Thank you for choosing SYNCO product.

Please read this manual carefully before use and follow all instructions mentioned

herein.

Microphone CMic-V10 User Manual

Caring For Your SYNCO Product

Please keep the product in a dry, clean, dust-free environment.

Keep corrosive chemicals, liquids and heat source away from the product to

prevent mechanics damage.

Use only a soft and dry cloth for cleaning the product.

Malfunction may be caused by dropping, impact of external force.

Do not attempt to disassemble the product. Doing so voids warranty.

Please have the product checked or repaired by authorized technicians if any

malfunctions happened.

Failure to follow all the instructions may result in mechanics damage.

Warranty does not apply to human errors.

1. The Use of Wind Mu󽗈

Product Introduction

Operations

It is highly recommended that you set the recording level on your camera

quite low, 1/2 or 1/3 of it at 󽗉rst, and tailor your levels to just about

environment and recording device.

① High Frequency Boost

② High-pass Filter

③ Front Attenuator

Speci󽗉cations

1. Polar Pattern: Hyper-cardioid

2. The Use of Mic Clip

The 5/8” screw and 3/8” screw accessible mic clip is for attaching accessories

like boompole, mic stand.

3. The Use of Microphone

Connect the mic with the device via the XLR cable.

5/8” screw 3/8” screw

Block 15th, No.200 Fangcun Avenue East, Liwan District, Guangzhou, China, 510000

support@syncoaudio.com

www.syncoaudio.com

https://www.facebook.com/syncomicrophones

Guangzhou Zhiying Technology Co., Ltd

Warranty Exclusions and Limitations

Faults resulted from inappropriate use of a product without following its

operation speci󽗉cation

Arti󽗉cial damage, e.g. crash, squeeze, scratch, or soaking

Warranty Claim Procedure

If failure or any problem occurs to your product after purchase, please contact

a local agent for assistance, or you can always contact SYNCO’s customer

service through email at

support@syncoaudio.com.

Please retain your sales receipt and warranty certi󽗉cate as proof of purchase.

If any of these documents is missing, only sales return or chargeable service

will be provided.

If the SYNCO product is out of the warranty coverage, the service and the

parts cost will be charged.

Transducer

Frequency Response

Signal/Noise

Maximum SPL

Sensitivity

Impedance

Equivalent Noise Level

High Frequency Boost

High-pass Filter

Front Attenuator

Output Connector

Operating Voltage

Operating Current

Material

Dimensions (φ×L)

Weight

Back Electret Condenser

40Hz-18KHz

82dB (1KHz at 1Pa)

130dB (T.H.D≤1% at 1KHz)

-32dB±3dB (1dB=1V/Pa at 1KHz)

600Ω±20%

14dB(A)

+3dB at 4~5KHz

150Hz

-10dB

XLR 3-Pin

12V-52 V (Phantom Power)

≤2mA

Metal

23 x 145mm

94g

2. Performance Parameter

Warranty Period

Thank you for purchasing SYNCO products.

1. Customers are entitled to free replacement or repair service in case of quality

defect(s) found in the product under normal use within 30 days upon receipt of

the product.

2. Original SYNCO products are entitled to limited warranty service. 12-month

The warranty period begins on the date of purchase of brand new, unused

products by the 󽗉rst end-user.

Within the warranty period, if product defect or failure is attributable to material

defection or technological problem, the defective product or defective part will

be repaired or replaced without charge (service and materials fee).

Warranty

Modi󽗉cations to a product by its user or a third party without prior written

consent of SYNCO, e.g. replacement of element or circuit, label alteration

The code on product is inconsistent with that of warranty certi󽗉cate, or the

code on the product or warranty certi󽗉cate is altered or torn o󽗈

All consumable accessory attached to a product, like cable, wind mu󽗈, battery

Faults as a result of force majeure, such as 󽗉re, 󽗊ood, lightning, etc.

WARRANTY CERTIFICATE

USER

INFORMATION

SALES

INFORMATION

REPAIR

RECORD

RESULT

Please register your warranty. Meanwhile, you are welcomed to contact us

via Email：support@syncoaudio.com

Customer Name:

Phone Number:

Email:

Address:

Sales Date:

Model:

Product Code:

Dealer:

Service Date:

Technician:

Issue:

Solved Unsolved Returned(Replaced)
