V-Zug DKS6iw Bruksanvisning

V-Zug ventilationskåpa DKS6iw

Läs gratis den bruksanvisning för V-Zug DKS6iw (20 sidor) i kategorin ventilationskåpa. Guiden har ansetts hjälpsam av 4 personer och har ett genomsnittsbetyg på 4.6 stjärnor baserat på 2.5 recensioner. Har du en fråga om V-Zug DKS6iw eller vill du ställa frågor till andra användare av produkten? Ställ en fråga

Ladda ner PDF

Sida 1/20

Operating instructions

DKS5i/DKS6i

Range hood

Thank you for choosing to buy one of our products. Your appliance is made to

high standards and is easy to use. Nevertheless, please take the time to read

these operating instructions in order to familiarise yourself with the appliance

and get the best use out of it.

Please follow the safety precautions.

Modifications

Text, diagrams and data correspond to the technical standard of the appliance

at the time these operating instructions went to press. The right to make tech-

nical modifications for the purpose of the further development of the appliance

is reserved.

Validity

The product family (model number) corresponds to the first alphanumerics on

the identification plate. These operating instructions apply to:

Type

TypeType

Product family

Size system

Size systemSize system

DKS5i 61005 55

DKS6i 61006 60

Variations depending on the model are noted in the text.

Contents

1 Safety precautions 4

1.1 Symbols used ........................................................................................................ 4

1.2 General safety precautions ................................................................................. 5

1.3 Before using for the first time ............................................................................. 5

1.4 Correct use............................................................................................................. 6

1.5 Children in the home............................................................................................ 6

1.6 Note on use ........................................................................................................... 7

2 Disposal 9

3 Your appliance 10

3.1 Appliance description ........................................................................................10

3.2 Extraction model .................................................................................................10

3.3 Recirculation model............................................................................................10

3.4 Equipment ............................................................................................................10

3.5 Construction.........................................................................................................11

3.6 Operating elements ............................................................................................11

4 Operating the appliance 12

4.1 Switching the extractor fan on..........................................................................12

4.2 Setting the power level ......................................................................................12

4.3 Switching the illumination on/off ......................................................................12

4.4 Switching the extractor fan off ..........................................................................12

5 Care and maintenance 13

5.1 Cleaning the housing .........................................................................................13

5.2 Cleaning the grease filter and inside surfaces..............................................13

5.3 Removing the grease filter ................................................................................14

5.4 Installing the grease filter ..................................................................................14

5.5 Replacing the light bulb.....................................................................................14

6 Trouble-shooting 15

6.1 What to do if ... ....................................................................................................15

7 Accessories and spare parts 16

8 Technical data 17

9 Index 18

10 Service & Support 19

Produktspecifikationer

Varumärke:	V-Zug
Kategori:	ventilationskåpa
Modell:	DKS6iw
Inbyggd display:	Nej
Vikt:	12000 g
Bredd:	597 mm
Djup:	302 mm
Höjd:	242 mm
Årlig energiförbrukning:	113 kWh
Sladdlängd:	1.5 m
Motoreffekt:	150 W
Belysningsstyrka:	95 lx
Antal motorer:	1
Ljudnivå (låg hastighet):	49 dB
Antal lampor:	2 lampor
Antal filter:	1 styck
Antal hastigheter:	2
Modell:	Inbyggd
Produktens färg:	Vit
Kontrolltyp:	Scrollbar
Tryck (Pa):	177
Fettfilter typ:	Fleece
AC-inspänning:	230 V
Lamptyp:	halogen
Växelström Frekvens:	50 hz
Ström:	10 A
Ljudnivå Lc IEC:	65 dB
Installationsfack, bredd:	597 mm
Installationsfack, djup:	302 mm
Installationsfack, höjd:	242 mm
Lampor:	56 W
Ansluten effekt:	230 W
Typ av fläkt:	Frånluft/recirkulerande
Maximal flödeskapacitet:	324 m³/h
Intensiv hastighet:	Nej
Evakueringsanslutning diameter:	120 mm
Maximal återcirkulerande ström:	326 m³/h
Energiklass, flödesdynamik:	F
Energiklass, belysning:	G
Energiklass, fettfiltrering:	C
Exhaust plats:	Övre
Ljudnivå (hög hastighet):	65 dB
Minsta avstånd från elektrisk spis:	600 mm
Minsta avstånd från gashäll:	750 mm
Kontrollventil:	Ja
