112*112mm

系 列

1200 黑色胶柱 x4

INTEL 螺丝 x4

1700 Standoffs x4

LGA115X/1700

背板 x1

散热器 x1

A

120mm风扇 x1

B

INTEL支架 x2

D

E

F

F1

H

I

G

J

KLM

C

140mm 风扇 x1

120mm风扇扣 x2140mm 风扇扣 x2

B1

INTEL LGA115X/1200

INTEL LGA115X/1200

INTEL LGA1700/1851

INTEL LGA1700/1851

PEERLESS ASSASSIN140 SE

PEERLESS ASSASSIN 140 SE

Series

AM4/AM5螺丝x4

导热膏 x1

1700蓝色胶柱 x4

Y型转接线 x1

AM4/AM5支架 x2

AM4 红色胶柱 x4

AMD AM4/AM5

Parts List

配件清单

AMD AM4/AM5

移除AMD原装塑胶支架，保留背板;放置AM4/AM5胶柱，使用AM4/AM5螺丝

将支架固定到主板。

Remove AMD plastic brackets, Keep the back plate, install AM4/AM5

metal brackets with AM4/AM5 screws and AM4/ AM5 plastic standoffs

涂好导热膏，然后用螺丝刀锁好主体,再用风扇线扣固定风扇

涂好导热膏，然后用螺丝刀锁好主体,再用风扇线扣固定风扇

涂好导热膏，然后用螺丝刀锁好主体,再用风扇线扣固定风扇

Adjust backplate mounting hole position, install backplate from back side of

motherboard, place LGA115X/1200 standoffs from front side, install brackets

with screws.

Adjust backplate mounting hole position, install backplate from back side of

motherboard, place LGA1700 standoffs from front side, install brackets with

screws.

！安装前请先去除铜底保护膜

1200 Standoffs x4

INTEL x4Screw

LGA115X/1700

Backplate x1

Heatsink x1

A

120mm FAN x1

B

INTEL Bracket x2

D

E

F

F1

H

I

G

J

KLM

C

140mm FAN x1

120mm FAN Clip x2140mmFAN Clip x2

B1

AM4/AM5

Screw x4

Thermal Greasa x1

FAN Y Cable x1

AM4/AM5

Bracket

x2

AM4/AM5

Standoffs x4

Apply thermal compound on CPU,install the heatsink with a screw driver, and

install fans on heatsink with fan clips.

Apply thermal compound on CPU,install the heatsink with a screw driver, and

install fans on heatsink with fan clips.

Apply thermal compound on CPU,install the heatsink with a screw driver, and

install fans on heatsink with fan clips.

E

E

L

L

滑块位置

C

L

L

L

L

G

G

Slider

position

C

M

D

H

M

D

H

将背板【C】推到115X位置放置在主板背面,然后正面放置胶柱【G】,扣具【D】,

再用螺丝【H】固定住扣具。

将背板【C】推到1700位置放置在主板背面,然后正面放置胶柱【M】,扣具【D】,

再用螺丝【H】固定住扣具。

D

H

D

H

将风扇4针PWM接头插入主板 CPU FAN插座

如果使用双风扇,请使用Y型转接线。

B1

B

F

F1

B1

B

F

F1

B1

B

F

F1

A

B1

B

F

F1

A

B1

B

F

F1

A

B1

B

F

F1

A

A

A

C

Slider

position

滑块位置

C
