Makro Soundstation X6

User Manual

The Declaration of Conformity for this device is under: www.technaxx.de/

(in bottom bar “Konformitätserkärung”)

Portable Mini Speaker System with built-in Radio

Features

 Mini speaker system for iPhone, iPad, iPod, Mobile phones, Tablet PC, PC/Notebook

 MicroSD card slot & USB slot up to 32GB

 AUX entrance for connection of other audio devices

 Built-in rechargeable (~4 hours) Lithium battery 600mAH (via USB cable)

 Playing time with MicroSD card / USB: ~11 hours / ~6 hours

 Durable aluminum housing in 5 trendy colours

 Easy installation and excellent sound quality

 Small and handy, ideal for traveling

How to use:

Function of buttons

USB slot

Mode

Micro USB slot

Back  and VOL–

MicroSD card slot

Forth  and VOL+

3.5mm earphone jack

Play / Pause /

Indicator light

Power ON / OFF

10 POWER ( ): Press the POWER button for 2 seconds to turn on the speaker, indicator

light turns to BLUE; the same operation turns off the speaker.

Playing Music by 3 MicroSD card or 1 USB: Turn on the speaker, plug in the slot a

MicroSD card or USB, then the speaker starts streaming music. Press the button to

play/pause. Press the /－ button to go back to last song or decrease volume. Press the

/＋ button to move on to next song or increase volume. Press the MODE button to change

to different functions.

4 Earphone Jack: Plug the cable into the earphone 3.5mm jack slot. After that you will be

able to listen to music through the earphone.

6 MODE: If the speaker is turned on, press shortly the MODE button to transfer from

MicroSD card to USB, FM Radio Mode, Line-IN/AUX (it works only if the 3.5mm Line-IN cable

is plugged).

7 BACK/VOL– ( /

－

): Press the button shortly to go back to last song, press longer to

decrease the volume.

8 FORTH/VOL+ ( /

＋

): Press the button shortly to move on to next song, press longer to

increase the volume.

9 PLAY/PAUSE ( ): Press the button shortly to pause or restart when playing music,

listening to radio.

Handling FM Radio:

Plug in 3.5mm Line-IN cable or charging cable into the slot for better

reception. If the speaker is used as FM radio, pressing the MODE button for 2 seconds to

search tracks. The speaker searches available tracks automatically and stores after pre-

playing, meanwhile the indicator light flashes in BLUE until the search ends. Then press the

button to play/pause. Press the /－ button to last track or decrease volume. Press the

/＋ button to next track or increase volume. Press the MODE button to transfer to MicroSD

card or to USB or Line-IN. The speaker enters FM radio automatically when MicroSD card or

USB or Line-IN is not available.

Handling LINE–IN:

Plug one end of 3.5mm cable into the speaker and the other end into

Line-IN slot, Mobile Phone, PC, Notebook, Tablet PC, MP3/MP4 Player etc. After that, press

the MODE button and select Line-IN. Then you can listen to music.

Charging:

Plug the cable into the Line-IN slot, USB slot of PC or another USB slot of

chargers to charge the speaker. When the speaker is being charged, the indicator light turns

to RED. Once it is fully charged, the indicator light turns off. (It is recommended to turn off the

speaker while charging, because it will take longer time to get completely charged if the

speaker works while charged.)

FAQ (important questions) and Warnings

 The speaker cannot be turned on after pressing the POWER button or it turns off while

turning on  Is it fully charged? (if the speaker has no power, charge it and try again).

 The speaker must be charged in DC 5V slot (otherwise it may fail to work or even be

damaged.)

 Do NOT increase the volume of your mobile phone / PC / MP3-MP4 player / CD / DVD /

etc. to a large or to the maximum loudness, because it may cause a sound distortion or may

damage the speaker. In case of a sonic boom or sound distortion, decrease the volume either

of the mobile phone / PC / MP3-MP4 player / CD / DVD / etc. or of the speaker itself. The will

sound go to normal soon.

Technical Specifications

Function MicroSD card, USB flash drive, Line-IN, FM

Sound track Mono

Earphone output Ø 3.5mm jack

Audio output USB audio slot

Output power maximum 3W (4 Ω)

Impedance 4 Ω

Frequency response 150Hz ~ 18KHz (here with OUT Ω)

S / N ratio 80 dB

Sensitivity 420 mV

Distortion degree 1% (here with OUT Ω), 1W, 1KHz

Power source DC 5V

Battery Built-in rechargeable 3.7V 600mAh Lithium battery

Charging time ~ 4 hours

Playing time with MicroSD card ~ 11 hours

Playing time with USB ~ 6 hours

Material speaker case Metallic material + ABS plastic

Speaker Ø / Weight 45mm / 153g

Package Contents:

MusicMan

Makro Soundstation X6, Micro 5 PIN charging cable, 3.5mm

Line–IN cable, User Manual

Security and Disposal Hints for Batteries: Hold children off batteries. When a child swallowed a battery go to a doctor’s place or bring the

child into a hospital promptly! Look for the right polarity (+) and (--) of batteries! Always change all batteries, never use old and new batteries

or batteries of different type’s together, never short batteries. Do NOT open, deform or load up batteries! There is a risk of injury by battery

leakage fluid! NEVER throw batteries into fire! There is a risk of explosion!

Hints for Environment Protection: Packages materials are raw materials and can be recycled. Do not disposal old devices or

batteries into the domestic waste. Cleaning: Protect the device from contamination and pollution. Only clean the device with soft

cloth or drapery, avoid using rough or coarse-grained materials. Do NOT use solvents or aggressive cleaner. Wipe the device after

cleaning accurately. Important Notice: Should battery fluid leak from a battery, wipe the battery-case with a soft cloth dry.
