ISCOM017-0911

Mod. Sensor-140

Sensor-200

User manual

Movement detectors

Read all instructions carefully

The

Sensor-140

and

Sensor-200

proximityswitchesareelectronicswitchingdevices

containingmicro-disconnection(µ)accordingtoEN60669-2-1.Theoutputcircuitisactivated

whenaheatsourcemovesinfrontofthedeviceandisdeactivatedwhennomovementis

intercepted, after a settable period of elapsed time.

SAFETY WARNINGS

During installation and operation of the instrument, comply with the following

instructions:

1) The instrument must be installed by a skilled person, in strict compliance with the

connection diagrams

2) Do not power on or connect the instrument if any part of it is damaged

3) In the building where the instrument is to be installed, there must be a switch and a

device for protection from overloads

4) Before touching the connector terminals make sure that the wires to be connected or

already connected to the instrument are not live.

Code Model Description

VE212700 Sensor-140 Movement detector 140°

VE213500 Sensor-200 Movement detector 200°

TECHNICAL CHARACTERISTICS

• Powersupply:230VAC50Hz

• Beakingcapacity:5A250VAC(resistiveload)

• Maximumrecommendedloads:

 −Incandescentlightbulbs:1000W

 −Non-compensateduorescent:500W

 −Compensateduorescent:250W

 −Halogen(230VAC):1000W

 −Lowconsumptionbulbs:200W

• Consumption:6VA(1W)

• Rangeofbrightness:5-30-2000lux

• Interventiontime:from3secondsto30minutes(approximate)

• Angleofdetection: −Sensor-140:140°

  −Sensor-200:200°

• Rangeofdetection:−frontal12mat20°C

  −lateral8mat20°C

• Operatingtemperature:-20°C÷+40°C

• Protectiondegree:IP55

• Insulation:classII

INSTALLATION

• Thedevicemustbeinstalledfarfrominductiveloads(motors,transformers,telephone

antennas,transformerplants,industrialmachinery,etc.)asespeciallystrongmagnetic

eldsmayalteroperation.Thedevicemustalsobeprotectedfromrainandsunlight.

Itmustnotbeplacednearlights,neardevicesthataresubjecttotemperaturechanges

(heating,airconditioning).Itmustbelocatedfarfromhighlyreectivesurfaces.

 Removethecoverbylooseningthescrewatthebottom.Fastenthebasecoveratthepoint

onthewallwhereyouwanttoinstallit,ataheightof2-3metres.

 Thedirectionofmovementoftheheatsourcemustbetransversaltolensofthedevice,

becausedetectionoccursbymeansofintersectionofbands.Therefore,ifsourcemoves

paralleltothebands,detectionwilloccuratalesserdistance.Theambienttemperature

alsoaffectsthesensitivityofthedevice.Thehigherthetemperature,thepoorersensitivity

willbe.

• Theheadcanrotatehorizontallyabout180°andverticallyabout45°.Toadjusttheeldof

detection:

 −turntheinterventiontimeselectortotheminimumandthebrightnessselectorto();

 −checkcoveragebymovinginsidetheeldofdetection.

 Thedeviceisalsoequippedwithlimitersofthedetectionareadividedintofoursectors.If

appliedtothelens,theymakeitpossibletoexcludeoneormoreofthesectorsoftheeld

of detection.

• Toadjustthebrightness,turntheselectortowards( );whentheambientbrightnessisas

desiredforoperation,startturningtheselectortheotherway,untililluminationoccurs.

• Toadjusttheinterventiontime,turntheselector() to the desired position. You can

choosefromaminimumof3secondstoamaximumof30minutes.Thistimeisreset

eachtimethereisaninterceptionbythedetector.

• Duringnormaloperation,whenthelevelofbrightnessdropsbelowthesetlevel,the

devicesetsupfordetection,andsignalsthisconditionviaashingoftheinternalLED.

OPERATION

• The

Sensor-140

and

Sensor-200

havetwooperatingmodes:

 −normalmode,inwhichthedevicesarenormallyactivated30secondsaftertheyare

connected;

 −permanentlyon,withthedevicesremainingonpermanentlyforsixhours.Thisoccurs

whenyouperformarapidOFF-ON-OFF-ONoperation(lessthan2seconds).The

devicesbeingoperatinginnormalmodeagainwhenthesixhourshaveelapsedorif,

duringthisperiod,youperformanotherOFF-ONoperation.

REFERENCE STANDARDS

ConformitytotheEUdirectives:

2006/95/EC(lowvoltage)

2004/108/CE(EMC)

isdeclaredwithreferencetoharmonizedstandard:

EN 60669-2-1

Dimensions

Connection diagrams

Sensitivity

L' N L

230 V ACLAMPADINA

100

GREATER SENSITIVITY LESS SENSITIVITY

BULB

direction of

movement

direction of

movement

Field of detection
