Camera and Electronic Products for Integrators

pricing are subject to change without notice. Vaddio, DomeVIEW, EZCamera, Quick-Connect, WallVIEW, CeilingVIEW, EZCable and PowerRite are

trademarks of Vaddio, Inc. All other trademarks are property of their respective owners. Document 341-443 Rev C1.

Installation and User Guide

™

Integrated Flush Mount Dome Systems

and Flush Mount Dome Enclosures for

Sony® and Canon® PTZ Cameras

OVERVIEW:

The Vaddio™ DomeVIEW Flush Mount Domes are integrated

camera mounting systems that are attractive and easy to install.

Designed for indoor security applications, the 7.3” (18.54cm) flush

mount dome enclosure is outfitted with the internal brackets to

support the option of using the Sony EVI-D70 or Canon VC-C50iR

robotic PTZ cameras.

The DomeVIEW Flush Mount Dome Package is sold complete with the Camera and features the Vaddio

EZCamera Cabling System for both the Sony EVI-D70 and the Canon VC-C50iR. Both systems provide for

fast and efficient installations using Cat-5e cabling for video, power and control. The enclosures are also

sold without the camera to accommodate an existing camera to be used with the Flush Mount Dome

enclosure without the EZ Camera cabling system.

The Domes are formed from optical grade polycarbonate (Figure 1) and are available in clear (standard) or

smoked tint (optional). The DomeVIEW Flush Mount Domes are excellent values that are high quality,

attractive and durable solutions for indoor security applications.

This Manual covers the following Vaddio DomeVIEW Flush Mount Dome Systems:

 DomeVIEW 50iR Flush Mount Dome 999-9000-050 with Canon VC-C50iR, EZCamera Cabling System

and Internal Mounting Bracket

 DomeVIEW 70 Flush Mount Dome 999-9000-070 with Sony EVI-D70, EZCamera Cabling System and

Internal Mounting Bracket

This Manual covers the following Flush Mount Dome Enclosures:

 998-9000-050 Flush Mount Dome with Internal Mounting Bracket for VC-C50iR (Camera Not Included)

 998-9000-070 Flush Mount Dome with Internal Mounting Bracket for EVI-D70 (Camera Not Included)

Note: When mounting the Flush Mount Dome in Acoustic ceiling tile, the 997-9000-000 Tile Support Brace is highly

recommended in order to transfer the weight of the camera and enclosure into the ceiling grid. The Tile Support Brace is not

required in a dry wall ceiling installation. The Tile Support Brace is sold separately.

INTENDED USE:

Before operating the DomeVIEW system, please read the entire manual thoroughly. The DomeVIEW Flush Mount

systems were designed, built and tested for use indoors and with the provided power supply. The use of a power supply

other than the one provided or outdoor operation has not been tested and could damage the electronics and/or create a

potentially unsafe operating condition.

SAVE THESE INSTRUCTIONS:

The information contained in this manual will help you install and operate your Vaddio DomeVIEW. If these instructions

are misplaced, Vaddio keeps copies of Specifications, Installation and User Guides and most pertinent product drawings

for the Vaddio product line on the website. These documents can be downloaded from www.vaddio.com free of charge.

Figure 1:

Flush Mount Dome Enclosure shown with

Smoke Tinted Dome (Clear is Standard,

Smoked Tinted is Optional)

Vaddio DomeVIEW Flush Mount Dome Installation and User Guide - Document 341-443 Rev C1

Page 2 of 12

IMPORTANT SAFEGUARDS:

Read and understand all instructions before using. Do not operate the system if it has been dropped or damaged. In this

case, a Vaddio technician must examine the product before operating. To reduce the risk of electric shock, do not

immerse in water or other liquids and avoid extremely humid conditions.

UNPACKAGING – SYSTEM COMPONENT LISTS

Carefully remove all parts from the packaging. Unpack and identify the following parts for each product:

999-9000-050 DomeVIEW 50iR Flush Mount Dome System includes:

QTY Description

1 Canon VC-C50iR PTZ camera

1 Canon IR remote control

3 4.5” x .375 (114.3mm x 9.525mm) Hex shaped stand-offs

1 6” x 6” (15.24cm x 15.24cm) Camera mounting stage

3 8-32 x .5” Flat head screws (flush mount)

2 8-32 x .5” pan head screws

2 Lock washers for pan head screws

1 Plenum rated steel back can

1 White twist and lock trim ring

1 Clear dome bubble mounted to trim ring

1 Conduit connector and nut

1 Safety chain attachment plate

1 50 EZCamera Shoe (998-4411-001)

1 Quick-Connect (998-1105-001)

1 PowerRite Power Supply (451-2750-018)

999-9000-070 DomeVIEW 70 Flush Mount Dome System includes:

QTY Description

1 Sony EVI-D70C/W PTZ camera (platinum white)

1 Vaddio IR Remote Commander (for Sony cameras)

3 2.75” x .375 (69.85mm x 9.525mm) Hex shaped stand-offs

1 6” x 6” (15.24cm x 15.24cm) Camera mounting stage

3 8-32 x .5” Flat head screws (flush mount)

1 6” x 6” (15.24cm x 15.24cm) Camera mounting plate

1 ¼”-20 x ½” Mounting screw (to attach camera to mounting plate)

4 8-32 x .5” pan head screws

2 #8 Lock washers for pan head screws

1 Plenum rated steel back can

1 White twist and lock trim ring

1 Clear dome bubble mounted to trim ring

1 Conduit connector and nut

1 Safety chain attachment plate

1 70 EZCamera Shoe (998-2211-004)

1 Quick-Connect (998-1105-001)

1 PowerRite Power Supply (998-2750-018)

Use only the power supply (or power supplies) provided with the DomeVIEW

systems. Use of any unauthorized power supply will void any and all warranties.

Do not use “pass-thru” RJ-45 connectors during installation. Use only

standard RJ-45 connectors and test all terminated cables.

Vaddio DomeVIEW Flush Mount Dome Installation and User Guide - Document 341-443 Rev C1

Page 3 of 12

Flush Mount Dome Enclosures Only (Cameras Not Included)

The Flush Mount Dome Enclosures are for use with existing or standard Sony EVI-D70 and Canon VC-

C50iR. The Dome enclosures can also be used with the Vaddio Standard EZCamera Cable system for the

EVI-D70 or the VC-C50i analog PTZ cameras. The dome enclosures without cameras are listed below:

998-9000-050 Flush Mount Dome Enclosure includes:

QTY Description

1 Plenum rated steel back can

1 White twist and lock trim ring

1 Clear dome bubble mounted to trim ring

1 Conduit connector and nut

1 Safety chain attachment plate

3 4.5” x .375 (114.3mm x 9.525mm) Hex shaped stand-offs

1 6” x 6” (15.24cm x 15.24cm) Camera mounting stage

3 8-32 x .5” Flat head screws (flush mount)

2 8-32 x .5” pan head screws

2 Lock washers for pan head screws

998-9000-070 Flush Mount Dome Enclosure includes:

QTY Description

1 Plenum rated steel back can

1 White twist and lock trim ring

1 Clear dome bubble mounted to trim ring

1 Conduit connector and nut

1 Safety chain attachment plate

3 2.75” x .375 (69.85mm x 9.525mm) Hex shaped stand-offs

1 6” x 6” (15.24cm x 15.24cm) Camera mounting stage

3 8-32 x .5” Flat head screws (flush mount)

1 6” x 6” (15.24cm x 15.24cm) Camera mounting plate (attaches to camera)

1 ¼”-20 x ½” Mounting screw (to attach camera to mounting plate)

4 8-32 x .5” pan head screws

4 #8 Lock washers for pan head screws

INSTALLATION INSTRUCTIONS for:

DomeVIEW 50iR Flush Mount Dome System (999-9000-050)

DomeVIEW 70 Flush Mount Dome System (999-9000-070)

Flush Mount Dome Enclosures for:

CanonVC-C50iR (998-9000-050) and Sony EVI-D70 (998-9000-070)

Before Starting the Installation

Before starting the installation of the Flush Mount Dome system, check above the ceiling where you plan to

install the camera to make sure the area is clear and that there is adequate room for the Camera Enclosure.

Make sure that the cabling required to operate the camera is brought to the point where the camera is to be

installed. For cabling requirements, see the Cabling Requirements section. All above ceiling work must

conform to local building codes and should be performed by qualified personnel.

Produktspecifikationer

Varumärke:	Vaddio
Kategori:	övervakningskamera
Modell:	DomeView
Vikt:	950 g
Bredd:	132 mm
Djup:	144 mm
Höjd:	144 mm
Wi-Fi:	Nej
Diameter:	18.54 mm
Antal kameror:	1
Zoomkapacitet:	Ja
Hörlursutgångar:	1
Optisk sensorstorlek:	1/4 "
Bildsensortyp:	CCD
Digital zoom:	12 x
Optisk zoom:	18 x
Gränssnitt:	RS-232C
RS-232 port:	1
Modell:	Hölje och fäste
Kompatibilitet:	Sony EVI-D70 PTZ, Canon VC-C50iR
Antal TV-linjer:	470
RS-422-portar:	1
Lutningsvinkel:	-30 - 90 °
Maxvikt:	- kg
Produktens färg:	Black, White
bruksanvisning:	Ja
Monteringssats:	Ja
Analogt signalformatsystem:	NTSC
Slutartid:	1/1 - 1/10000 s
Formfaktor:	Kub
Kompositvideo ut:	1
Strömförsörjning via Ethernet (PoE) stöd:	Nej
Temperatur vid drift:	0 - 40 ° C
Temperaturintervall (förvaring):	-20 - 60 ° C
Material, hölje:	Polykarbonat
Kabel inkluderad:	AC
Placeringar som kan användas:	inomhus
Anslutningsteknologi:	Kabel
Monteringssätt:	Tak/Skrivbord
Minimibelysning:	1 lx
Brännviddsintervall:	4.1 - 73.8 mm
Nätverksansluten (Ethernet):	Nej
Likströmsingång:	Ja
DC-utgång volt:	12
AC-adapter inkluderad:	Ja
Panoreringshastighet:	100 °/sek
PTZ-styrning:	Ja
Justering av fokus:	1.4 - 3.0
DC utgående ström:	1 A
Objektivets betraktningsvinkel, horisontell:	48 °
Signal/brusförhållande (SNR):	50 dB
Panoreringsvinkel:	-170 - 170 °
Lutningshastighet:	90 °/sek
