TIME (s)

FINAL TEMPERATURE

020406080100

0

10%

20%

30%

40%

50%

60%

70%

80%

90%

100%

D003

LMT8xLPG

Thermistor

LMT84

OUT

GND

V

DD

C

BP

V

DD

(+1.5V to +5.5V)

Copyright © 2016, Texas Instruments Incorporated

Product

Folder

Order

Now

Technical

Documents

Tools &

Software

Support &

Community

AnIMPORTANTNOTICEattheendofthisdatasheetaddressesavailability,warranty,changes,useinsafety-criticalapplications,

intellectualpropertymattersandotherimportantdisclaimers.PRODUCTIONDATA.

LMT84-Q1

SNIS178–OCTOBER2017

LMT84-Q11.5-V,SC70,

AnalogTemperatureSensors

1

1Features

1

•LMT84-Q1isAEC-Q100QualifiedforAutomotive

Applications:

–DeviceTemperatureGrade0:–40°Cto

+150°C

–DeviceHBMESDClassificationLevel2

–DeviceCDMESDClassificationLevelC6

•VeryAccurate:±0.4°CTypical

•Low1.5-VOperation

•AverageSensorGainof-5.5mV/°C

•Low5.4-µAQuiescentCurrent

•WideTemperatureRange:–50°Cto150°C

•OutputisShort-CircuitProtected

•Push-PullOutputWith±50-µADriveCapability

•FootprintCompatibleWiththeIndustry-Standard

LM20/19andLM35TemperatureSensors

•Cost-EffectiveAlternativetoThermistors

2Applications

•Automotive

•InfotainmentandCluster

•PowertrainSystems

•SmokeandHeatDetectors

•Drones

•Appliances

(1)Forallavailablepackages,seetheorderableaddendum

addendumattheendofthedatasheet.

3Description

TheLMT84-Q1isaprecisionCMOStemperature

sensorwith±0.4°Ctypicalaccuracy(±2.7°C

maximum)andalinearanalogoutputvoltagethatis

inverselyproportionaltotemperature.The1.5-V

supplyvoltageoperation,5.4-μAquiescentcurrent,

and0.7-mspower-ontimeenableeffectivepower-

cyclingarchitecturestominimizepowerconsumption

forbattery-poweredapplicationssuchasdronesand

sensornodes.TheLMT84-Q1deviceisAEC-Q100

Grade0qualifiedandmaintains±2.7°Cmaximum

accuracyoverthefulloperatingtemperaturerange

withoutcalibration;thismakestheLMT84-Q1suitable

forautomotiveapplicationssuchasinfotainment,

cluster,andpowertrainsystems.Theaccuracyover

thewideoperatingrangeandotherfeaturesmakethe

LMT84-Q1anexcellentalternativetothermistors.

Fordeviceswithdifferentaveragesensorgainsand

comparableaccuracy,refertoComparable

AlternativeDevicesforalternativedevicesinthe

LMT8xfamily.

DeviceInformation

(1)

PARTNUMBERPACKAGEBODYSIZE(NOM)

LMT84-Q1SOT(5)2.00mmx1.25mm

ThermalTimeConstant

*FastthermalresponseNTC

OutputVoltagevsTemperature
