Sida 1/9

Rev.7/17/2018RDC‐100,MANUAL

RDC‐100&RDC‐100‐10DRUMROTATINGCARTS

SSEMBLYINSTRUCTIONS

Receivinginstructions:

After delivery, remove the packaging from the product. Inspect the product closely to determine whether it

sustaineddamageduringtransport.Ifdamageisdiscovered,recordacompletedescriptionofitonthebilloflading.If

theproductisundamaged,discardthepackaging.



NOTE:

Theend‐userissolelyresponsibleforconfirmingthatproductdesign,installation,use,andmaintenancecomply

withlaws,regulations,codes,andmandatorystandardsappliedwheretheproductisused.

VestilManufacturingCorp.

2999NorthWayneStreet,P.O.Box507,Angola,IN46703

Telephone:(260)665‐7586‐or‐TollFree(800)348‐0868

Fax:(260)665‐1339

www.vestilmfg.come‐mail:info@vestil.com

TableofContents



SignalWords………………………………………………………………………………………………………………………………………………………………………2



Specifications……..…………………........…………………………………………………………………………………………………………………………………...2



HazardsofImproperUse.………………………………………………………………………………………...............................................................2



DCR‐100explodedpartsdiagramandbillofmaterials……………………………………………………………………………………………………… .3



DCR‐100‐10explodedpartsdiagramandbillofmaterials………………………………………………………………………………………………….4



Specifications……………………………………….…………………………………………………………………………………………………………………………….5



Assembly………………………………………………………………………………………………………………………………………………….……………...... 5‐6



UsingtheCart…………………………………………………………………………………………………………………………………………………………………….7



InspectionsandMaintenance……………………………………………………………….……………………………………………………………………………8



LabelingDiagram………………………………………………………………………………..………………………………………………………………………………8



LimitedW

arranty………

…………………………………………………………………..

……………………………………………………………

………………………



Rev.7/17/2018RDC‐100,MANUAL

SIGNALWORDS:

ThismanualusesSIGNALWORDStoindicatethelikelihoodofpersonalinjuries,aswellastheprobable

seriousnessofthoseinjuries,iftheproductismisusedinthewaysdescribed.Othersignalwordscallattentionto

usesoftheproductlikelytocausepropertydamage.

Identifiesahazardoussituationwhich,ifnotavoided,WILLresultinDEATHorSERIOUS

INJURY.Useofthissignalwordislimitedtothemostextremesituations.



Identifiesahazardoussituationwhich,ifnotavoided,COULDresultinDEATHorSERIOUS

INJURY.



Indicatesahazardoussituationwhich,ifnotavoided,COULDresultinMINORorMODERATE

injury.



Identifiespracticeslikelytoresultinproduct/propertydamage,suchasoperationthatmight

damagetheproduct.



HazardsofImproperUse:



Vestilstrivestoidentifyeveryforeseeablehazardsassociatedwiththeuseofitsproducts.However,material

handlingisinherentlydangerousandnomanualcanaddresseveryconceivablerisk.Ultimately,themosteffective

meansforpreventingaccidentsisfortheend‐usertoapplygoodjudgmentandforesightwheneverusingthis

product.



Ifthisproductisusedimproperlyorcarelessly,theuserand/orbystandersmightsustainserious

personalinjuries.Toreducethelikelihoodofinjury:

 Readandunderstandtheentiremanualbeforeassembling,usingormaintainingthecart.

 DO NOT modify this cart in any way UNLESS you first obtain written approval from Vestil. Unapproved

modificationsautomaticallyvoidtheLimitedWarranty(p.9)andmightmakethecartunsafetouse.

 DONOTattempttocarryortransportloadsthatexceedthecapacityofthecart.Capacityinformationappears

inthe“Specifications”tableonp.#aswellasonlabel287(see“LabelingDiagram”onp.8.)

 ALWAYSsecuredrumstothecartwiththe(yellow)drumlock.

 DONOTstand,sit,orrideonthecart.Onlyusethiscarttomovedrums.

 Alwayswatchthedrumcarefullywhilethecartis moving.Ifnecessary,securethedrumtothecart,e.g.with

ratchetstraps.

 Do not attempt to go up ordown slopedterrain witha loaded cart. Only use thecart on even, levelground

whenitisloaded.Whenunloaded,alwayscontrolthecartfromtheuphillsidewhilemovingupordownslopes.

 Carefullyrotatethecarttosetthedrumontheground.Ifyoucannotcomfortablyliftthedrumandcontrolthe

cartasitrotates,asksomeonetoassistyou.

 Routinelyinspectthecartaccordingtotheinstructionsin“InspectionsandMaintenance”(p.8).



 Proper use, maintenance, and storageare essential to keepthis cart in normalcondition for as

longaspossible.Applytheinspectionandmaintenanceproceduresprovidedonp.8.

o Regularlycheckallfasteners.Tightenloosenuts.Lubricaterollers,wheels,andcasterswhenevernecessary.

o Inspectthehandle,handlereceiver,andretaininghardwareforcracks,bends,etc.

o Examinetheframe.Checkallweldsandframemembersforcracksandseverecorrosion/rusting.

o Cleanthecartperiodically.

o Removerustwithasteelbristlebrush,cleantheaffectedarea,andcoveritwithtouchuppaint.

o Storethecartinadrylocation.
