IMPULSE IR LOADER

Service Manual

Created: 29 May 2021

Cab Sim and IR Loader to Host All of Your Favorite Impulse Responses

with 20 built in cab models, A/B mode, 99 IR slots and supports IR

lengths up to 200ms

drawings and diagrams) contained in this document is the property of MUSIC Group IP Ltd., its subsidiaries or content providers, and is protected by intellectual property (copyright,

trademark, patents, etc) laws, international treaty provisions and other laws. Any unauthorized disclosure, use, application, reproduction, modication, lease, sale, transmission or

any other dealings in the information may violate applicable laws and result in civil and/or (where applicable) criminal liabilities and penalties.

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

PCB Schematic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Exploded Drawing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

IMPULSE IR LOADER

Specications

- Cab Sim and IR loader with 20 built in cab models for guitar and bass

- Transforms your pedalboard into a gig-ready DI guitar rig when placed at the end of your signal chain

- Load an acoustic guitar IR and place after your instrument in the signal chain. Transforms your piezo

pickup from dull to full

- Comes pre-loaded out of the box with 12 of the most popular official Celestion speaker cab IRs

- 79 empty slots to load in your own impulse response files for guitar cabs, bass cabs, acoustic

instruments, etc…

- Super simple controls. Output level, next IR, previous IR, that’s it!

- Easy IR loading. Drag and drop your IR files from your computer onto IMPULSE via USB using the

dedicated APP or a standard file explorer. IMPULSE does the rest

- A/B mode lets you instantly toggle between 2 different IR’s in real time via the footswitch

- TrueBypass mode for convenient A/B your rig with and without IR via the footswitch

- High output range for easy integration into all setups

- 24-bit uncompressed audio for ultimate sound quality

- Loads IR’s up to 200ms in length

- Supports 44.1, 48 and 96Khz sample rates

- Supports PCM 16 / 24 / 32-bit and 32-bit float format

- Ultra small enclosure easily fits on any pedalboard

- True bypass retains signal integrity when pedal is off

- 3-Year Warranty Program

- Designed and engineered in Denmark
