Sida 1/2

Output power（RMS）: 100W

Output Impedance: 4（ohm）

S/N： 76dB

Input sensitivity: 500mV

Frequency response: 40Hz-20kHz

Rating voltage: ~ 110V-240V 50/60Hz

Note:

Specifications and design subject to possible modification

without notice, due to improvements.

SPEAKER SYSTEM

POWERED SPEAKER

MODEL NO. :IQ-4912DJWK

POWERED SPEAKER

SYSTEM

P A N E L O P E R A T I O N E X P L A N A T I O N

M A I N T E C H N I C A L P A R A M E T E R

1. Radio FM antenna ;

2. Audio DVD or AUX input ;

3. LED switch ;

4. Voltage 110V/240V switch ;

5. HDMI output ;

6. Power on/off ;

7. AC ~110V-240V 50Hz/60Hz input

LED S WITCH

POW ER

HDM I

OUT PUT

~110 V-240 V 50Hz /60H z

VOLTAGE SWITCH

110V

240 V

SPEAKER SYSTEM SPEAKER SYSTEM

TO CUSTOMERS

Thank you for your purchase of the advanced acoustics equipment. In

order to make your unit best operation ease, please read through the

《Operation》before using the unit. It will help you to know the unit

features and make you get most satisfactory enjoy.

IMPORTANT SAFETY METHODS

Before using it, please read safety operation instruction. Please obey

warning on the unit and in operation on manual. Meaning while, obey

instruction about safety operation. These material should be well taken

of or reference.

1.power wire protection: pay attention to step or put heavy object on

power wire, especially taking care of power wire plug. Outlet socket of

unit. Do not lengthen wire or make all power supply socket over loaded.

Because this can cause fire or electricity shock. Do not pull drug power

wire.

2.aeration: the unit must be put in places where the aeration is good. In

order to keep seration good, do not put dist or cloth on it.

The distance between the unit and the wall should be more than 10cm.

Do not put it on bed, sofa, carpet or similar object surface to avoid

shocking intake.

3.unit shell remove wire. Avoid removing unit shell. If you touch inner

components, severe risk of electricity shock happen.

4.exceptional smell if you find exceptional smell or smoke. You should

immediately cut power supply and remove plug from socket and

connect with sell shop or the nearest maintain center.

5.attention: the unit uses AC220V-240V/50HZ-60HZ power supply. Do

not use nonstandard power supply and low power adjust stable power

supply.

BACK PANEL CONNECTION

Power supply plug

Left/right voice box output

Left/right voice resource input

OPERATION INSTRUCTION FOR KARAOKE

When playing karaoke programes, you can use karaoke function for singing

1.insert the microphone plug into the microphone input MIC2

2.adjust the microphone volume knob MIC VOL for proper volume. Then

adjust the echo depth to the proper position. Now you can start the karaoke

and exert your sing talent.

P A N E L O P E R A T I O N E X P L A N A T I O N

T O A L L C U S T O M E R S

1. Echo control

2. MIC volume control

3. Bass volume

4. Treble volume

5. Volume

6. MIC1 jack

7. Guitar jack

8. EQ control

9. Guitar volume control

10. Audio input key

11. MIC2 jack

GUI. VOL

MIC 2

MIC 1

GUITAR

AUDIO INP UT

MIC PRIOR IT Y

AUX

WIF I

OFF

Produktspecifikationer

Varumärke:	SuperSonic
Kategori:	högtalaranläggning
Modell:	IQ-4912DJWK
Vikt:	19998 g
Bredd:	335 mm
Djup:	304 mm
Höjd:	1117 mm
Handtag:	Ja
Förpackningens bredd:	381 mm
Mobila operativsystem som stöds:	Android, Android 4.4
Transporthjul:	Ja
Modell:	Fristående PA-system (Public Address)
Impedans:	4 Ω
Bashögtalare:	Ja
Karaoke:	Ja
Fjärrkontroll ingår:	Ja
Typ av minneskort:	SD
Produktens färg:	Svart
Antal USB-portar:	1
Låddjup:	355 mm
Vikt inkl. förpackning:	21999 g
Inbyggd kortläsare:	Ja
Uteffekt (RMS):	80 W
diskanthögtalare:	Ja
AC-inspänning:	110 V
Equalizer:	Ja
Frekvensområde:	40 - 20000 hz
Anslutningsteknologi:	Kabel & Trådlös
Monteringssätt:	Golv
Strömkälla av typen:	AC
Strömingång:	Ja
Växelström Frekvens:	60 hz
Modulator:	FM
Antal USB 2.0 anslutningar:	1
Woofer diameter (imperial):	12 "
Bluetooth:	Ja
Hanterar mängd:	1
Uttag för mikrofon/linje in:	Ja
Antal talare:	1
Aux-In:	Ja
Antal woofer-drivenheter:	2
Signal/brusförhållande (SNR):	78 dB
Display inkluderad:	Ja
Högsta musikuteffekt (PMPO):	4000 W
Mikrofon inkluderad:	Ja
Equalizer tonkontroller:	5
Disktanthögtalare diameter:	1 "
Antal tweeter förare:	1
Övergångsfrekvens:	3000 hz
Mixerfunktion:	Ja
Antal mikrofoner inkluderade:	1
