Mod. Energy-230 D80
In normal operation the LED and the pulse output (terminals 20 and 21)
emit a signal with a frequency proportional to the measured energy
(1000 flashes every kWh).
The counter increments every 0,1 kWh
4
OPERATION
3
CONNECTION DIAGRAM
03-2025
REFERENCE STANDARDS
Compliance with Community directives:
2014/35/EU (LVD) e 2014/30/EU (EMCD)
is declared in reference to the following harmonised standards:
• EN 62052-11 • EN 62053-21 • EN 61010-1
Manuals
download
PDF
1
User Manual
SINGLE-PHASE ACTIVE ENERGY METER
Read all the instructions carefully
The Energy-230 D80 static energy meter is a device for internal use, for
counting active energy in single-phase 230 Vac systems. Current insertion
is direct for values up to 80 A. It has a pulse output for remote energy
counting.
Code Model
Description
VE799000 Energy-230 D80 Single-phase active energy meter 80A
SAFETY WARNINGS
During product installation and operation it is necessary to observe the
following instructions:
1) The product must be installed by a qualified person, strictly in observance
of the connection diagrams shown in this manual.
2) The product must be installed and activated in compliance with current
electric systems standards
3) After installation inaccessibility to the terminals without using dedicated
tools must be guaranteed
4) Do not use the product for anything other than the indicated purpose.
5) The product must be installed in an adequately protected closed electrical
panel.
6) In the supply network there must be a bipolar disconnection.
7) In the electrical system upstream of the product must be installed a
protection device against the overcurrents.
8) Before accessing the connection terminals, make sure that the leads
are not live.
9) Do not connect or feed the product if any part of it is damaged.
10) The product can be used in environments with Measurement Category III
and Pollution degree 2, according to the Standard EN 61010-1.
TECHNICAL SPECIFICATIONS
• Power supply:230 Vac 50 Hz
• Absorption ≤ 10VA (≤ 2W)
• Starting current: I
st
= 20 mA
• Reference current: I
ref
= 5 A
• Maximum current: I
max
= 80 A
• Insertion type: direct for current inputs
• Signal LED: Flashing LED (1000 flashes per kWh)
• Display: 6-digit electromechanical pulse counter
• Energy display resolution: 0,1 kWh (full scale: 99999,9 kWh)
• Optoisolated pulse output for remote reading of counts
(1000 pulses/ kWh)
• Pulse characteristics:
- Pulse duration = 80 ms
- Maximum voltage: 30 Vdc
- Maximum current: 27 mA
• Container: 1 DIN modules
• : IP20/IP51 Degree of protection on the front
• Class index: 1
• Operating temperature: -10 ÷ 45 °C
• Storage temperature: -20 ÷ 70 °C
• Average relative humidity: ≤75% non-condensing
• Maximum humidity ≤95%
INSTRUMENT DESCRIPTION and DIMENSIONS
2
100.5
36
65
45
information to users pursuant to art. 14 of the directive
2012/19 / EU of the european parliament and of the council
of 4 july 2012 on waste electrical and electronic equipment (WEEE)
If the crossed-out bin symbol appears on the equipment or packaging,
this means the product must not be included with other general waste
at the end of its working life.
The user must take the worn product to a sorted waste center,
or return it to the retailer when purchasing a new one.
Products for disposal can be consigned free of charge (without any new purchase obligation)
to retailers with a sales area of at least 400 m
2
, if they measure less than 25 cm.
An efficient sorted waste collection for the environmentally friendly disposal of the used device, or its
subsequent recycling, helps avoid the potential negative effects on the environment and people’s health,
and encourages the re-use and/or recycling of the construction materials.
1 Terminals for direct insertion
of measuring conductors
2 Electromechanical numerator
with 5+1 digit
3 LED indicator of absorbed energy
(ashing with frequency
1000 imp/kWh)
4 Pulse output terminals
4
2
3
1
1
21
3
4
L
N
2021
V = 30 V
max
I = 20 mA
max
1 Wh/pulse
+
2021
LOAD
