Supermicro X6DAE-G Bruksanvisning

Supermicro moderkort X6DAE-G

Läs gratis den bruksanvisning för Supermicro X6DAE-G (106 sidor) i kategorin moderkort. Guiden har ansetts hjälpsam av 2 personer och har ett genomsnittsbetyg på 4.7 stjärnor baserat på 1.5 recensioner. Har du en fråga om Supermicro X6DAE-G eller vill du ställa frågor till andra användare av produkten? Ställ en fråga

Ladda ner PDF

Sida 1/106

X6DA8-G

X6DAE-G

X6DA8-G2

X6DAE-G2

USER’S MANUAL

Revision 1.1b

SUPER

The information in this User’s Manual has been carefully reviewed and is believed to be

accurate. SUPER MICRO COMPUTER assumes no responsibility for any inaccuracies that

may be contained in this document, makes no commitment to update or to keep current the

information in this manual, or to notify any person or organization of the updates.

Please Note: For the most up-to-date version of this manual, please

see our web site at www.supermicro.com.

SUPER MICRO COMPUTER reserves the right to make changes to the product described

in this manual at any time and without notice. This product, including software, if any, and

documentation may not, in whole or in part, be copied, photocopied, reproduced, translated

or reduced to any medium or machine without prior written consent.

IN NO EVENT WILL SUPER MICRO COMPUTER BE LIABLE FOR DIRECT, INDIRECT,

SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES ARISING FROM THE USE OR

INABILITY TO USE THIS PRODUCT OR DOCUMENTATION, EVEN IF ADVISED OF THE

POSSIBILITY OF SUCH DAMAGES. IN PARTICULAR, SUPER MICRO COMPUTER SHALL

NOT HAVE LIABILITY FOR ANY HARDWARE, SOFTWARE, OR DATA STORED OR USED

WITH THE PRODUCT, INCLUDING THE COSTS OF REPAIRING, REPLACING,

INTEGRATING, INSTALLING OR RECOVERING SUCH HARDWARE, SOFTWARE, OR

DATA.

Any disputes arising between manufacturer and customer shall be governed by the laws of

Santa Clara County in the State of California, USA. The State of California, County of

Santa Clara shall be the exclusive venue for the resolution of any such disputes.

Supermicro's total liability for all claims will not exceed the price paid for the hardware

product.

*California Best Management Practices Regulations for Perchlorate Materials

This Perchlorate warning applies only to products containing CR (Manganese Dioxide) Lithium coin

cells. "Perchlorate Material-special handling may apply. See WWW.dtsc.ca.gov/hazardouswaste/

perchlorate".

*FCC Statement: This equipment has been tested and found to comply with the limits for a

Class B digital device pursuant to Part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference in a residential installation. This

equipment generates, uses, and can radiate radio frequency energy and, if not installed and

used in accordance with the manufacturer’s instruction manual, may cause interference with

radio communications. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or television

reception, which can be determined by turning the equipment off and on, you are encouraged

to try to correct the interference by one or more of the following measures:

· Reorient or relocate the receiving antenna.

· Increase the separation between the equipment and the receiver.

· Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

· Consult the dealer or an experienced radio/television technician for help.

Revision Number: Rev. 1.1b

Release Date: June 5, 2007

Unless you request and receive written permission from SUPER MICRO COMPUTER, you

may not copy any part of this document.

Information in this document is subject to change without notice. Other products and

companies referred to herein are trademarks or registered trademarks of their respective

companies or mark holders.

Printed in the United States of America

Produktspecifikationer

Varumärke:	Supermicro
Kategori:	moderkort
Modell:	X6DAE-G
Bredd:	305 mm
Djup:	332 mm
Wi-Fi:	Nej
Maximalt internminne:	32 GB
RAID-stöd:	Ja
Komponent för:	Server
Minnesspänning:	2.5 V
Antal processorer som stöds:	2
Minnestyper som stöds:	DDR-SDRAM
BIOS-typ:	Phoenix
processortillverkare:	Intel
Typ av ethernet-gränssnitt:	Gigabit Ethernet
Antal LAN (RJ-45) anslutningar:	1
processorsockel:	Socket 604 (mPGA604)
Antal PS/2-portar:	1
Nätverksansluten (Ethernet):	Ja
Antal USB 2.0 anslutningar:	4
RAID-nivåer:	0, 1
Minnets hastigheter:	266,333 MHz
USB 2.0 anslutning:	4
BIOS minnesstorlek:	64 mbit
Moderkortets chipset:	Intel® E7525
Moderkort formfaktor:	Utökad ATX
Medföljande programvara:	Optional IPMI (Intelligent Platform Management Interface) 2.0 \nSuper Doctor III \nWatch Dog \nNMI\n
Lagringsenhetsgränssnitt som stöds:	SATA
Som stöds DIMM-modul kapacitet:	1GB, 4GB, 512MB, 2GB, 256MB
Stöd för processorsystembussar:	800 MHz
PCI-kortplatser:	1
Moderkort southbridge:	Intel ICH5R
PCI Express x4 platser:	1
PCI Express x16 platser:	1
Processor antal kärnor som stöds:	2
PCI-X-kortplatser:	3
