Sida 1/7
Table of Contents
Rev. 7/23/2020.
SSLP-200-2 MANUAL
Table of Contents
Copyright 2020 Vestil Manufacturing Co.
Page 1 of 7
Vestil Manufacturing Corp.
2999 North Wayne Street, P.O. Box 507, Angola, IN 46703
Telephone: (260) 665-7586 -or- Toll Free (800) 348-0868
Fax: (260) 665-1339
Web: www.vestil.com e-mail: info@vestil.com
SSLP-200-2
Short Span Lifting Plate, 20,000lb. (9,090kg) Capacity
Receiving Instructions
After delivery, remove the packaging from the product. Inspect the product closely to determine
whether it sustained damage during transport. If damage is discovered, record a complete description of
it on the bill of lading. If the product is undamaged, discard the packaging.
NOTE: The end-user is solely responsible for confirming that product design, use, and maintenance
comply with laws, regulations, codes, and mandatory standards applied where the product is used.
Technical Service & Replacement Parts
For answers to questions not addressed in these instructions and to order replacement parts, labels,
and accessories, call our Technical Service and Parts Department at (260) 665-7586. The department
can also be contacted online at http://www.vestilmfg.com/parts_info.htm.
Electronic copies of Instruction Manuals
Additional copies of this instruction manual may be downloaded from
https://www.vestil.com/page-
manuals.php.
Table of Contents
Signal Words……………………………………………………………………………………………………
Safety Instructions…...…………………………….…………………………….....……………….……….
…
National Standards……………………………………………………………………………………………..
Record of Satisfactory Condition………………………..………………………………………….
………...
Specifications……………………………………………………………………………………………...……
Exploded View and Bill of Materials……..…………………………………………………………......…….
Using the Lifter….……………………………………………………………………….……………………...
Load Tests………………………………………………………………………………………………………
.
Inspections & Maintenance.……………………………………………………………….……..…………
…
Labeling Diagram.….……………………………………………………………………………………….….
Limited Warranty……………………………………………..………………………………………….……………
Page
2
2-3
3
3
3
4
4
5
5
6
7
Table of Contents
Rev. 7/23/2020.
SSLP-200-2 MANUAL
Table of Contents
Copyright 2020 Vestil Manufacturing Co.
Page 2 of 7
SAFETY INSTRUCTIONS
Vestil strives to identify all foreseeable hazards associated with the use of its products. However,
material handling is dangerous and no manual can address every conceivable risk. The most
effective
way to prevent injury is to apply sound judgment whenever using this device.
Material handling is dangerous and could result in serious personal injuries or death.
• Read and understand the entire manual before using or servicing this lifter. DO NOT use this
device until you read and understand the entire instruction manual. Read the manual to refresh your
understanding of proper use and maintenance procedures.
• This lifting device must only be used by designated persons and lifting device inspectors. Maintenance
and test personnel should only use this device when necessary to perform their duties.
• DO NOT use this lifter if it is damaged or missing parts. Only use manufacturer-approved replacement
parts.
• DO NOT modify the product in any way without first obtaining written approval from Vestil. Unapproved
modifications automatically void the LIMITED WARRANTY and might make the product unsafe to use.
• Only attach the lifter to a properly functioning safety hook, i.e. a hook with a spring latch.
• DO NOT remove or obscure any label. Confirm the placement and legibility of all labels as shown in the
LABELING DI
AGRAM on p. 6. DO NOT use this device UNLESS all labeling is readable and undamaged.
• Inspect the lifter before each use. See INSPECTIONS AND MAINTENANCE on p. 5.
• Review safety messages in the manuals for your crane, trolley, hoist, rigging, and all other devices used
in conjunction with this spreader beam
.
• Tighten shackle pins before each use. See Load Shackle (08-145-006-001) in EXPLODED VIEW on p 5.
• DO NOT use this lifter to move an item if the item does not balance when it is suspended. The bottom
side of the lifter should be horizontal/level when the load is elevated.
• DO NOT lift more than 1 item at a time.
• DO NOT lift people. This lifter is a material handling device.
• Center the hoist above the load item before connecting it to a load. Centering minimizes load swing as
the load lifts off of the ground. DO NOT side load the hoist/lifter.
• DO NOT sit, or ride, on the load item or the lifter.
• DO NOT exceed the rated load/capacity of your lifter (20,000 lb.; 9,090kg). See SPECIFICATIONS on p. 3
as well as product label #1000 shown in the LABELING DIAGRAM on p. 6.
• Carefully eliminate slack in the hoist line and rigging before raising the load. Lift and lower loads slowly
and steadily. Avoid jolting the loads.
• Slowly raise th
e loaded lifter a few inches above the ground to determine whether the load is stable.
• DO NOT lift a load higher than necessary. See USING THE LIFTER on p. 7. Keep the suspended load as
close to the ground as possible while moving it and avoid obstructions.
• Avoid contact with the load item while it is suspended. DO NOT get in front of or behind a suspended
item. Avoid putting your feet and other parts of your body beneath the item. NEVER lift material over
yourself or other people.
• Watch the load carefully while lifting and moving it. The load could swing or spin while elevated.
SIGNAL WORDS
This manual uses SIGNAL WORDS to draw attention to uses of the product that could result in personal
injuries, as well as the probable seriousness of those injuries. Other signal words call attention to uses
likely to cause property damage. Signal words used in this manual appear below along with the definition
of each word.
Identifies a hazardous situation which, if not avoided, WILL result in DEATH or
SERIOUS INJURY. Use of this signal word is limited to the most extreme situations.
Identifies a hazardous situation which, if not avoided, COULD result in DEATH or
SERIOUS INJURY.
Identifies practices likely to result in product/property damage, such as operation that
might damage the product.
