Sida 1/6

www.tenda.com.cn

TEG1105PD

5-Port Gigabit PD Switch With 4-Port PoE

TEG1105PD 5-Port Gigabit PD Switch With 4-Port PoE

TEG1105PD

5-Port Gigabit PD Switch With 4-Port PoE

Products Description

Key Feature

Ports 1 - 4 support power supply to low-power PDs compliant with IEEE 802.3af

The switch supports auto MDI/MDIX, simpliﬁng the network structure and maintenance.

Featuring low cost, high performance and plug & play, the PoE switch TEG1105PD is both a PSE and a PD,

designed for such surveillance networking scenarios as roads in parks/communities, medium to large

factories, and colleges. Small and delicate, it can be installed in an outdoor waterproof box easily. The

switch provides four 10/100/1000 Mbps PoE OUT ports (ports 1 to 4) compliant with IEEE 802.3af and

one 10/100/1000 Mbps PoE IN port (port 5) compliant with IEEE 802.3af/at. The maximum PoE output

power of the whole switch is 30 W. The switch can supply power and transmit data to low-power APs and

IP cameras through CAT5 cables, greatly reducing the cost of the network deployment. It is an ideal

choice for wired networking in monitoring scenarios of middle to long distance.

The switch supports the store-and-forward transfer mode and a 2 K MAC address table.

The switch supports 9K jumbo frame, improving the forwarding rate of large ﬁles.

Port 5 supports power supply by a PSE compliant with IEEE 802.3af/at

Five 10/100/1000 Mbps auto-negotiation ports

The non-blocking wire-speed forwarding function guarantees the smooth operation of

network applications.

Full-duplex ﬂow control and half-duplex back pressure control prevent frame loss caused

by port blocking.

The switch supports IP camera connection and guarantees the smoothness and

clearness of monitoring videos.

Product Features

Gbps data transmission

PoE Relay for long-distance network

Integrated PSE & PD

6kVlightningprotection

The transmission rate of 5 Gigabit ports can reach up to 2000

Mbps in full-duplex mode. Full wire-speed forwarding

functionality on all ports guarantees the smooth transmission of

the surveillance videos monitored by HD IP cameras.

The switch can be powered by an IEEE 802.3af/at compliant PSE

through port 5 with an Ethernet cable, and supply power to such

PDs as low-power APs and IP cameras through ports 1 to 4.

This switch provides short circuit protection for PSE and 6 kV

lightning protection for all ports, protecting the switch itself to

operate steadily from surge and lightning damages in

thunderstorms. 

As a relay, the switch can extend the data transmission distance

to 325 meters at most and offer long-distance PoE power supply

through multiple PoE ports.

Plug and play

With the plug and play functionality, the switch can be used

directly after it is connected to a PSE with an Ethernet cable,

reducing breakdowns as well as operation and maintenance cost.

TEG1105PD 5-Port Gigabit PD Switch With 4-Port PoE

Produktspecifikationer

Varumärke:	Tenda
Kategori:	brytare
Modell:	TEG1105PD
Bredd:	100 mm
Djup:	100 mm
Höjd:	26 mm
LED-indikatorer:	Link, PoE, Power
Certifiering:	CQC, FCC, CE, RoHS
Strömförsörjning ingår:	Ja
Paketbuffertminne:	1 MB
Produktens färg:	Brun
Strömförsörjning via Ethernet (PoE) stöd:	Ja
Temperatur vid drift:	0 - 45 ° C
Temperaturintervall (förvaring):	-40 - 70 ° C
Intervall för relativ operativ luftfuktighet:	10 - 90 %
Fuktighet (förvaring):	5 - 90 %
Material, hölje:	Metall
Kommunikationsstandarder:	IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x
Ingående ström:	0.6 A
Adresstabellstorlek:	2000 poster
Jumboramar:	9000
Jumbo Frames stöd:	Ja
Switch kapacitet:	10 Gbit/s
10G stöd:	Nej
Antal grundläggande RJ-45 Ethernet-portar:	5
Typ av grundläggande RJ-45 Ethernet-portar:	Gigabit Ethernet (10/100/1000)
Strömanslutning:	DC-in-uttag
Power over Ethernet (PoE)-portar kvantitet:	4
Koppar Ethernet-kablar teknik:	10BASE-T, 100BASE-T, 1000BASE-T
Likströmsdriftspänning:	50 - 57 V
Paketförmedlingshastighet (1 Gbps):	14880 pps
Stöd för automatisk inlärning av MAC-adresser:	Ja
Paketförmedlingshastighet (10 Mbps):	1488000 pps
Paketförmedlingshastighet (100 Mbps):	148800 pps
