CAUTION: To reduce the risk of electric shock,

Do not remove cover.

No user serviceable parts inside.

Refer servicing to qualied service personnel.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

This symbol indicates that dangerous

voltage constituting a risk of electric

shock is present within this unit.

This symbol indicates that there are

important operating and maintenance

instructions in the literature accompanying

this unit.

ISSUE 1

VIP-AL IP /Outdoor Stealth Horn 9831Indoor

INTRODUCTION

The VIP-9831AL IP Stealth Horn is a

self-contained paging system which enables voice

paging hundreds of feet from an Ethernet connection.

The VIP-9831AL consists of a horn and

Network/Aud Interface allowing standalone io

capability when used with a SIP enabled telephone

system or can be accessed from a variety of Valcom

managed VoIP products.

SPECIFICATIONS

Access Methods

SIP telephone system

PBX, FXO Port w/VIP-811A

POTS telephone set w/VIP-A 811

PBX, FXS Port w/VIP-821A

Valcom M Cast Page Group

Features

-network connection RJ45

Network activity LEDs

Power over Ethernet (PoE) 802.3af compatible

Dimensions/Weight

Horn Enclosure:

9.3 "H x 15.0 "W x 5.0 "D

(23.6 cm x 38.1 cm x 12.7 cm)

Wei ght: 5.5 lbs (2.05 kg)

Network Interface

 1.62” H x 5.63” W x 3.45” D

(4.11 cm) x (14.30 cm) x (8.76 cm)

 W (20.87 cm) with brackets–8.22”

Weight: 2.10 lbs. (0.95 kg)

Environment

Network Interface:

Temperature: +32 to +104°F (0 to +40°C)

Humity: 0 to 85% non-precipitating di

Indoor installation only

Horn Enclosure:

Temperature: -4 to +131°F (-20 to +55°C)

Humidity: 0 to 95% non-condensing

Indoor/Outdoor installation

Power

Via 802.3af PoEthernet Switch: Class 3 E

Precautionary Designations

INSTALLATION

FCC Information

This equipment has been tested and found to

comply with the limits for a Class A digital device,

pursuant to Part 15 of the FCC Rules. These

lits are designed to provide reasonable im

protection against harmful interference when the

equipment is operated in a commercial

environment. This equipment generates uses

and can radiate radio frequency energy and if not

installed and used in accordance wh the it

instruction manual, may cause harmful

interference to radio communications. Operation

of this equipment in a residential area may cause

harmful interference in which case the user will

be required to correct the interference at his own

expense.
