Sida 1/8
TRT-BA-CRH100-TC211208TTRT01-001-EN
CRH100
EN
OPERATING MANUAL
CRH MEASURING CHAMBER
2 EN
CRH measuring chamber CRH100
Table of contents
Notes regarding the operating manual.................................2
Safety .....................................................................................2
Information about the product..............................................3
Transport and storage...........................................................4
Operation ...............................................................................4
Disposal .................................................................................6
Test protocol..........................................................................7
Notes regarding the operating manual
Symbols
Warning
This signal word indicates a hazard with an average
risk level which, if not avoided, can result in serious
injury or death.
Caution
This signal word indicates a hazard with a low risk
level which, if not avoided, can result in minor or
moderate injury.
Note
This signal word indicates important information (e.g.
material damage), but does not indicate hazards.
Info
Information marked with this symbol helps you to carry
out your tasks quickly and safely.
Follow the manual
Information marked with this symbol indicates that the
operating manual must be observed.
You can download the current version of the operating manual
and the EU declaration of conformity via the following link:
CRH100
https://hub.trotec.com/?id=46087
Safety
Warning
Read all safety warnings and all instructions.
Failure to follow the warnings and instructions may
result in electric shock, fire and/or serious injury.
Keep these instructions for future reference and
ensure that the instructions are available when
using the product.
Children shall not play with the product. Cleaning and
user maintenance shall not be made by children
without supervision.
Intended use
Only use the product together with the multifunction measuring
meter T3000 and the sensor TS230SDI for measuring the
residual humidity in mineral screeds according to the KRL
measuring method. Observe and comply with the technical data
of the measuring chamber, the measuring device and the
sensor.
Foreseeable misuse
Any unauthorised modifications, alterations or structural
changes to the product are forbidden.
Any other use than the one described in the chapter "Intended
use" is regarded as reasonably foreseeable misuse.
Personnel qualifications
People who use this product must:
• have read and understood the operating manual of the
device with which you are using this accessory, especially
the Safety chapter.
Residual risks
Warning
Risk of suffocation!
Do not leave the packaging lying around. Children may
use it as a dangerous toy.
Warning
The product is not a toy and does not belong in the
hands of children.
Warning
Dangers can occur at the product when it is used by
untrained people in an unprofessional or improper way!
Observe the personnel qualifications!
Caution
Keep a sufficient distance from heat sources.
EN 3
CRH measuring chamber CRH100
Note
To prevent damages to the product, do not expose it to
extreme temperatures, extreme humidity or moisture.
Note
Do not use abrasive cleaners or solvents to clean the
product.
Information about the product
Product description
Using the CRH measuring chamber CRH100 together with the
multifunction measuring meterT3000 as well as the climate
sensor TS230SDI allows you to measure the residual humidity
in mineral screeds according to the CRH method and thus to
check the mineral screed's readiness for covering.
CRH measuring method
When using the CRH measurement method, the corresponding
relative humidity(CRH) of mineral screeds is determined with a
test method suitable for construction sites and crafts. The
corresponding relative humidity is the relative humidity in
percent[%RH] that is measured in the air space via a mortar
sample of the material in a state of equilibrium. The measuring
method was co-developed by the Technical Commission on
Construction Adhesives(TKB) and confirmed in extensive
interlaboratory tests with experts.
The great advantage of this measurement method is that
general, material-independent statements on the moisture
condition of mineral screeds can be made immediately after the
measurement. This increases the reliability when determining
the readiness for covering, especially for screeds mixed with
aggregates (screed accelerators). With conventional cement
screeds, not all of the water that is required for processing the
screed is consumed by the setting/hydration process. Due to
excess water, the drying time is delayed and thus also the
readiness of the screed for covering.
This excess water is permanently bound in crystalline form by
screed accelerators, resulting in a significantly faster readiness
for covering. However, these aggregates may well result in
significant deviations in a CMmeasurement, making the
CRHmeasurement method an advantage.
The screed's readiness for covering is achieved once it can
permanently accommodate a floor covering without any
damages or defects caused.
To measure the relative humidity according to the CRH method,
only measuring devices suitable for this purpose should be used
which have been tested and approved for the CRH measuring
method by the Technical Commission on Construction
Adhesives(TKB).
Product depiction
1
2
3
4
5
No. Operating element
1 Sealing plug
2 Cover
3 Test chamber
4 Measuring tube
5 Rubber seal
Technical data
Parameter Value
Dimensions (length x width x height) 110x 110x 90mm
Weight 138g
Diameter of measuring tube 12mm
Test material grain size ≤8mm
Weighed quantity of test material 150 ± 20g
Scope of delivery
• 1 × CRH100 CRH measuring chamber
