VR-260 Video Ring Light LED Bilight,
VR-440 Video Ring Light LED Bilight
LED video light
User manual
Musikhaus Thomann
Thomann GmbH
Hans-Thomann-Straße 1
96138 Burgebrach
Germany
Telephone: +49 (0) 9546 9223-0
E-mail: info@thomann.de
Internet: www.thomann.de
16.03.2021, ID: 495350, 498926 (V2)
Table of contents
1 General information 5.................................................................................................................................
1.1 Further information........................................................................................................................... 6
1.2 Symbols and signal words............................................................................................................... 7
2 Safety instructions 9.....................................................................................................................................
3 Features 13.......................................................................................................................................................
4 Installation 15..................................................................................................................................................
4.1 Dealing with lithium batteries..................................................................................................... 17
5 Connections and controls 19...................................................................................................................
6 Technical 22specications.......................................................................................................................
7 Cleaning 25.......................................................................................................................................................
8 Protecting the environment 26..............................................................................................................
Table of contents
VR-260 Video Ring Light LED Bilight,VR-440 Video Ring Light LED Bilight 3
LED video light
1 General information
This user manual contains important information on the safe operation of the device. Read and
follow all safety notes and all instructions. Save this manual for future reference. Make sure
that it is available to all persons using this device. If you sell the device to another user, be sure
that they also receive this manual.
Our products and user manuals are subject to a process of continuous development. We there‐
fore reserve the right to make changes without notice. Please refer to the latest version of the
user manual which is ready for download under .www.thomann.de
General information
VR-260 Video Ring Light LED Bilight,VR-440 Video Ring Light LED Bilight 5
LED video light
1.1 Further information
On our website ( you will lots of further information and details on thewww.thomann.de) nd
following points:
Download This manual is also available as PDF for you to download.le
Keyword search Use the search function in the electronic version to the topics ofnd
interest for you quickly.
Online guides Our online guides provide detailed information on technical basics
and terms.
Personal consultation For personal consultation please contact our technical hotline.
Service If you have any problems with the device the customer service will
gladly assist you.
General information
6VR-260 Video Ring Light LED Bilight,VR-440 Video Ring Light LED Bilight
LED video light
1.2 Symbols and signal words
In this section you will an overview of the meaning of symbols and signal words that arend
used in this manual.
Signal word Meaning
DANGER! This combination of symbol and signal word indicates an
immediate dangerous situation that will result in death or
serious injury if it is not avoided.
WARNING! This combination of symbol and signal word indicates a pos‐
sible dangerous situation that can result in death or serious
injury if it is not avoided.
NOTICE! This combination of symbol and signal word indicates a pos‐
sible dangerous situation that can result in material and
environmental damage if it is not avoided.
General information
VR-260 Video Ring Light LED Bilight,VR-440 Video Ring Light LED Bilight 7
LED video light
Warning signs Type of danger
Warning – dangerous optical radiation.
Warning – suspended load.
Warning – danger zone.
General information
8VR-260 Video Ring Light LED Bilight,VR-440 Video Ring Light LED Bilight
LED video light
2 Safety instructions
This device is intended for use as an electronic lighting by means of LED technology. Theeect
device is designed for professional use only and is not suitable for use in households. Use the
device only as described in this user manual. Any other use or use under other operating con‐
ditions is considered to be improper and may result in personal injury or property damage. No
liability will be assumed for damages resulting from improper use.
This device may be used only by persons with physical, sensorial, and intellectualsucient
abilities and having corresponding knowledge and experience. Other persons may use this
device only if they are supervised or instructed by a person who is responsible for their safety.
Extend the operating life of the device by regular breaks and by avoiding frequent
switching on and The device is not suitable for continuous operation.o.
Intended use
Safety instructions
VR-260 Video Ring Light LED Bilight,VR-440 Video Ring Light LED Bilight 9
LED video light
Safety
DANGER!
Danger for children
Ensure that plastic bags, packaging, etc. are disposed of properly and are not within reach of babies and young children. Choking
hazard! Ensure that children do not detach any small parts (e.g. knobs or the like) from the unit. They could swallow the pieces and
choke! Never let children unattended use electrical devices.
WARNING!
Eye damage caused by high light intensity
Never look directly into the light source.
WARNING!
Incorrect handling of lithium batteries can result in injury
In the event of a short circuit, overheating or mechanical damage, lithium batteries can cause severe injuries. Follow the advice on
the correct handling of lithium batteries in the present section.
Safety instructions
10 VR-260 Video Ring Light LED Bilight,VR-440 Video Ring Light LED Bilight
LED video light
NOTICE!
Operating conditions
This device has been designed for indoor use only. To prevent damage, never expose the device to any liquid or moisture. Avoid
direct sunlight, heavy dirt, and strong vibrations. Only operate the device within the ambient conditions in the chapterspecied
‘Technical of this user manual. Avoid heavy temperature and do not switch the device on immediatelyspecications’ uctuations
after it was exposed to temperature (for example after transport at low outside temperatures). Dust and dirt inside canuctuations
damage the unit. When operated in harmful ambient conditions (dust, smoke, nicotine, fog, etc.), the unit should be maintained by
qualied service personnel at regular intervals to prevent overheating and other malfunction.
NOTICE!
Power supply
Before connecting the device, ensure that the input voltage (AC outlet) matches the voltage rating of the device and that the AC
outlet is protected by a residual current circuit breaker. Failure to do so could result in damage to the device and possibly injure the
user. Unplug the device before electrical storms occur and when it is unused for long periods of time to reduce the risk of electric
shock or re.
NOTICE!
Possible damage to lithium-ion batteries through incorrect storage
By deep discharge, lithium-ion batteries can be permanently damaged or lose some of their capacity. Before long breaks, charge the
batteries to around 50 % of their capacity and then switch the device. Store the device at room temperature or cooler in an envi‐o
ronment as dry as possible. If the batteries are stored for a longer period, recharge them to 50 % every three months. Fully charge
the batteries only shortly before use at room temperature.
Safety instructions
VR-260 Video Ring Light LED Bilight,VR-440 Video Ring Light LED Bilight 11
LED video light
NOTICE!
Use of stands
When mounting the device onto a stand, ensure that the stand is in a safe and stable position and that the weight of the device does
not exceed the maximum permissible load capacity of the stand.
Safety instructions
12 VR-260 Video Ring Light LED Bilight,VR-440 Video Ring Light LED Bilight
LED video light
3 Features
The LED ring light with variable colour temperature is particularly suitable for lighting tasks
during video shooting, in reports on the road, or in the studio.
Special features of the device:
nLong service life and low heat emission
nLightweight design for use on the go
nSimple control directly on the device
n180° swivelling
nHigh CRI
nLarge and even illumination
nNumerous mounting options for tripods, mobile devices and cameras
nMobile operation via built-in rechargeable battery
nOperation also possible during charging
nUSB port for charging smartphones or other devices
nPlug-in power supply included
nMatching bags available separately (item no. 497377 for item no. 495350, item no. 499547
for item no. 498926)
nTripod and smartphone holder available separately
Features
VR-260 Video Ring Light LED Bilight,VR-440 Video Ring Light LED Bilight 13
LED video light
For technological reasons, the light output of LEDs decreases over their lifetime. This eect
increases with higher operating temperature. You can extend the service life of the illuminants
by providing adequate ventilation and operating the LEDs with the lowest possible brightness.
Features
14 VR-260 Video Ring Light LED Bilight,VR-440 Video Ring Light LED Bilight
LED video light
4 Installation
Unpack and check carefully there is no transportation damage before using the unit. Keep the
equipment packaging. To fully protect the product against vibration, dust and moisture during
transportation or storage use the original packaging or your own packaging material suitable
for transport or storage, respectively.
Create all connections while the device is Use the shortest possible high-quality cables foro.
all connections. Take care when running the cables to prevent tripping hazards.
You can install the device standing or hanging. When in use, the device must be mounted at a
solid surface or clamped to an approved truss.
Work from a stable platform whenever you install or move the device or when you perform
any kind of maintenance. Block access under the work area.
Installation
VR-260 Video Ring Light LED Bilight,VR-440 Video Ring Light LED Bilight 15
LED video light
WARNING!
Risk of injury caused by falling objects
Make sure that the installation complies with the standards and rules that apply
in your country. Always secure the device with a secondary safety attachment,
such as a safety cable or a safety chain.
Secure the barn door with a safety cable on the spotlight after installation. The
safety cable must run outside the barn door and must not interfere with the light
emission.
Installation
16 VR-260 Video Ring Light LED Bilight,VR-440 Video Ring Light LED Bilight
LED video light
4.1 Dealing with lithium batteries
WARNING!
Incorrect handling of lithium batteries can result in injury
In the event of a short circuit, overheating or mechanical damage, lithium bat‐
teries can cause severe injuries.
Follow the advice on the correct handling of lithium batteries in the present sec‐
tion.
When handled correctly and appropriately lithium batteries pose no risk.
Store lithium batteries in a cool, dry place, ideally in the original packaging.
Store lithium batteries away from heat sources (e.g. radiators or sunlight). Lithium batteries are
hermetically sealed. Never attempt to open a lithium battery.
If the battery housing is damaged small amounts of the electrolyte may leak out. If this should
happen, seal the lithium battery in airtight packaging and wipe up the traces of electrolyte
using absorbent paper towels. You must wear protective rubber gloves when doing so. Clean
your hands and the surface thoroughly with cold water.aected
Installation
VR-260 Video Ring Light LED Bilight,VR-440 Video Ring Light LED Bilight 17
LED video light
Never attempt to recharge non-rechargeable lithium batteries. When charging lithium bat‐
teries you must use a suitable charging device intended for the purpose.
Before disposing of the device remove the lithium batteries. Protect used lithium batteries
against potential short circuits, e.g. by covering the poles with adhesive tape.
Only use powder extinguishers or other suitable extinguishing agents to extinguish a burning
lithium battery.
Installation
18 VR-260 Video Ring Light LED Bilight,VR-440 Video Ring Light LED Bilight
LED video light
5 Connections and controls
Connections and controls
VR-260 Video Ring Light LED Bilight,VR-440 Video Ring Light LED Bilight 19
LED video light
1 LED ring
2 Thread for mounting a smartphone holder (1/4" thread)
3[WW]
Brightness control (warm white)
4 Locking screws for the bracket
5 Bracket for hanging or tripod mounting
6[CW]
Brightness control (cool white)
7 with charge control LED[USB]
USB port for charging smartphones or other devices.
If the charge control LED lights up red, the internal battery is being charged. When the LED lights up green, the bat‐
tery is fully charged.
8 [ON] [OFF]
Main switch. Turns the device on and o.
Connections and controls
20 VR-260 Video Ring Light LED Bilight,VR-440 Video Ring Light LED Bilight
LED video light
9 Thread for tripod mounting (3/8" thread)
10 [POWER]
Connection socket for the power adapter
Connections and controls
VR-260 Video Ring Light LED Bilight,VR-440 Video Ring Light LED Bilight 21
LED video light
6 Technical specications
Item no. 495350 Item no. 498926
Light source 120 × SMD-LED, 0.5 W
(60 × 3000 K, 60 × 5700 K)
312 × SMD-LED, 0.5 W
(156 × 3000 K, 156 × 5700 K)
Light source properties Colour temperature 3000 … 5700 K, selectableinnitely
Colour rendering index CRI 95
Optical properties Beam angle 120°
Light output 0.5 m: 1120 lm
1 m: 256 lm
0.5 m: 1340 lm
1 m: 475 lm
Input connections Power supply Connection socket for the power adapter
Power consumption LEDs 18 W 22 W
Operation while charging 34 W 48 W
Charging only 16 W 26 W
Technical specications
22 VR-260 Video Ring Light LED Bilight,VR-440 Video Ring Light LED Bilight
LED video light
Item no. 495350 Item no. 498926
Power supply Power adapter, 100 - 240 V 50/60 Hz
Operating voltage 15 V / 3 A 15 V / 5 A
Battery / rechargeable
battery
Battery type Lithium-ion
Voltage 12 V
Capacity 6000 mAh 9000 mAh
Charging time 4.5 h 6 h
Operating time 4.5 h 5 h
Protection class IP20
Mounting options hanging, tripod
Dimensions (W × H × D) 262 mm × 353 mm × 56 mm 445 mm × 577 mm × 78 mm
Weight 1 kg 2.3 kg
Ambient conditions Temperature range 0 °C…40 °C
Relative humidity 20 %…80 % (non-condensing)
Technical specications
VR-260 Video Ring Light LED Bilight,VR-440 Video Ring Light LED Bilight 23
LED video light

Produktspecifikationer

Varumärke: Varytec
Kategori: Lättnad
Modell: VR-440

Behöver du hjälp?

Om du behöver hjälp med Varytec VR-440 ställ en fråga nedan och andra användare kommer att svara dig


Lättnad Varytec Manualer

Varytec

Varytec LED Pad 7x10W Bruksanvisning

10 September 2024
Varytec

Varytec Bat.Derby Bruksanvisning

10 September 2024
Varytec

Varytec Giga Bar HEX 3 Bruksanvisning

10 September 2024
Varytec

Varytec LED Ball Bruksanvisning

9 September 2024
Varytec

Varytec BAT.PARset 4 Bruksanvisning

9 September 2024
Varytec

Varytec Hero Spot 90 Bruksanvisning

9 September 2024
Varytec

Varytec Typhoon True 12x10 Bruksanvisning

9 September 2024
Varytec

Varytec Giga Bar 5 LED Bruksanvisning

9 September 2024
Varytec

Varytec Area Flood 80 IP Bruksanvisning

9 September 2024
Varytec

Varytec VR-260 Bruksanvisning

9 September 2024

Lättnad Manualer

Nyaste Lättnad Manualer

Smartwares

Smartwares 10.012.53 Bruksanvisning

9 April 2025
ET2

ET2 Waterfall E24846-90 Bruksanvisning

9 April 2025
Schwaiger

Schwaiger CALE100 511 Bruksanvisning

9 April 2025
Ryobi

Ryobi One+ P796B Bruksanvisning

8 April 2025
ADB

ADB Orkis Fresnel Bruksanvisning

8 April 2025
Claypaky

Claypaky Actoris ParLED Bruksanvisning

8 April 2025
V-Tac

V-Tac VT-995 Bruksanvisning

7 April 2025
WAC Lighting

WAC Lighting WS-W42016 Bruksanvisning

5 April 2025
WAC Lighting

WAC Lighting WS-W21110 Bruksanvisning

5 April 2025
WAC Lighting

WAC Lighting DS-WS05 Bruksanvisning

5 April 2025
