TRENDnet User’s Guide

Cover Page



© Copyright 2018 TRENDnet. All Rights Reserved.


TRENDnet User’s Guide
Table of Contents
i
Contents
Product Overview ........................................................................... 1
Package Contents .......................................................................................................... 1
Features ......................................................................................................................... 1
Product Hardware Features........................................................................................... 2
Expanding a Powerline Network ...................................................... 3
Basic Installation ............................................................................................................ 4
Installing your Powerline Adapters .................................................. 5
Powerline Security ......................................................................................................... 5
Before you Install ........................................................................................................... 5
Connect a Powerline adapter to your router ................................................................ 6
Add adapters to your network ...................................................................................... 6
Securing your Powerline Network ................................................... 7
Scramble your Network Name and Encryption ............................................................. 7
The Powerline Utility ....................................................................... 8
Powerline Utility System Requirements
 ........................................................................ 8
Software Installation
 ..................................................................................................... 8
Using the Utility
 ........................................................................................................... 12
Powerline Utility – Map View ........................................................ 13
Powerline Utility – Detailed View .................................................. 15
Powerline Utility – Device Setup ................................................... 16
Powerline Utility – Advanced ........................................................ 17
Powerline Utility – Options ........................................................... 18
Powerline Utility – About .............................................................. 19
Technical Specifications ................................................................ 20
Troubleshooting ........................................................................... 21
Appendix ...................................................................................... 22


TRENDnet User’s Guide

TPL-422E / TPL-422E2K

Product Overview

TPL-422E TPL-422E2K

Package Contents

TPL-422E package includes:

• TPL-422E

• Quick Installation Guide

• CD-ROM (Utility & User’s Guide)

• Network cable (1.5 m / 5 ft.)

TPL-422E2K package includes:

• 2 x TPL-422E

• Quick Installation Guide

• CD-ROM (Utility & User’s Guide)

• 2 x network cables (1.5 m / 5 ft.)

If any package contents are missing or damaged, please contact the retail store, online

retailer, or reseller/distributor from which the product was purchased.

Features

Powerline 1300 AV2 Adapter (TPL-422E)

TRENDnet’s Powerline 1300 AV2 Adapter, model TPL-422E, creates a high-speed

Powerline 1300 network using your home’s existing electrical system. Two adapters are

needed to start a network. TRENDnet adapters are protected with 128-bit AES

Encryption. Plug in the first adapter and network it to your existing router. Plug in other

adapters on the same electrical system and they auto-connect to the first adapter for

instant internet access.

Powerline 1300 AV2 Adapter Kit (TPL-422E2K)

TRENDnet’s Powerline 1300 AV2 Adapter Kit, model TPL-422E2K, comes with two

Powerline adapters to create a high-speed Powerline 1300 network using your home’s

existing electrical system. Two adapters are needed to start a network. TRENDnet

adapters are protected with 128-bit AES Encryption. Plug in the first adapter and

network it to your existing router. Plug in other adapters on the same electrical system

and they auto-connect to the first adapter for instant internet access.

Sync Button

Press the Sync button to change existing Powerline encryption keys

Powerline 1300

Powerline 1300 technology delivers fast and stable networking to seamlessly connect

devices and stream 4K video.

Gigabit Port

Gigabit port for computers, smart TVs, or other network enabled devices

Cross Compatibility

Cross compatible with Powerline 1200, 600, 500, and 200 adapters
