Sida 1/99
Complete Manual for
ConferenceSHOT AV
Enterprise-Class Conferencing System
Document 411-0001-30 Rev E
October 2019
ii
Contents
Overview 1
What's in this Guide 3
Features 3
Unpacking the Conferencing System 4
Conferencing Accessories 4
ConferenceSHOT AV Bundles 5
A Quick Look at the System 9
Front of the Camera 9
Back of the Camera 10
Back of the Speaker 10
Installation 11
Don’t Void Your Warranty! 11
Before You Install the Camera 11
Installing the Wall Mount 12
About Ceiling-Mounted Cameras 12
Cabling Notes 13
About Echo Cancellation 13
Basic Connections 14
Installing the Camera without the Speaker 16
Installing the Camera and Speaker 17
Powering Up the System 18
Status Indicator Light 18
Using the Remote Control 19
Quick Reference 19
IR Remote Details 20
Storing a Preset Using the Remote 20
Clearing a Preset Using the Remote 20
Using the Web Interface 21
Browser Support 21
Getting the Camera's IP Address 21
User Access 23
Administrative Access 23
Compact Menu View 24
System Administration 25
Configuring the Camera for Your Network 25
For Non-DHCP Environments: Configuring the Device with a Static IP Address for Initial
Installation 26
Optional For DHCP Environments: Changing from a DHCP Address to a Static IP Address 28
Changing the Camera's Hostname 28
Specifying Time Zone and NTP Server 29
Setting Passwords and Access 30
Configuring Other Security Settings 30
Enabling or Requiring HTTPS 31
Disabling Telnet Access 31
Adding Room Information to the Screen 32
Saving (Exporting) or Restoring (Importing)a Configuration 32
Installing a Firmware Update 34
Installing a Firmware Update for a Connected Microphone 35
Rebooting the Camera 36
Contacting Vaddio Technical Support 37
Viewing Diagnostic Logs 37
Configuring Camera Behavior 38
Setting the Home Position and Other Preset Shots 38
Renaming Presets 40
Adjusting the Color and Image Quality Settings 40
Lighting and Image Quality Quick Reference 41
Color Adjustment Quick Reference 41
Adjusting the Focus 42
Speed Adjustments 42
Setting the Speeds for Manual Movements 43
Setting the Speeds of Movements to Presets 43
Setting the Direction for Camera Movements 44
Configuring Streaming Behavior 45
Enabling or Disabling Streaming 45
Viewing a Stream 46
Configuring USB Streaming 46
Setting up IPStreaming in Easy Mode 47
Setting up IPStreaming in Custom Mode 48
RTSPStreaming Protocol and URL 49
Configuring RTMP Streaming 50
Changing MTU 51
Managing Audio 52
Muting All Audio Inputs Together 52
Controlling Volume and Muting Per Input or Output 52
Fine-Tuning Microphone Performance 53
Fine-Tuning Speaker Performance 54
Setting up Macros and Triggers 55
Writing and Editing Macros 56
Testing Macros 57
Assigning Macros to Triggers 58
Testing Triggers 59
iii
Complete Manual for the ConferenceSHOT AV Enterprise-Class Conferencing System
