Rev. 6/12/2018 DJG-100, MANUAL
Copyright 2017 Vestil Manufacturing Corp. Page 1 of 15
Instruction Manual
DJG-100 and DJG-100-10
Receiving instructions:
After delivery, remove the packaging from the product. Inspect the product closely to determine whether
it sustained damage during transport. If damage is discovered, record a complete description of it on the
bill of lading. If the product is undamaged, discard the packaging.
NOTE:
The end-user is solely responsible for confirming that product design, installation, use, and maintenance
comply with laws, regulations, codes, and mandatory standards applied where the product is used.
Replacement Parts and Technical Assistance:
To order replacement parts, labels, and accessories, contact the technical service and parts department
online at http://www.vestilmfg.com/parts_info.htm. Alternatively, you may request replacement parts and/or
service by calling (260) 665-7586 and asking for the Parts Department.
Vestil Manufacturing Corp.
2999 North Wayne Street, P.O. Box 507, Angola, IN 46703
Telephone: (260) 665-7586 -or- Toll Free (800) 348-0868
Fax: (260) 665-1339
www.vestilmfg.com e-mail: [email protected]
Table of Contents
Signal Words………………………………………………………….……………………………………………… 2
Hazards of Improper Use……..…………………………………………………………..……………………….. 2
Exploded Parts Diagrams and Bills of Materials………..………………………………………………..….....
3-5
115V, 1-Phase Electrical Layout Diagram and Circuit Diagram…..………………………………………….
6-7
208-230V, 1-Phase Electrical Layout Diagram and Circuit Diagram………..……………………………….
8-9
460V, 3-Phase Electrical Layout Diagram and Circuit Diagram…………..……………………………….
10-11
Installation………………………………………………………………………………………………………..
12-13
Operating the Barricade…………………………………………………………………………………………… 13
Inspections and Maintenance…………………………………………………………………………………….. 14
Labeling Diagram …………...………...……………………………………………………….................... ……. 14
Limited Warranty…………………………………………………………………………………………………… 15
