INSTRUCTION MANUAL

EAR-HOOK MICROPHONE -M5000E YP

Thank you for purchasing TOA’s Ear-hook Microphone.

Please carefully follow the instructions in this manual to ensure long, trouble-free use of your equipment.

This product is an expendable item. No warranty is provided for any trouble except incipient failure

1. GENERAL DESCRIPTION

The TOA YP-M5000E is ear-hook microphone of an

omnidirectional pick-up pattern, featuring a light weight

design.

2. NOMENCLATURE

3. HOW TO USE

・By bending the boom slightly, position the

microphone as close to the cheek as possible for the

best sound reproduction.

・Do not hold the microphone while bending, bend the

boom, making a smooth curve with your thumb to

best t the prole of the face.

・Make sure the join is connect properly to prevent

unwanted noise. Do not over tighten the join.

・The donut-shaped sweat stopper is to protect the

microphone's element from sweat and moisture.

・Position the sweat stopper as close to the

microphone's element as possible to provide

maximum protection.

4. SPECIFICATIONS

Type

Electret condenser type

Directivity

Omnidirectional

Frequency Response

20 – 20,000 Hz

Sensitivity

-67 dB 3 dB ±

(0 dB=1V/0.1Pa, 1kHz)

Maximum Input Level

115 dBSPL, 1kHz at 1%

Cord Length

1.3 m (4.27 ft)

Terminal

φ3.5 mm (0.14 ) ”

Stereo plug

Finish

Beige color

Weight

14 or 0. g 49 oz

(cable included)

Accessories

Windscreen 1 …

Cable clip …1

Microphone

Boom

Plug lock

φ3.5 mm

(0.14 ) ”

Microphone

133 00096- -07 -01

Sweat stopper

TOA C

ada

Corpoion

Produktspecifikationer

Varumärke:	Toa
Kategori:	mikrofon
Modell:	YP-M5000E
Inbyggda högtalare:	Nej
Gränssnitt:	3,5 mm (1/8 tum)
Modell:	Kragmikrofon
Maximal räckvidd:	1.3 m
Mikrofonfrekvens:	20 - 20000 hz
Maximal ljudtrycksnivå (1 kHz):	115 dB
Produktens färg:	Beige
Mikrofonvikt:	14 g
Anslutningsteknologi:	Kabel
Mikrofon känslighet (utnivå):	-67 dB
Mikrofon, riktning:	Rundtagande
