Vestil EHLTP-3648-3-48-A1 Bruksanvisning
Sidor 26 ej kategoriserat
Läs bruksanvisningen för Vestil EHLTP-3648-3-48-A1 gratis online eller ladda ner PDF:en. 12 personer har tyckt att guiden var hjälpsam. Fråga om modellen? Ställ en fråga
TABLE OF CONTENTSRev. 11/23/2021 EHLTP MANUAL
TABLE OF CONTENTSCopyright 2020 Vestil Manufacturing Corp. Page 1 of 26
EHLTP-Series Portable Electric-Hydraulic Lift Tables
Receiving Instructions
After delivery, remove the packaging from the product. Inspect the product closely to determine
whether it sustained damage during transport. If damage is discovered, record a complete description of
it on the bill of lading. If the product is undamaged, discard the packaging.
NOTE:The end-user is solely responsible for confirming that product design, use, and maintenance comply
with laws, regulations, codes, and mandatory standards applied where the product is used.
Technical Service & Replacement Parts
For answers to questions not addressed in these instructions and to order replacement parts, labels,
and accessories, call our Technical Service and Parts Department at (260) 665-7586. The Department can
also be contacted online at https://www.vestil.com/page-parts-request.php
.
Electronic Copies of Instruction Manuals
Additional copies of this instruction manual may be downloaded from
https://www.vestil.com/page-
manuals.php.
Vestil Manufacturing Corp.
2999 North Wayne Street, P.O. Box 507, Angola, IN 46703
Telephone: (260) 665-7586 -or- Toll Free (800) 348-0868
Fax: (260) 665-1339
Web:
www.vestilmfg.come-mail: info@vestil.com
Table of Contents
Page
Signal Words……………………..…………………………….……………………………..……….………….….
2
Safety Instructions………….……………………………………………………..…………..……….…………...
2 - 3
Hydraulic Circuit Diagram………..…………...……………………..………………………..………………….
3
Exploded Views and Bills of Materials………………………………………………………..…………………
4 - 15
Power Unit Subassemblies………………………………………………………………………………….……..
16, 17, 18
Exploded View and Bill of Materials: Perimeter Toeguard………………………………..……………...…
19
Specifications………………………………………………………………………………………..………………
19
Record of Satisfactory Condition………………………………………………………………….…………....
20
Operation Instructions………………………………………………………………………………..………...….
20, 21
Inspections and Maintenance……………………………………………………………………….……….…
21, 22, 23
Bleeding Air from the Hydraulic Cylinder…………………………………………………………..….……….
23
Troubleshooting Guide…………………………………………………………………………….……..…..……
24
Labeling Diagram.…………..………………………………………..……………............................................
25
Limited Warranty…………………………………………….……………………………………………..…....…
26
