Mini MusicMan MA

Mobile Speaker / Soundsystem

User Manual

Please find the Declaration of Conformity for this device under following internet-link:

www.technaxx.de//konformitätserklärung/mini_musicman_ma

 Mini mobile stereo wide range speaker system for MP3/4, CD/DVD, iPhone, iPad, iPod,

PSP, mobile phones, PC/Notebook, TF/MicroSD cards up to 32GB.

 Aluminium for lightweight but very durable housing, available in different metallic colours.

 Several power supply options: integrated rechargeable battery, computer USB or AC

adapter DC-5V* (*not included).

Key functions

 JH-MD06 functions MP3 decoding, capable of directly inserting a TF/MicroSD card for

playing music.

 JH-MD06 can decode the MP3 format music play.

 When insert directly the TF/MicroSD, music plays in the last volume. Press VOL+ to

increase volume, press VOL – to decrease volume.

 Default mode is Line-in mode. When inserting a TF/MicroSD card it changes to the

TF/MicroSD mode automatically to play music.

Key Function

Play / Pause / Stop

VOL –

Volume down

VOL +

Volume up

One back / Last music

Next one / Next music

Technical specifications

Loudspeaker 1x 1.77” (external diameter 45mm) magnetic resistant 4 Ohm

Line in / 5V USB power supply, audio input

Signal / Noise Ratio

≥80dB

Flash memory TF/MicroSD cards up to 32GB

Battery Built-in rechargeable Lithium battery 600mAh (playing 2–3 hrs.);

can play music and be charged when using the USB power

Output RMS3W THD=10%

Frequency response 150 – 18000Hz (±3dB)

Power supply 5V/1000mA AC adapter* (*not included) or computer USB power

rotate connect line – you can choose

Charging process

(3 – 5 hours)

When power OFF, LED turns red while charging. When charging

is completed, LED turns off.

When power ON, LED turns pink while charging. When power ON

but no charging process, LED turns to blue colour.

ON / OFF

(Power switch)

ON button: turn to ON, then power ON and start playing music

OFF button: turn to OFF, then power OFF

Package Contents: Mini Musicman, USB/Audio cable, User manual

Security and Disposal Hints for Batteries

• Hold children off batteries. When a child swallowed a battery by mistake go to a doctors place or bring the child into a hospital

promptly!

• Look for the right polarity (+) and (▬) of batteries! Always change all batteries, never use old and new batteries or batteries of different

types together. Never short batteries.

• Do NOT open, deform or load up batteries! There is a risk of injury by battery leakage fluid!

• NEVER throw batteries into fire! There is a risk of explosion!

• Take out exhausted batteries from the device and take out batteries from the device when its not used over a longer period of time.

Hints for Environment Protection

Cleaning: Protect the device from contamination and pollution. Only clean the device with soft cloth or drapery, avoid using rough or

coarse-grained materials. Do NOT use solvents or other aggressive cleaner. Wipe the device after cleaning accurately.

Important Notice: Should battery fluid leak from a battery, wipe the battery-case with a soft cloth dry and put in a new battery!

Packages materials are raw materials and can be recycled. Separate the packages by types and put them to an

adequate recycling on behalf of the environment. More detailed information you get from your official civil service.

Do not disposal old devices into the domestic waste. Disposal old / defective devices professionally! The

environment will be grateful for that.

Do not disposal batteries into the domestic waste. Disposal old / empty / defective batteries professionally! The

environment will be more than grateful for that.

Mini MusicMan MA

Système audio / Haut-parleur mobile

Manuel d'utilisation

La déclaration de conformité de ce produit peuvent être consultés à l'adresse internet:

www.technaxx.de//konformitätserklärung/mini_musicman_ma

 Mini système stéréo mobile de haut-parleur pour lecteur MP3/4, CD/DVD, iPhone, iPad,

iPod, PSP, téléphones mobiles, PC/ordinateur portable, cartes TF/Micro SD jusqu’à 32GB.

 Boîtier en aluminium léger et robuste, disponible en plusieurs coloris métalliques.

 Plusieurs alimentations possibles: batterie rechargeable intégrée, USB ordinateur ou

adaptateur CA (DC-5V *non fourni).

Fonctions des boutons

 Le JH-MD06 reconnaît les MP3 et lit les cartes TF/MicroSD pour jouer de la musique.

 Le JH-MD06 prend en charge la lecture de musique au format MP3.

 Si vous insérez directement une carte TF/MicroSD, la musique sera jouée au volume

précédemment réglé. Appuyez sur VOL+ pour augmenter le volume, appuyez sur VOL –

pour diminuer le volume.

 Le mode par défaut est le mode d’entrée de ligne. Si vous insérez une carte TF/MicroSD,

l’appareil passera automatiquement en mode TF/MicroSD pour jouer la musique.

Bouton

Fonction

Lecture/pause/stop

VOL –

Baisser le volume

VOL +

Monter le volume

Piste de musique

MARCHE/ARRÊT

PRISE CASQUE

ENTRÉE DE

LIGNE

Produktspecifikationer

Varumärke:	Technaxx
Kategori:	högtalare
Modell:	Mini MusicMan MA
Vikt:	150 g
Bredd:	50 mm
Djup:	50 mm
Höjd:	50 mm
LED-indikatorer:	Nej
Volymkontroll:	Digital
Rekommenderad användning:	MP3-spelare
Impedans:	4 Ω
Antal förare:	1
Kompatibla produkter:	- MP3/4, CD/DVD, iPhone, iPad, iPod, GPS, PSP, mobile phones, PC/Notebook\n- USB, TF/MicroSD
Total harmonisk distorsion (THD):	10 %
Förstärkare:	Inbyggd
Batteriteknik:	Litium-Ion (Li-Ion)
Antal batterier:	1
Produktens färg:	Grön
Uteffekt (RMS):	3 W
diskanthögtalare:	Nej
Equalizer:	Nej
Material, hölje:	Plast
Kabel inkluderad:	AUX, USB
Frekvensområde:	150 - 18000 hz
Anslutningsteknologi:	Kabel
Batterispänning:	5 V
Drifttid för batteri:	5 h
Uttag för mikrofon/linje in:	Ja
Antal talare:	1
Högtalartyp:	1-vägs
Aux-In:	Ja
