TABLE OF CONTENTSRev. 5/28/2025 AHA MANUAL
TABLE OF CONTENTSCopyright 2020 Vestil Manufacturing Co. Page 1 of 24
AHA-SERIES ALUMINUM ADJUSTABLE-HEIGHT GANTRY CRANES
Receiving Instructions
After delivery, remove the packaging from the product. Inspect the product closely to determine whether it
sustained damage during transport. If damage is discovered, record a complete description of it on the bill of lading. If
the product is undamaged, discard the packaging.
NOTE:The end-user is solely responsible for confirming that product design, use, and maintenance comply with laws,
regulations, codes, and mandatory standards applied where the product is used.
Technical Service & Replacement Parts
For answers to questions not addressed in these instructions and to order replacement parts, labels, and accessories,
call our Technical Service and Parts Department at (260) 665-7586. The department can also be contacted online at
http://www.vestilmfg.com/parts_info.htm.
Electronic copies of Instruction Manuals
Additional copies of this instruction manual may be downloaded from https://www.vestil.com/page-manuals.php.
Vestil Manufacturing Company
2999 North Wayne Street, P.O. Box 507, Angola, IN 46703
Telephone: (260) 665-7586 -or-Toll Free (800) 348-0868
Fax: (260) 665-1339
Website: www.vestil.com e-Mail: HU[email protected]U
Table of Contents
Page
Table of Figures
Page
Specifications………...……………...
2, 3
FIG. 1 Exploded view: AHA-2-8-8, 2-8-10, & 2-8-12 ………………….
5
Signal Words……….…………...........
4
FIG. 2 Exploded View AHA-2-10-8, 2-10-10, & 2-10-12………………
6
Safety Instructions……..…………….
4
FIG. 3 Exploded View AHA-2-12-8, 2-12-10, & 2-12-12………………
7
Assembling the Crane..…………....
17, 18, 19, 20
FIG. 4 Exploded View AHA-2-15-8, 2-15-10, & 2-15-12…..……........
8
Using the Crane...............................
21
FIG. 5 Exploded View AHA-4-8-8, AHA-4-8-10, & AHA-4-8-12……..
9
Record of Satisfactory Condition..
21 - 22
FIG. 6 Exploded View AHA-4-10-8, AHA-4-10-10, & AHA-4-10-12...
10
National Standards…………………
22
FIG. 7 Exploded View AHA-4-12-8, AHA-4-12-10, & AHA-4-12-12…
11
Inspections & Maintenance………
22 - 23
FIG. 8 Exploded View AHA-4-15-8, AHA-4-15-10, & AHA-4-15-12…
12
Labeling Diagram…………………...
23
FIG. 9 Exploded View AHA-6-8-8, AHA-6-8-10, & AHA-6-8-12….….
13
Limited Warranty………………….…
24
FIG. 10 Exploded View AHA-6-10-8, AHA-6-10-10, & AHA-6-10-12.
14
FIG. 11 Exploded View AHA-6-12-8, AHA-6-12-10, & AHA-6-12-12.
15
FIG. 12 Exploded View AHA-6-15-8, AHA-6-15-10, & AHA-6-15-12.
16
