Copyright 2017 Vestil Manufacturing Corp. Page 1 of 7
ACP
ALUMINUM
CHANNEL
DOLLY
I
NSTRUCTION
M
ANUAL
Receiving instructions:
After delivery, IMMEDIATELY remove the packaging from the product in a manner that preserves the
packaging and maintains the orientation of the product in the packaging; then inspect the product closely
to determine whether it sustained damage during transport. If damage is discovered during the
inspection, immediately record a complete description of the damage on the bill of lading. If the
product is undamaged, discard the packaging.
NOTES:
1) Compliance with laws, regulations, codes, and non-voluntary standards enforced in the location where
the product is is exclusively the responsibility of the owner/end-user. used
2) VESTIL is for any injury or property damage that occurs as a consequence of failing to apply either: a) not liable
the instructions in this manual; or b) information provided on labels axed to the product.
Neither is Vestil
responsible for consequential damages sustained as a result of failing to exercise sound judgment any
while assembling, installing, using or maintaining this product.
V
ESTIL
M
ANUFACTURING
C
ORP
.
2999 North Wayne Street, P.O. Box 507, Angola, IN 46703
Telephone: (260) 665-7586 -or- Toll Free (800) 348-0868
Fax: (260) 665-1339
www.vestilmfg.com e-mail: sales@vestil.com
Table of Contents
Hazard identication: explanation of signal words……………………………………………………………………. 2
Safety Guidelines…………………………………………………………………………..………………………….….2
Exploded parts diagrams and bills of materials………..……………………………………………………………...3-5
Label placement diagram …………..
…………………………………………………………...................................6
Limited warranty…………………………………………………………………………………………………………..7
rev. 2/1/2017
Copyright 2017 Vestil Manufacturing Corp. Page 2 of 7
HAZARD IDENTIFICATION: explanation of signal words
This manual uses SIGNAL WORDS to indicate the likelihood of personal injuries, as well as the probable
seriousness of those injuries, if the product is misused in the ways described. Other signal words call attention to
uses of the product likely cause property damage.
The signal words used appear below along with the meaning of each word:
Identies a hazardous situation which, if not avoided, WILL result in DEATH or
SERIOUS INJURY. Use of this signal word is limited to the most extreme
situations.
Identies a hazardous situation which, if not avoided, COULD result in DEATH or
SERIOUS INJURY.
Indicates a hazardous situation which, if not avoided, COULD result in MINOR or
MODERATE injury.
Identies practices likely to result in product/property damage, such as operation that
might damage the product.
Each person who assembles, installs, uses, or maintains this product should read the entire manual and fully
understand the directions in advance. If after reading the manual you do not understand an instruction, ask
your supervisor or employer for clarication, because failure to adhere to the directions in this manual
might result in serious personal injury.
SAFETY GUIDELINES
Vestil diligently strives to identify foreseeable hazards associated with the use of its products. However, material
handling is inherently dangerous and no manual can address every conceivable risk. The end-user ultimately is
responsible for exercising sound judgment at all times.
Electrocution might result if any part of the product contacts electried wires. Reduce the likelihood of
electrocution by applying : common sense
DO NOT electried wires with any part of this device, your body, or clothing. contact
DO NOT use or store the product where contact with electried wires is likely.
Always inspect the usage area before using the product & implement precautions that account for conditions.
If this product is used improperly or carelessly, the operator and/or bystanders might sustain serious
personal injuries or even be killed. To reduce the likelihood of injury:
• Failure to read and understand the entire manual before assembling, installing, using or servicing the
product is a misuse of the product .
• Read the manual to refresh your understanding of proper use and maintenance procedures.
• DO NOT attempt to resolve any problem(s) with the product unless you are both authorized to do so and that it certain
will be safe to use afterwards.
• DO NOT modify the product in any way UNLESS you rst obtain written approval from Vestil. Unauthorized
modifications automatically void the Limited Warranty and might make the product unsafe to use.
• DO NOT exceed the maximum rated load (see Label 287 on product).
• Inspect the product before each use.
A. DO NOT use this product if the inspection reveals structural damage. Examples of structural damage include,
but are not limited to, the following: 1) Cracked, broken or significantly deformed load-bearing members; 2)
cracked welds; 3) missing or deformed safety chain/strap; 3) corrosion, severe wear, or other condition that
aects the ability of the product to support weight or itself. Replace each part that fails to pass an inspection,
and DO NOT use the product until it is fully restored to normal condition.
B. DO NOT use the product if any unusual noise or movement is observed. If a malfunction occurs, remove the unit
from service and notify your supervisor & maintenance personnel about the issue.
• DO NOT use this device UNLESS all product labels (see “Label Placement Diagram”) are readable and undamaged.
Proper use, maintenance, and storage are essential for this product to function properly.
o Always use this product in accordance with the instructions in this manual and consistent with any training relevant
to machines, devices, etc. used in conjunction with this product.
o Keep the product clean & dry. Lubricate moving parts.
o FOR HYDRAULIC UNITS: Do not use brake uid or jack oils in the hydraulic system. If oil is needed, use an anti-
wear hydraulic oil with a viscosity grade of 150 SUS at 100°F, (ISO 32 cSt @ 40°C), or Dexron transmission uid.
o Contact the manufacturer for MSDS information
rev. 2/1/2017
Copyright 2017 Vestil Manufacturing Corp. Page 3 of 7
ACP-1824-9
ACP-2130-9
ITEM NO PART NUMBER DESCRIPTION QTY
1 16-514-100 WELDMENT, FRAME 1
2 16-132-004 CASTER HR-3/1.25-SLB-S 4
3 11105 BOLT, HHCS #2 Z PLATED 16
4 33008 3/8 USS FLAT WASHER Z PLATED 16
5 36105 NUT, 3/8-16 UNC 16
6 33622 LOCK WASHER Z PLATED, 3/8 16
ITEM NO PART NUMBER DESCRIPTION QTY
1 16-514-101 WELDMENT, FRAME 1
2 16-132-004 CASTER HR – 3/1.25 – SLB – S 4
3 11105 BOLT, HHCS #2 Z PLATED 16
4 33008 3/8 USS FLAT WASHER Z PLATED 16
5 36105 NUT, 3/8 – 16 UNC 16
6 33622 LOCK WASHER Z PLATED, 3/8 16
