PRAIL Interlocking Crowd Control Barriers
Receiving instructions:
After delivery, remove the packaging from the product. Inspect the product closely to determine
whether it sustained damage during transport. If damage is discovered, record a complete description of
it on the bill of lading. If the product is undamaged, discard the packaging.
NOTE: The end-user is solely responsible for confirming that product design, use, and maintenance
comply with laws, regulations, codes, and mandatory standards applied where the product is used.
Replacement Parts and Technical Assistance:
If you have questions that are not addressed in these instructions and to order replacement parts,
labels, and accessories, call (260) 665-7586 and ask for the Service and Parts Department. The
department can also be contacted online at http://www.vestilmfg.com/parts_info.htm.
Vestil Manufacturing Corp.
2999 North Wayne Street, P.O. Box 507, Angola, IN 46703
Telephone: (260) 665-7586 -or- Toll Free (800) 348-0868
Fax: (260) 665-1339
Web: www.vestilmfg.com e-mail: info@vestil.com
Table of Contents
Signal Words………………………………………………………..……………………………………………….. 2
Hazards…………………………………………………….………………………………..………………….……. 2
Barrier Frame Models……………………………………………………………………………………………….. 2
Types of Feet & Foot Installation………………………………………………………………………………….. 2
Specifications………………………………………………………………………………………………………... 3
Using the Barrier…………….………………………………………………..……………………………...……… 3
Limited Warranty…………………………………………………………………………...…………………….….. 4
**Photo of PRAIL-102-Y
Table of Contents Rev. 8/9/2019 PRAIL MANUAL
Table of Contents Copyright 2019 Vestil Manufacturing Corp. Page 2 of 4
Signal Words
This manual uses SIGNAL WORDS to direct the reader’s attention to important safety-related messages. These
messages describe uses of the product that could result in personal injury or property damage. Each signal word
corresponds to a specific hazard level. The following are definitions of signal words that might appear in this
manual.
Identifies a hazardous situation which, if not avoided, WILL result in DEATH or SERIOUS
INJURY. Use of this signal word is limited to the most extreme situations.
Identifies a hazardous situation which, if not avoided, COULD result in DEATH or SERIOUS
INJURY.
Indicates a hazardous situation which, if not avoided, COULD result in MINOR or MODERATE
injury.
Identifies practices likely to result in product/property damage, such as operation that might
damage the product.
Hazards
Vestil strives to identify all foreseeable hazards associated with the use of its products. However, material handling is
dangerous and no manual can address every risk. Ultimately the most effective way to prevent injury is for the operator
to apply sound judgment whenever using this device.
Serious personal injuries or death could result if this product is used improperly.
• Read and understand the entire manual before assembling and using this barrier.
• This barrier does NOT anchor to the ground and can fall over if pushed or leaned against. DO NOT use it as a
guardrail! These barriers do not provide fall protection. They should only be used to define boundaries.
• DO NOT modify the barrier in any way. Modifications automatically void the Limited Warranty on p. 4 and might make
the product unsafe to use.
• Inspect the product before each use. Confirm that there are no breaks or severely rusted/corroded regions, especially
along the top rail.
• DO NOT use this device UNLESS all labeling is readable and undamaged.
Barrier
frame
Foot
(standard
“curved”
foot
shown)
Barrier frame model
Part no.
PRAIL-48-Y
23-001-704-B
PRAIL-102-Y
23-001-363-B
PRAIL-102-G
23-001-353-B
PRAIL-102-HD-Y
(Heavy duty)
23-001-368-B
PRAIL-102-HD-G
(Heavy duty)
23-001-358-B
PRAIL-102-SS
23-001-373-B
PRAIL-102-HD-SS
(Heavy duty)
23-001-374-B
Wheels
(-W suffix)
Flat
(-F suffix)
Curved
(no suffix)
Foot type
Finishes available
Part no.
Curved
(standard
foot)
Yellow
Galvanized
Stainless steel
23-014-309
23-014-306
23-014-318
Flat
Yellow
Galvanized
23-014-311
23-014-308
Wheels
Yellow
galvanized
23-014-310
23-014-307
Types of Feet
Unless wheels or flat feet are ordered, barriers include
(standard) curved feet. Hardware included.
Barrier Models
Barriers are available in 3 finishes: yellow powder coat,
galvanized, and stainless steel. Heavy duty
barriers are
also available in all 3 finishes.
Yellow powder coat finish (-Y suffix)
Galvanized finish (-G suffix)
Stainless steel (-SS suffix)
Foot installation: Insert the feet into the
legs of the barrier frame. Align the bolt
holes in the foot with the holes in the frame.
Insert
1
/
4
”-20 x 2” bolts through the holes.
Secure each bolt with a
1
/
4
” flat washer and
1
/
4
”-20 hex nut.
Bolt
Washer
and nut
