Microphone G3 User Manual
Thank you for choosing SYNCO product. Please read this manual
carefully before use and follow all instructions mentioned herein.
Caring For Your SYNCO Product Product Introduction
Package List
Please keep the product in a dry, clean, dust-free environment.
Keep corrosive chemicals, liquids and heat source away from the
product to prevent mechanics damage.
Use only a soft and dry cloth for cleaning the product.
Malfunction may be caused by dropping, impact of external force.
Do not attempt to disassemble the product. Doing so voids warranty.
Please have the product checked or repaired by authorized technicians
if any malfunctions happened.
Failure to follow all the instructions may result in mechanics damage.
Warranty does not apply to human errors.
RX Receiver
x1
Carrying Bag
x1
TX
Transmitter
x2
User
Manual
x1
Mic
Windshield
x2
Lightning
to Type-C
Adapter x1
TRRS to
TRRS Cable
x1
Usb-A to
Type-C
Adapter x1
Type-C to
Type-C
Cable x1
RX Receiver
TX Transmitter
① Volume Control Button
② Built-In Mic
③ Switch Button
④ 3.5mm Monitoring Port
① Switch Button/Back Button
② Setting Button
③ Up Option Button
④ Down Option Button
⑤ Display Screen
⑤ Recording Button
⑥ Pocket Clip
⑦ Contacts (For Charging And File
Transmission)
⑥ Type C/Digital Output Port
⑦ 3.5mm TRS/TRRS Output
⑧ 3.5mm Monitoring Port
⑨ Rx Built-In Mic
⑩ Pocket Clip
TX Indicator
Blue/green indicator on transmitter corresponds to the A/
B transmitter shown on the receiver screen
Blue/green indicator
ashes
Blue/green indicator keeps
on
Orange indicator on
Red indicator on
Red indicator o
Orange indicator o
Blue / green indicator
lights up and ashes at the
same time
The transmitter waiting for
connection
The transmitter successfully
connected to the receiver
Charging
Recording on
Recording o
Fully charged
Reset completed
Working
Indicators
Recording Indicators
Basic Operations
TX Transmitter
RX Receiver
1. Power on & Power o
Method 1：The TX will automatically powers on when push out the
TX upwards in the direction shown in the gure. When put back the
transmitter, it will automatically charge and shut down when fully charged.
1. Power on /o
Long press the switch button on the RX for 3 seconds to switch on/o.
3. Recording
Long press the recording button on the TX for 3
seconds to enter or exit recording. When enter
the recording mode, the red light turns on. When
exit the recording mode, the red light o.
＊ A single recording audio le lasts for a
maximum of 22 hours.
4. Monitor
Insert the monitoring device into 3.5mm monitoring
port of TX to monitor the TX input sound. Adjust the
ve-level monitoring volume when press the volume
button on the TX.
＊ This port of the TX is used as output only, not input.
2. Reset
Long press the up and down buttons 8 seconds to reset the RX when
power on.
2. Reset
When the TX power o, long press the switch
button for 8 seconds until the indicator ashes
blue-green and enters the reset state.
Method 2：Long press the switch button on the front of the transmitter
for three seconds.
3s/8s
3s
3. Monitoring
Insert the monitoring headset into the 3.5mm monitoring port of the
receiver for monitoring in real time.
＊ The TX power on successfully when the indicator
keeps blue/green, and power off when the indicator off.
＊ The TX automatically shuts down in 5 minutes without
connection or recording.
Function Operations
1. Display Screen
① Transmitter A
② Transmitter B
③ Transmitter Signal
④ Transmitter Power
⑤ Transmitter Power Level
⑥ Sound Eect Of Left Channel
⑦ Gain Value Of Left Channel
⑧ Sound Eect Of Right
Channel
⑨ Gain Value Of Right Channel
⑩ Receiver
⑪ Receiver Power
⑫ Power Level Of Receiver
Microphone Power Level
⑬ Gain Value Of Receiver
⑭ Frequency Setting/Version
Information
⑮ Output Channel Option
⑯ USB Port Output Gain
⑰ 3.5Mm Port Output Mode
⑱ 3.5Mm Port Output Gain
⑲ Monitoring Port Output Mode
⑳ Output Channel Option
㉑ Monitoring Port Volume
2. Set Panel Parameters
1. When the RX powers on, press any button to
light up the screen.
2. Switch the panel with the up or down option
button.
3. The selected panel will be highlighted by short
pressing the Setting button(SET).
4. Short press the switch button returns to the
upper level.
1). TX Option
(1) Set the mute switch of each TX,
(2) Check the recording storage duration of each emitter.
＊ Note: When the memory card is full, the icon of the TX will ash red
as shown in the gure.
3. Option Information
2). Sound Channel Option
Set the sound of each channel, including:
① Noise reduction
② High frequency light-up
③ EQ sound eect
④ Gain adjustment of channel
3). RX Option
① Set microphone of RX on/o ② Gain microphone of RX on/o
