Charge

Pump

Vtune

CPout

RFoutAP

Sigma-Delta

Modulator

N Divider

OSCin

Douber

Post-R

Divider

Multiplier

Pre-R

Divider

ϕ

Vcc

RFoutAM

RFoutBP

Vcc

Channel

Divider

Loop Filter

Phase

Detector

Serial Interface

Control

SDI

SCK

CSB

MUXout

OSCinP

OSCinM

Input

signal

RFoutBM

MUX

MUX

SYSREF

Copyright © 2017,Texas Instruments Incorporated

Product

Folder

Order

Now

Technical

Documents

Tools &

Software

Support &

Community

AnIMPORTANTNOTICEattheendofthisdatasheetaddressesavailability,warranty,changes,useinsafety-criticalapplications,

intellectualpropertymattersandotherimportantdisclaimers.PRODUCTIONDATA.

LMX2594

SNAS696C–MARCH2017–REVISEDAPRIL2019

LMX259415-GHzWidebandPLLATINUM™RFSynthesizer

WithPhaseSynchronizationandJESD204BSupport

1

1Features

1

•10-MHzto15-GHzoutputfrequency

•–110dBc/Hzphasenoiseat100-kHzoffsetwith

15-GHzcarrier

•45-fsrmsjitterat7.5GHz(100Hzto100MHz)

•Programmableoutputpower

•PLLkeyspecifications

–Figureofmerit:–236dBc/Hz

–Normalized1/fnoise:–129dBc/Hz

–Highphasedetectorfrequency

–400-MHzintegermode

–300-MHzfractionalmode

–32-bitfractional-Ndivider

•Removeintegerboundaryspurswith

programmableinputmultiplier

•Synchronizationofoutputphaseacrossmultiple

devices

•SupportforSYSREFwith9-psresolution

programmabledelay

•Frequencyrampandchirpgenerationabilityfor

FMCWapplications

•<20-µsVCOcalibrationspeed

•3.3-Vsinglepowersupplyoperation

2Applications

•5Gandmm-Wavewirelessinfrastructure

•Testandmeasurementequipment

•Radar

•MIMO

•Phasedarrayantennasandbeamforming

•High-speeddataconverterclocking(supports

JESD204B)

3Description

TheLMX2594isahigh-performance,wideband

synthesizerthatcangenerateanyfrequencyfrom10

MHzto15GHzwithoutusinganinternaldoubler,

thuseliminatingtheneedforsub-harmonicfilters.The

high-performancePLLwithfigureofmeritof–236

dBc/Hzandhigh-phasedetectorfrequencycanattain

verylowin-bandnoiseandintegratedjitter.Thehigh-

speedN-dividerhasnopre-divider,thussignificantly

reducingtheamplitudeandnumberofspurs.Thereis

alsoaprogrammableinputmultipliertomitigate

integerboundaryspurs.

TheLMX2594allowsuserstosynchronizetheoutput

ofmultipledevicesandalsoenablesapplicationsthat

needdeterministicdelaybetweeninputandoutput.A

frequencyrampgeneratorcansynthesizeuptotwo

segmentsoframpinanautomaticrampgeneration

optionoramanualoptionformaximumflexibility.The

fastcalibrationalgorithmallowschangingfrequencies

fasterthan20µs.TheLMX2594addssupportfor

generatingorrepeatingSYSREF(compliantto

JESD204Bstandard)designedforlow-noiseclock

sourcesinhigh-speeddataconverters.Afinedelay

adjustment(9-psresolution)isprovidedinthis

configurationtoaccountfordelaydifferencesofboard

traces.

TheoutputdriverswithinLMX2594deliveroutput

powerashighas7dBmat15-GHzcarrierfrequency.

Thedevicerunsfromasingle3.3-Vsupplyandhas

integratedLDOsthateliminatetheneedforon-board

lownoiseLDOs.

DeviceInformation

(1)

PARTNUMBERPACKAGEBODYSIZE(NOM)

LMX2594VQFN(40)6.00mm×6.00mm

(1)Forallavailablepackages,seetheorderableaddendumat

theendofthedatasheet.

SimplifiedSchematic
