SureFly Tach2 Installation Instructions
SF2002, Revision IR
Page 1 of 8
Technical Support:
817 373 5161- -
M F, 8:30a 4:30p, CDT – –
TACH2
INSTALLATION INSTRUCTIONS
Document No. SF2002, Revision IR
Revision History
Revision:
Date:
Description:
Approved
By:
IR
07/17/2020
Initial release.
RVC
SureFly Partners, LTD.
350 Howard Clemmons Rd.
Granbury, TX 76048
SureFly Tach2 Installation Instructions
SF2002, Revision IR
Page 2 of 8
Technical Support:
817 373 5161- -
M F, 8:30a 4:30p, CDT – –
Contents
Contents ................................................................................................................................................. 2
1. Installation Overview ...................................................................................................................... 3
1.1. General Description: ................................................................................................................... 3
1.2. Technical References: ................................................................................................................ 3
1.3. Compatible Electronic Tachometers: .......................................................................................... 3
2. Step- -Step Installation Instructions By ............................................................................................ 4
2.1. Mounting the Tach2 Unit: ............................................................................................................ 4
2.2. Wiring the Tach2 Unit: ................................................................................................................ 4
3. Post-Installation .............................................................................................................................. 8
3.1. Final Inspection: .......................................................................................................................... 8
3.2. Operational Check: ..................................................................................................................... 8
3.3. Radio Interference Test: ............................................................................................................. 8
a) All Installed VHF COMM and NAV Radios (record frequencies utilized): . 8................................
b) GPS (if installed): ........................................................................................................................ 8
c) Resolution: .................................................................................................................................. 8
4. Documentation ............................................................................................................................... 8
4.1. ICA: ............................................................................................................................................. 8
SureFly Partners, LTD.
350 Howard Clemmons Rd.
Granbury, TX 76048
SureFly Tach2 Installation Instructions
SF2002, Revision IR
Page 3 of 8
Technical Support:
817 373 5161- -
M F, 8:30a 4:30p, CDT – –
1. Installation Overview
1.1. General Description:
The Tach Signal Converter (Tach2) converts SIM P-Lead signals to negative going signals compatible with –
the Horizon P-1000 digital tachometer input and to a positive-going 0-5V square wave signal compatible with
electronic tachometers that rely on a signal from a magnetic pickup inserted into a magneto. Tach 2 can
accept one or two SIM P-Leads as input, converts and conditions the signals and outputs them to
corresponding output terminals.
The Tach2 must be installed in the aircraft cabin and secured to the airframe with screws and nuts.
The Tach2 power input from the aircraft bus may range from 8.5VDC to + 30VDC without damage.
The Tach2 consumes less than 0. A of power. 25
1.2. Technical References:
The following documents may be referenced during the installation of the Tach2:
1. SureFly Tach2 Installation Instructions: SF2002 (this document),
2. FAA Advisory Circular 43.13- Acceptable Methods, Techniques, and Practices. 1b
Copies of these documents may be found at www.surey.aero/airframe
1.3. Compatible Electronic Tachometers:
Compatible electronic tachometers are:
1. P-Lead signals negative-going compatible with the Horizon P-1000 digital tachometer input,
2. P-Lead signals positive-going 0-5V square wave signal that previously relied on a signal from a
magnetic pickup inserted into a magneto.
Produktspecifikationer
| Varumärke: | SureFly |
| Kategori: | ej kategoriserat |
| Modell: | Tach2 |
