INSTALLATION MANUAL

DIRECT SELECT UNIT N-8000DI

Thank you for purchasing TOA’s Direct Select Unit.

Please carefully follow the instructions in this manual to ensure long, trouble-free use of your equipment.

TABLE OF CONTENTS

1. SAFETY PRECAUTIONS ............................. 2

2. GENERAL DESCRIPTION ........................... 4

3. FEATURES ................................................... 4

4. NOMENCLATURE AND FUNCTIONS ......... 5

Front .............................................................. 5

Rear ............................................................... 5

5. INSTALLATION ............................................ 6

5.1. Equipment Rack Mounting ...................... 6

5.1.1. Set ting s pace ................................. 6

5.1.2. Caution when installing the unit .... 7

5.1.3. Mounting on the rack .................... 7

5.2. Desk-Top Installation .............................. 7

5.3. Wall Mounting ......................................... 8

6. WIRING ......................................................... 9

6.1. Type of Cable .......................................... 9

6.2. Removable terminal plug connection .... 9

6.3. Connection Diagram ............................ 10

7. ACCESSORIES .......................................... 12

8. OPTIONAL PRODUCT ............................... 12

1. SAFETY PRECAUTIONS

• Before installation or use, be sure to carefully read all the instructions in this section for correct and safe

operation.

• Be sure to follow all the precautionary instructions in this section, which contain important warnings and/or

cautions regarding safety.

• After reading, keep this manual handy for future reference.

Safety Symbol and Message Conventions

Safety symbols and messages described below are used in this manual to prevent bodily injury and property

damage which could result from mishandling. Before operating your product, read this manual first and

understand the safety symbols and messages so you are thoroughly aware of the potential safety hazards.

Indicates a potentially hazardous situation which,

if mishandled, could result in death or serious

personal injury.

WARNING

When Installing the Unit

• Do not expose the unit to rain or an environment

where it may be splashed by water or other liquids,

as doing so may result in re or electric shock.

• Use the unit only with the voltage specied on

the unit. Using a voltage higher than that which is

specied may result in re or electric shock.

• Do not cut, kink, otherwise damage nor modify

the power supply cord. In addition, avoid using the

power cord in close proximity to heaters, and never

place heavy objects -- including the unit itself -- on

the power cord, as doing so may result in re or

electric shock.

• Avoid installing or mounting the unit in unstable

locations, such as on a rickety table or a slanted

surface. Doing so may result in the unit falling

down and causing personal injury and/or property

damage.

• Install the unit only in a location that can structurally

support the weight of the unit and the mounting

bracket. Doing otherwise may result in the unit

falling down and causing personal injury and/or

property damage.

When the Unit is in Use

• Should the following irregularity be found during

use, immediately disconnect the power supply plug

from the AC outlet and contact your nearest TOA

dealer. Make no further attempt to operate the unit

in this condition as this may cause re or electric

shock.

· If you detect smoke or a strange smell coming

from the unit

· If water or any metallic object gets into the unit

· If the power supply cord is damaged (exposure of

the core, disconnection, etc.)

· If it is malfunctioning (no tone sounds.)

• To prevent a re or electric shock, never open nor

remove the unit case as there are high voltage

components inside the unit. Refer all servicing to

qualied service personnel.

• Do not insert nor drop metallic objects or ammable

materials in the ventilation slots of the unit's cover,

as this may result in re or electric shock.

• Do not touch a plug during thunder and lightning, as

this may result in electric shock.

Indicates a potentially hazardous situation which,

if mishandled, could result in moderate or minor

personal injury, and/or property damage.

CAUTION

When Installing the Unit

• Never plug in nor remove the power supply plug with

wet hands, as doing so may cause electric shock.

• When unplugging the power supply cord, be sure to

grasp the power supply plug; never pull on the cord

itself. Operating the unit with a damaged power

supply cord may cause a re or electric shock.

• Be sure to follow the instructions below when rack-

mounting the unit. Failure to do so may cause a re

or personal injury.

· Install the equipment rack on a stable, hard oor.

Fix it with anchor bolts or take other arrangements

to prevent it from falling down.

· When connecting the unit’s power cord to an AC

outlet, use the AC outlet with current capacity

allowable to the unit.

· The supplied rack-mounting screws can be used

for the TOA equipment rack only. Do not use them

for other racks.

When the Unit is in Use

• Do not place heavy objects on the unit as this may

cause it to fall or break which may result in personal

injury and/or property damage. In addition, the

object itself may fall off and cause injury and/or

damage.

• Do not stand or sit on, nor hang down from the unit

as this may cause it to fall down or drop, resulting in

personal injury and/or property damage.

Produktspecifikationer

Varumärke:	Toa
Kategori:	internt kommunikations system
Modell:	N-8000DI
Vikt:	2800 g
Bredd:	420 mm
Djup:	267 mm
Höjd:	44.3 mm
Wi-Fi:	Nej
Inbyggda högtalare:	Nej
Inbyggd mikrofon:	Nej
Material:	Stål
Antal RJ-45-portar:	1
Produktens färg:	Svart
Monteringssats:	Ja
Antal per förpackning:	1 styck
Datahastighet för Ethernet-LAN:	10, 100 Mbit/s
Strömförsörjning via Ethernet (PoE) stöd:	Nej
Temperatur vid drift:	0 - 40 ° C
Kabel inkluderad:	AC
Brand kompatibilitet:	TOA
