Power Supply PWS-1K23A-1R 2
SAS3108 controller for 6039P-E1CR16H
SAS3008 controller for 6039P-E1CR16L
AOC-S3108L-H8IR
AOC-S3008L-L8E 1
Add-on Card AOM-SAS3-8I8E 1
Hard Drive Backplane BPN-SAS3-836EL1 1
Front Hot-swap Hard Drive Trays MCP-220-00075-0B 16
Rear Hot-swap Dual Hard Drive Tray (optional) MCP-220-83608-0N 1
Power Distributor PDB-PT826-8824 1
System Fans (Rear Exhaust) FAN-0125L4 2
System Fans (Mid-chassis) FAN-0158L4 3
Air Shroud MCP-310-39001-0N 1
Heatsink SNK-P0068PS 2
8-port Mini SAS Cable Adapter AOM-SAS3-8I8E 1
Rack Rail Mounting Kit MCP-290-00053-0N 1
1.2 Unpacking the System
Inspect the box the system was shipped in and note if it was damaged in any way. If any
equipment appears damaged, please le a damage claim with the carrier who delivered it.
Decide on a suitable location for the rack unit that will hold the server. It should be situated
in a clean, dust-free area that is well-ventilated. Avoid areas where heat, electrical noise, and
electromagnetic elds are generated. A grounded AC power outlet is also required. Read the
precautions and considerations noted in Appendix B.
13
Chapter 1: Introduction
1.5 Motherboard Layout
Below is a layout of the X11DPH-T with jumper, connector, and LED locations shown. See
the table on the following page for descriptions. For detailed descriptions, pinout information,
and jumper settings, refer to Chapter 4.
Figure 1-4. Motherboard Layout
IPMI CODE
+
BIOS LICENSE
MAC CODE
X11DPH-i
REV: 1.01
BAR CODE
LEDM1
JUIDB1
JHSSI
JPWR4 JPWR2 JPWR1
JSD1
JSD2
JSDCARD1
SATA2 SATA1
MH4
MH11
T-SGPIO1
JNCSI
JRK1
JTPM1
JPWR3
JPI2C1
JF1
JD1
JVRM2
JVRM1
JL1
JSTBY1
BT1
JPG1
JPL1
JPME2
JWD1
JIPMB1
LE1
LE4 LE3
JBT1
FAN6
FAN5
FANB FANA FAN4 FAN3
FAN2
FAN1
JHFI1
AST2500 LAN
CTRL
Intel
PCH
LE2
P2-DIMMF1
P2-DIMME1
P2-DIMMD1
P2-DIMMD2
P1-DIMMC1
P1-DIMMB1
P1-DIMMA1
P1-DIMMA2
P2-DIMMA2
P2-DIMMA1
P2-DIMMB1
P2-DIMMC1
P1-DIMMD2
P1-DIMMD1
P1-DIMME1
P1-DIMMF1
Battery
BMC
JPME1
BIOS
M.2-C2M.2-C1
CPU1-HSSI GPIO
USB 4/5(3.0)
USB 6 (3.0)
S-SATA1
S-SATA0
I-SATA 4~7I-SATA 0~3
CPU1 SLOT1 PCI-E 3.0 x8
CPU2 SLOT2 PCI-E 3.0 x16
CPU1 SLOT3 PCI-E 3.0 x8
CPU2 SLOT4 PCI-E 3.0 x16
CPU2 SLOT5 PCI-E 3.0 x16
CPU1 SLOT6 PCI-E 3.0 x8
CPU1 SLOT7 PCI-E 3.0 x8
VGA
CPU2
CPU1
LAN2 LAN1
USB 2/3(3.0)
USB 0/1(3.0)
IPMI_LAN
COM1
JP4
USB6 (3.0)
JWD1
T-SGPIO1
SLOT4
SLOT6
SLOT5
SLOT3
SLOT2
SLOT1
LEDM1
JPL1
JD1
JIPMB1
JP4
JPME2
M.2-C1
BT1
JBT1
JP2
JVRM1
I-SATA 0~3
LE3
S-SATA1
FANB
FANA
JSD1
FAN6
LE1
JUIDB1
VGA
FAN5
LAN2
LAN1
USB2/3 (3.0)
IPMI LAN
USB0/1 (3.0)
COM1
JPWR1
JPWR2
JPWR3
JF1
LE2
P2-DIMMD2
P2-DIMMD1
P2-DIMME1
P2-DIMMF1
P1-DIMMA2
P1-DIMMA1
P1-DIMMB1
P1-DIMMC1
P2-DIMMC1
P2-DIMMB1
P2-DIMMA1
P2-DIMMA2
FAN3
FAN4
JSTBY1
JPI2C1
P1-DIMMD2
P1-DIMMD1
P1-DIMME1
P1-DIMMF1
JHFI1
FAN1
FAN2
CPU1
CPU2
JTPM1
JPME1
M.2-C2
LE4
I-SATA 4~7
USB4/5 (3.0)
JSD2
S-SATA0
JL1
JRK1
JPWR4
JHSSI
SLOT7
JSDCARD1
JNCSI
JPG1
JVRM2
Note: Components not documented are for internal testing only.
Produktspecifikationer
| Varumärke: | Supermicro |
| Kategori: | Inte kategoriserad |
| Modell: | SuperStorage 6039P-E1CR16H |
Behöver du hjälp?
Om du behöver hjälp med Supermicro SuperStorage 6039P-E1CR16H ställ en fråga nedan och andra användare kommer att svara dig
Inte kategoriserad Supermicro Manualer
1 April 2025
1 April 2025
31 Januari 2025
31 Januari 2025
31 Januari 2025
31 Januari 2025
9 Januari 2025
4 Januari 2025
29 December 2024
29 December 2024
Inte kategoriserad Manualer
- Inte kategoriserad Ozito
- Inte kategoriserad Volvo
- Inte kategoriserad Signature Hardware
- Inte kategoriserad IMM Photonics
- Inte kategoriserad Howard Leight
- Inte kategoriserad Victorio
- Inte kategoriserad ANDYCINE
- Inte kategoriserad Planet
- Inte kategoriserad Forza
- Inte kategoriserad Agfa
- Inte kategoriserad BlendMount
- Inte kategoriserad Joranalogue
- Inte kategoriserad Cudy
- Inte kategoriserad Rocktrail
- Inte kategoriserad Wonky Monkey
Nyaste Inte kategoriserad Manualer
9 April 2025
9 April 2025
9 April 2025
9 April 2025
9 April 2025
9 April 2025
9 April 2025
9 April 2025
9 April 2025
9 April 2025
