Table of Contents 3/30/2020 HBD MANUAL
Table of Contents Copyright 2019 Vestil Manufacturing Co. Page 1 of 21
HBD-Series Hydraulic Box Dumpers
Instruction Manual
Receiving instructions:
After delivery, remove the packaging from the product. Inspect the product closely to determine
whether it sustained damage during transport. If damage is discovered, record a complete description
of it on the bill of lading. If the product is undamaged, discard the packaging.
NOTE:
The end-user is solely responsible for confirming that product design, use, and maintenance comply
with laws, regulations, codes, and mandatory standards applied where the product is used.
Replacement Parts and Technical Service:
For answers to questions not addressed in these instructions and to order replacement parts, labels,
and accessories, call our Technical Service and Parts Department at (260) 665-7586. The department
can also be contacted online at http://www.vestilmfg.com/parts_info.htm.
Table of Contents
Specifications………………………………........................................................................................................................... 2
Signal Words……….………………...................................................................................................................................... 3
Safety Instructions.……..…………...................................................................................................................................... 3
Installation…………….………………………........................................................................................................................ 4
Loading the Dumper…………………………........................................................................................................................ 4
Inspections……………………………………........................................................................................................................ 5
Power Unit Operation……………………....................................................................................................................... ...5, 6
Figs. 1, 2, & 3: Electric Circuit Diagrams ….………….……………………………………………………………………7, 8, & 9
Fig. 4: Motor & Transformer Connection Diagrams….……………………...…………………………………………….......... 10
Figs. 5A, 5B, & 5C: Electrical Circuit Diagrams……………………………………………………………………...…11, 12, & 13
Figs. 6A & 6B: Hydraulic Circuit Diagrams……….............................................................................................................. 14
Figs. 7A, 7B, & 7C: Exploded Parts Diagrams…………………………………………………...…………………….15, 16, & 17
Installing Option HBD-GATE……………………..………………………………………………………………………………… 18
Troubleshooting……...……………………………………………………………………………………………………………… 19
Limited Warranty……………..…………….......................................................................................................................... 20
Labeling Diagram……………….……………...................................................................................................................... 21
Vestil Manufacturing Corp.
2999 North Wayne Street, P.O. Box 507, Angola, IN 46703
Telephone: (260) 665-7586 -or- Toll Free (800) 348-0868
Fax: (260) 665-1339
Web: www.vestilmfg.com Email: info@vestil.com
Table of Contents 3/30/2020 HBD MANUAL
Table of Contents Copyright 2019 Vestil Manufacturing Co. Page 2 of 21
Model
A: Max.
h
eight with
chute
retracted
B:
Dump
height
C: Max.
height with
chute
extended
Chute
usable
dimensions
[W x L]
D: Overall
length
E: Overall
width
Capacity
Net
weight
HBD-2-36
53
1
/
2
”
136 cm
36”
91 cm
111”
282 cm
52” x 50”
(132 x 127)cm
68
1
/
2
”
174 cm
69”
176 cm
2,000 lb.
909 kg
1631 lb.
741.2 kg
HBD-2-48
65”
165 cm
48”
122 cm
129
1
/
2
”
329 cm
52” x 50”
(132 x 127)cm
68
1
/
2
”
174 cm
69”
176 cm
2,000 lb.
909 kg
1787 lb.
812.2 kg
HBD-2-60
77”
196 cm
60”
152 cm
149
1
/
2
”
380 cm
52” x 50”
(132 x 127)cm
68
1
/
2
”
174 cm
69”
176 cm
2,000 lb.
909 kg
1948 lb.
885.5 kg
HBD-4-36
53
1
/
2
”
136 cm
36”
91 cm
111”
282 cm
52” x 50”
(132 x 127)cm
68
1
/
2
”
174 cm
69”
176 cm
4,000 lb.
1,818 kg
1655 lb.
752.1 kg
HBD-4-48
65”
165 cm
48”
122 cm
129
1
/
2
”
329 cm
52” x 50”
(132 x 127)cm
68
1
/
2
”
174 cm
69”
176 cm
4,000 lb.
1,818 kg
1859 lb.
844.8 kg
HBD-4-60
77”
196 cm
60”
152 cm
149
1
/
2
”
380 cm
52” x 50”
(132 x 127)cm
68
1
/
2
”
174 cm
69”
176 cm
4,000 lb.
1,818 kg
2020 lb.
918 kg
HBD-6-36
53
1
/
2
”
136 cm
36”
91 cm
111”
282 cm
52” x 50”
(132 x 127)cm
68
1
/
2
”
174 cm
69”
176 cm
6,000 lb.
2727 kg
1808 lb.
795kg
HBD-6-48
65”
165 cm
48”
122 cm
129
1
/
2
”
329 cm
52” x 50”
(132 x 127)cm
68
1
/
2
”
174 cm
69”
176 cm
6,000 lb.
2727 kg
1988 lb.
903.3 kg
HBD-6-60
77”
196 cm
60”
152 cm
149
1
/
2
”
380 cm
52” x 50”
(132 x 127)cm
68
1
/
2
”
174 cm
69”
176 cm
6,000 lb.
2727 kg
2021 lb.
919kg
SPECIFICATIONS
Our dumpers are rigorously engineered to provide safety-enhancing features while preserving simplicity.
Standard design features include: 2HP, 3-phase motor; cast iron pump that integrates pressure relief, check,
down solenoid, and pressure compensated flow control valves; expanded metal machine side-guards;
hydraulic actuators with internal brass velocity fuse and stainle
ss steel spring; and 24V fused control circuit.
Dimensions, net weight, and capacity information are provided in the following diagrams and table.
C
B
A
D
E
