Table of ContentsRev. 10/28/2020 PEL MANUAL
Table of Contents Copyright 2020Vestil Manufacturing Corp. Page 1 of 17
PEL-Series Pallet Handlers
Instruction Manual
Receiving Instructions
After delivery, remove the packaging from the product. Inspect the product closely to determine whether it sustained
damage duringtransport. If damage is discovered, record a complete description of it on the bill of lading. If the product
is undamaged, discard the packaging.
NOTE:The end-user is solely responsible for confirming that product design, use, and maintenance comply with laws,
regulations, codes, and mandatory standards applied where the product is used.
Technical Service & Replacement Parts
For answers to questions not addressed in these instructions and to order replacement parts, labels, and
accessories, call our Technical Service and Parts Department at (260) 665-7586. The department can also be
contacted online at http://www.vestilmfg.com/parts_info.htm
.
Electronic copies of Instruction Manuals
Additional copies of this instruction manual may be downloaded from https://www.vestil.com/page-manuals.php
.
Vestil Manufacturing Corp.
2999 North Wayne Street, P.O. Box 507, Angola, IN 46703
Telephone: (260) 665-7586 -or-Toll Free (800) 348-0868
Fax: (260) 665-1339
Web: www.vestilmfg.com e-mail: info@vestil.com
Table of Contents
Signal Words……………………………………………..……………………………………………………………..………….. 2
Safety Instructions…………..……………..……………………………………………..…………………………..…….………2
Specifications…………………………………..…………………………………………………………..………………………. 3
National Standards………………………………………………………………………………………………………………… 3
FIG. 1: PEL-88 & PEL-100 exploded view& bill of materials…………..……………………………..…………………...
4, 5
FIG. 2: PEL-88-A & PEL-100-A exploded view & bill of materials……………………………………………….…………… 6
FIG. 3: PEL-400-57 & PEL-400-72 exploded view& bill of materials………...………………….………………………..
7, 8
FIG. 4: PEL-100-A-SWA exploded viewand bill of materials……………………………………………………….…………
9
Accessory Carriage Attachments..……………………………………………………………………………………………… 10
Installing Accessory Carriage Attachments…………..………………………………………………………………………... 10
FIG. 5: Electrical circuit diagram………………………………………………………………………………………………… 11
Operation Instructions……………………………………………………………………………………………………………. 12
Chain Tension Adjustment Procedure (PEL-88 & PEL-100)…………………………………..…………..………………… 12
Chain Tension Adjustment Procedure (PEL-400-57 & PEL-400-72)……………………..………………………………….13
Battery Charger Operation………………………………………………………………………………………………………. 14
Record of Satisfactory Condition………………………………………………………………………………………………... 15
Inspections & Maintenance…………………………………………………………………………………………………….… 15
Labeling Diagram…………….....………………………………………………………………………………………………… 16
Limited Warranty…...…………………………………………………………………………………………………………..…. 17
Aluminum models
(PEL-88-A & PEL-100-A)
Steel models
(PEL-88, PEL-100, & PEL-400)
