Rev. 12/7/2017 PRAIL-102, MANUAL
Copyright 2017 Vestil Manufacturing Corp. Page 1 of 4
PRAIL-102 Interlocking Crowd Control Barriers
Receiving instructions:
After delivery, remove the packaging from the product. Inspect the product closely to determine whether
it sustained damage during transport. If damage is discovered, immediately record a complete description
of the damage on the bill of lading. If the product is undamaged, discard the packaging.
Note:
The end-user is solely responsible for confirming that product design complies with all laws, regulations,
codes, and mandatory standards applied where the product is used.
Vestil Manufacturing Corp.
2999 North Wayne Street, P.O. Box 507, Angola, IN 46703
Telephone: (260) 665-7586 -or- Toll Free (800) 348-0868
Fax: (260) 665-1339
Web: www.vestilmfg.com e-mail: info@vestil.com
Table of Contents
Signal Words………………………………………………………..……………………………………………….. 2
Safety Guidelines………………………………………….………………………………..………………….……. 2
Barrier Frame Models……………………………………………………………………………………………….. 2
Types of Feet & Foot Installation………………………………………………………………………………….. 2
Specifications………………………………………………………………………………………………………... 3
Using the Barrier…………….………………………………………………..……………………………...……… 3
Limited Warranty…………………………………………………………………………...…………………….….. 4
**Photo of PRAIL-102-Y
Rev. 12/7/2017 PRAIL-102, MANUAL
Copyright 2017 Vestil Manufacturing Corp. Page 2 of 4
Signal Words:
This manual uses SIGNAL WORDS to indicate the likelihood of personal injuries, as well as the
probable seriousness of those injuries, if the product is misused in the ways described. The signal words
used in this manual appear below along with their definitions.
Identifies a hazardous situation which, if not avoided, WILL result in DEATH or
SERIOUS INJURY. Use of this signal word is limited to the most extreme situations.
Identifies a hazardous situation which, if not avoided, COULD result in DEATH or
SERIOUS INJURY.
Indicates a hazardous situation which, if not avoided, COULD result in MINOR or
MODERATE injury.
Identifies practices likely to result in product/property damage, such as operation that
might damage the product.
Safety Guidelines:
Vestil strives to identify all foreseeable hazards of using its products, but no manual can address every
conceivable risk. Read the entire manual before assembling and using the barrier.
If this product is used improperly or carelessly, people might sustain serious personal injuries
or could even be killed.
Read and understand the entire manual before assembling and using this barrier.
This barrier does NOT anchor to the ground and can fall over if pushed. DO NOT use it as a guardrail
because it does not provide fall protection.
DO NOT modify the barrier in any way. Modifications automatically void the Limited Warranty (p. 4) and
might make the product unsafe to use.
Inspect the product before each use. Confirm that there are no breaks or severely rusted/corroded regions,
especially along the top rail.
DO NOT use this device UNLESS all product labels are readable and undamaged.
Barrier
frame
Foot
(standard
“curved”
foot
shown)
Barrier frame model Part no.
PRAIL-102-Y 23-001-363-B
PRAIL-102-G 23-001-353-B
PRAIL-102-HD-Y
(Heavy duty)
23-001-368-B
PRAIL-102-HD-G
(Heavy duty)
23-001-358-B
PRAIL-102-SS 23-001-373-B
PRAIL-102-HD-SS
(Heavy duty)
23-001-374-B
Wheels
(-W suffix)
Flat
(
-
F suffix)
Curved
(no suffix)
Foot Finishes available
Part no.
Curved
(standard
foot)
Yellow
Galvanized
Stainless steel
23-014-309
23-014-306
23-014-318
Flat
Yellow
Galvanized
23-014-311
23-014-308
Wheels
Yellow
galvanized
23-014-310
23-014-307
Types of Feet
Unless wheels or flat feet are ordered, barriers
include (standard) curved feet. Hardware included.
Barrier Frame Models
Barrier frames are available in 3 finishes: yellow
powder coat, galvanized, and stainless steel. Hea
vy
duty barriers are also available in all 3 finishes.
Yellow powder coat finish (-Y suffix)
Galvanized finish (-G suffix)
Stainless steel (-SS suffix)
Foot installation: Insert the feet into the
legs of the barrier frame. Align the bolt
holes in the foot with the holes in the
frame. Insert
1
/
4
”-20 x 2” bolts through the
holes. Secure each bolt with a
1
/
4
” flat
washer and
1
/
4
”-20 hex nut.
Bolt
Washer
and nut
