Operating instructions

DFSE 5/6

Range hood

Thank you for choosing to buy one of our products. Your appliance is made to

high standards and is easy to use. Nevertheless, please take the time to read

these operating instructions in order to familiarise yourself with the appliance

and get the best use out of it.

Please follow the safety precautions.

Modifications

Text, diagrams and data correspond to the technical standard of the appliance

at the time these operating instructions went to press. The right to make tech-

nical modifications for the purpose of the further development of the appliance

is reserved.

Validity

The product family (model number) corresponds to the first alphanumerics on

the identification plate. These operating instructions apply to:

Type

TypeType Product family

Product family

Product familyProduct family Size system

Size system

Size systemSize system

DFSE5 61028 55

DFSE6 61029 60

Variations depending on the model are noted in the text.

Inhaltsverzeichnis

2

1 Safety precautions 5

1.1 Symbols used ........................................................................................................ 5

1.2 General safety precautions ................................................................................. 6

1.3 Before using for the first time ............................................................................. 7

1.4 Correct use............................................................................................................. 7

1.5 Children in the home............................................................................................ 7

1.6 Note on use ........................................................................................................... 8

2 Disposal 10

3 Appliance description 11

3.1 Appliance description ........................................................................................11

3.2 Extraction mode ..................................................................................................11

3.3 Recirculation mode.............................................................................................11

3.4 Features ................................................................................................................11

3.5 Construction.........................................................................................................12

3.6 Operating elements ............................................................................................13

4 Operating the appliance 14

4.1 Using for the first time........................................................................................14

4.2 Switching the appliance on...............................................................................14

4.3 Extractor fan.........................................................................................................15

4.4 Intensive level ......................................................................................................15

4.5 After-running time................................................................................................15

4.6 Illumination ...........................................................................................................16

4.7 Switching the appliance off ...............................................................................16

4.8 Saturation indicator.............................................................................................16

5 Care and maintenance 17

5.1 Cleaning the housing .........................................................................................17

5.2 Metal grease filters .............................................................................................17

5.3 Long-life activated charcoal filter .....................................................................19

5.4 Standard activated charcoal filter ....................................................................21

5.5 Replacing the LED light bulbs..........................................................................21

6 Trouble-shooting 22

6.1 What to do if…......................................................................................................22

7 Accessories and spare parts 23

Produktspecifikationer

Varumärke:	V-Zug
Kategori:	ventilationskåpa
Modell:	DFSE6c
Inbyggd display:	Ja
Vikt:	12500 g
Bredd:	598 mm
Djup:	302 mm
Höjd:	396 mm
Årlig energiförbrukning:	43 kWh
Sladdlängd:	1.5 m
Motoreffekt:	200 W
Belysningsstyrka:	145 lx
Antal motorer:	1
Ljudnivå (låg hastighet):	46 dB
Antal lampor:	2 lampor
Tvättbart filter:	Ja
Antal filter:	2 styck
Antal hastigheter:	3
Automatisk avstängning:	Ja
Modell:	Halvinbyggd (utdragbar)
Produktens färg:	Krom
Kontrolltyp:	Knappar
Löstagbart filter:	Ja
Tryck (Pa):	414
Fettfilter typ:	Fleece
AC-inspänning:	220-240 V
Lamptyp:	LED
Växelström Frekvens:	50 - 60 hz
Ström:	10 A
Ljudnivå Lc IEC:	63 dB
Installationsfack, bredd:	600 mm
Installationsfack, djup:	305 mm
Lampor:	5 W
Ansluten effekt:	205 W
Typ av fläkt:	Frånluft/recirkulerande
Maximal flödeskapacitet:	625 m³/h
Intensiv hastighet:	Ja
Evakueringsanslutning diameter:	150 mm
Diskmaskin filter:	Ja
Maximal återcirkulerande ström:	490 m³/h
Energiklass, flödesdynamik:	A
Energiklass, belysning:	A
Energiklass, fettfiltrering:	C
Exhaust plats:	Övre
Filterrengöring indikator:	Ja
Ljudnivå (hög hastighet):	63 dB
Minsta avstånd från elektrisk spis:	430 mm
Minsta avstånd från gashäll:	750 mm
Bullernivå (intensiv hastighet):	67 dB
Kontrollventil:	Ja
