Technaxx

* User Manual

WiFi Rear Camera System TX-171

Suitable for most of cars (& vans, SUVs, minibuses, caravans, etc.)

as assistance for reverse parking.

This system should be an aid and should NOT replace the need to drive

carefully.

Do not point the high pressure cleaner directly to the plate holder

camera, or drive through a car wash - the device can be damaged.

NOTE: The Smartphone in the car may only be used if it is firmly fixed in

a holder.

Under no circumstances will the manufacturer or supplier accept any

responsibility or can held liable for any direct or indirect, incidental or

consequential damage, or for injuries resulting from installing or use of

this system.

The manufacturer Technaxx Deutschland GmbH & Co.KG hereby declares

that this device, to which this user manual belongs, complies with the

essential requirements of the standards referred to the Directive RED

2014/53/EU. The Declaration of Conformity you find here:

www.technaxx.de/ (in bar at the bottom “Konformitätserklärung”). Before

using the device the first time, read the user manual carefully.

Service phone No. for technical support: 01805 012643 (14 cent/minute from

German fixed-line and 42 cent/minute from mobile networks). Free Email:

support@technaxx.de

The support hotline is available Mon-Fri from 9 am to 1 pm & 2 pm to 5 pm

Keep this user manual for future reference or product sharing carefully. Do

the same with the original accessories for this product. In case of warranty,

please contact the dealer or the store where you bought this product.

Warranty 2 years

Enjoy your product. Share your experience and opinion on one of the

well-known internet portals.

2

Contents
Features ........................................................................................................ 2
Technical specifications ................................................................................. 3
Safety regulations .......................................................................................... 4
Product overview ........................................................................................... 4
License plate holder with camera ............................................................... 4
Commissioning .............................................................................................. 4
Insert the license plate in the holder .............................................................. 7
Camera angle adjustment .............................................................................. 7
Download & install the APP ........................................................................... 8
iOS: Setting up the WiFi connection: .......................................................... 8
Android: Setting up the WiFi connection: .................................................... 9
Start/Open the APP JoyTrip ..................................................................... 10
Tips, Note & Attention .............................................................................. 11
FAQ ............................................................................................................. 11
General information ..................................................................................... 12
Environmental conditions ............................................................................. 12
Disposal ....................................................................................................... 13

Features
⚫ Inconspicuous reversing camera in license plate holder
⚫ Suitable for most vehicles as assistance for reverse parking
⚫ Your Smartphone needs to support IEEE 802.11ac 5GHz
⚫ Video stream over WiFi 5GHZ to Smartphone APP (JoyTrip)
⚫ Wireless video transmission up to ~15m
⚫ IR LED for clear night vision ~3m
⚫ Adjustable camera alignements & 120° viewing angle
⚫ Power supply of the camera by connection to the reverse light
⚫  IP67  camera  protection  class  (dustproof  &  protection  against
temporary immersion)
⚫  License  plate  holder  suitable  for  single-line  registration
(52x11cm)
⚫ Distance displayed by reversing line on the Smartphone
⚫ Take photos and videos via App
⚫ More safety in reverse driving


Technical specifications

License plate holder with camera and WiFi module

Image sensor

2MP CMOS

Camera resolution / fps

1024x720 pixel / 30

Video compression

H.264

Viewing angle

120°

Min. illumination

0.1Lux / automatic white balance

IR night vision distance

~3m

Power supply

DC12V

Max. current

<270mA

Power wire length

Ca. 4m

Protocol

IEEE 802.11 ac

Transmission frequency

5GHz

Transmission distance

~15m open space (no interferences)

Max. radiated output power

80mW

Protection class

IP67

Operating temperature

–20°C up to +50°C

App name / version

JoyTrip / iOS version 12.0 and higher and

Android version 9.0 and higher

App Language

DE, EN, FR, SP

Weight / Dimensions

260g / (L) 52.8 x (W) 3.7 x (H)

12.6cm

Packing

Contents

WiFi Rear Camera System TX-171:

License plate holder with camera, WiFi transmitter

and power connection, Mounting material, User

Manual
