Sida 1/64
1
Owner’s Manual
4K/60 HDMI over Cat6 Extenders
and Splitters, Multi-Resolution
Function Support
Local Unit Models: B127P-002-H, B127P-004-H
Remote Unit Models: B127P-100-H, B127P-100-H-SR
1111 W. 35th Street, Chicago, IL 60609 USA • tripplite.com/support
Copyright © 2019 Tripp Lite. All rights reserved.
WARRANTY REGISTRATION
Register your product today and be automatically entered to win an
ISOBAR surge protector in our monthly drawing!
tripplite.com/warranty
Español 17 • Français 33 • Русский 49
2
Package Contents
Product Features
B127P-002-H
B127P-004-H
B127P-100-H
B127P-100-H-SR
Local (L) Unit or Remote (R) Unit L L R R
External Power Supplies (0 or 1) 1 1 0 0
Mounting Hardware Y Y Y N
All
• Support a maximum video resolution of 4K (3840 x 2160) @
60 Hz with 4:4:4 Chroma Subsampling
• Support up to 7.1-channel surround sound audio
• HDMI 2.0, HDCP 2.2 and HDR compatible
• Plug and play—no software or drivers required
3
Product Features
B127P-002-H
• 2-Port HDMI over Cat6 Extender/Splitter Local Transmitter Unit
• Splits an HDMI signal into two
• Works in tandem with Tripp Lite’s B127P-100-H and B127P-100-H-SR
receiver units to extend an HDMI signal
• Power over Cable (PoC) function to transfer power to remote receivers
• Supports 4K (3840 x 2160) @ 60 Hz and 1080 @ 60 Hz signals
• Multi-resolution function allows displays with varying resolutions to co-
exist in a single application without downgrading signal quality to the
lowest resolution
• Includes mounting hardware that allows unit to be wall-mounted, rack-
mounted or pole-mounted
B127P-004-H
• 4-Port HDMI over Cat6 Extender/Splitter Local Transmitter Unit
• Splits an HDMI signal into four
• Works in tandem with Tripp Lite’s B127P-100-H and B127P-100-H-SR
receiver units to extend an HDMI signal
• Power over Cable (PoC) function to transfer power to remote receivers
• Supports 4K (3840 x 2160) @ 60 Hz and 1080 @ 60 Hz signals
• Multi-resolution function allows displays with varying resolutions to co-
exist in a single application without downgrading signal quality to the
lowest resolution
• Includes an additional HDMI port, which can be used to connect a
local monitor or to daisy-chain additional B127P-004-H units (up to
three units can be daisy-chained together)
• Includes mounting hardware that allows unit to be wall-mounted, rack-
mounted or pole-mounted
