Sida 1/1
HW 1
User manualEN
• Please follow the instructions for using the appliance.
• Do not open, dismantle, cut or pierce the product with metal objects.
• Switch off the appliance immediately and stop using it if you notice sparks,
smoke or odours during operation.
• Do not expose the product to heat sources or open ames. Do not immerse it
in water or re and avoid prolonged exposure to direct sunlight.
• The operating temperature of the device is between 0 °C and 45 °C (32-
113 °F), with a relative humidity of 20-70 %. Keep it away from moisture, heat,
water and re.
• Please observe the applicable local laws and regulations.
1. Battery status display:
By pressing the on/off switch twice quickly, the current battery status is shown
on the LED display (in any operating status):
• 1 blue light: battery level 0-30 %
• 2 blue lights: battery level 30-66 %
• 3 blue lights: battery level 66-100 %
The blue light ashes when the hand warmer is charging.
1. Main function:
The charging station charges the hand warmer when it is inserted.
2. Key functions:
• Pressing and holding the on/off switch (approx. 3 seconds) activates the
manual heating mode (red LED lights up).
• A short press switches between the heating levels.
• A long press switches the hand warming mode off again.
2. Battery status display:
• Briey pressing the battery status button on the underside of the charging
case displays the current battery status via the blue LED.
3. Charging process:
• Charging process via PWM trickle charge and constant current charging.
• Use a 5V/2A power supply unit.
• LEDs 1-4 light up in sequence as the battery level increases.
• When fully charged, all 4 LEDs light up permanently.
4. Standby time
• At 25 % battery level: approx. 3 months
• At 50 % battery level: approx. 6 months
5. Battery life (fully charged):
A fully charged battery and fully charged hand warmer result in three times the
service life of the hand warmer.
3. Heating temperature:
• 1 red light: 35-42 °C
• 2 red lights: 42-48 °C
• 3 red lights: 48-55 °C
4. Charging mode:
Place the hand warmer in the charging station for charging.
• Chargin not start automatically if the battery level is above 98 %.
• D ged,
t y
D
2. Safety instructions
1. Delivery
3. Use of hand warmer 4. Use of charging case
5. Specications
Conformity information
Telestar GmbH hereby declares that the following device is in compliance with
the essential requirements and other relevant provisions of the RoHS Directive
2011/65/EU including the Delegated Directive (EU) 2015/863 and the REACH
Regulation (EC) No. 1907/2006:
TELESTAR HW 1 (Art-No. 5100003)
The declaration of conformity for these products is available to the company:
TELESTAR GmbH, Brückenstraße 2, D-97618 Niederlauer
You can download the declaration of conformity from our homepage:
https://www.telestar.de/support/dl/
Version 1.0 (07/2025)
TELESTAR GmbH, Brückenstraße 2, D-97618 Niederlauer
Telefon: 09771 / 63567-200 Fax: Telefon: 09771 / 63567-144
www.telestar.de, info@telestar.de
Note: The button functions and other functions of the hand warmer are de-
activated during the charging process. The charging container can charge
several hand warmers at the same time. Although this extends the charging
time, it does not impair the function. The charging station has a temperatu-
re detection function: if the temperature exceeds 60 °C, a protective mecha-
nism is activated which limits the charging and discharging currents.
• Hand warmer dimensions:
• 30.6 x 22 x 66.5 mm (W/H/D)
• Hand warmer weight: 45 g
• Charging case dimensions:
• 30.6 x 22 x 66.5 mm (W/H/D)
• Weight of charging case: 45 g
Features:
Heating levels:
Chargingcase:
Dimensions / Weight:
• Switch with three heat settings
• Battery capacity: 3.6 V, 2000 mAh
(per hand warmer)
• Charging time: approx. 3 hours
• Flexible at heating element
• First stage:
- Heating temperature: 35-42 °C
- Usage time: approx. 10 hours
• Second stage:
- Heating temperature: 42-48 °C
- Useful life: approx. 7 hours
• Third stage:
- Heating temperature: 48-55 °C
- Useful life: approx. 4.5 hours
• Push-button for displaying
the battery status
• Adaptive charge detection
• Battery capacity: 3.85 V, 10,000 mAh
• Charging connection: USB Type-C
• Charging time: approx. 6.5 hours (at 5V / 2A)
• 1x Charging case
• 2x Hand warmer
• 1x USB-C connection cable
• 1x User manual
Old appliances must not be disposed of with household waste, but
must be returned free of charge to municipal collection centres or
retailers. Removable used batteries and rechargeable batteries must be
removed and disposed of separately before handing them in.
Batteries and rechargeable batteries must be collected separately and
can be returned free of charge to collection centres or retailers. Lithium
batteries must be discharged and the terminals taped to prevent short
circuits before handing them in.
