Sida 1/88
08/2012 rev. 9/23/2014 SWA-60 manual.doc
SWA-Series Semi-Automatic Stretch Wrapping Machines
Instruction Manual
Receiving in
structions
:
After delivery, IMMEDIATELY remove the packaging from the product in a manner that preserves the packaging
and maintains the orientation of the product in the packaging; then inspect the product closely to determine
whether it sustained damage during transport. If damage is discovered during the inspection, immediately
record a complete description of the damage on the bill of lading. If the product is undamaged, discard the
packaging.
NOTES
:
1) Complia
nce with laws, regulations, codes, and non-voluntary standards enforced in the location wh
ere the
prod
uct is used is exclusively the responsibility of the owner/end-user.
2) VESTIL is
not liable for any injury or property damage that occurs as a consequence of failing to apply e
ither:
a) Inst
ructions in this manual; or b) Information provided on labels affixed to the product. Neither is
Vestil
respon
sible for any consequential damages sustained as a result of failing to exercise sound judgment while
assembling, installing, using or maintaining this product.
VESTIL MANUFACTURING CORP.
2999 North Wayne Street, P.O. Box 507, Angola, IN 46703
Telephone: (260) 665-7586 -or- Toll Free (800) 348-0868
Fax: (260) 665-1339
www.vestilmfg.com e-mail: sales@vestil.com
I N D E X
1 Introduction................................................................................................................................... 1
2 Machine Dimension ...................................................................................................................... 2
3 Safety Instruction .......................................................................................................................... 3
3-
3-
3-
3-
3-
4-
4-
4-
4-
4-
5-
5-
5-
5-
5-
9-
9-
11
11
1Warning labels............................................................................................................................ 3
2 Safety devices of turning table & interlocking function of safety guard .................................. 4
3 Safety guards ............................................................................................................................. 5
4 Moving elements ....................................................................................................................... 6
5 Safety related components......................................................................................................... 7
4 Installation of the machine............................................................................................................ 8
1 Setting the machine and choosing base..................................................................................... 8
2 Packing and Unpacking............................................................................................................. 8
3 Handling and Transportation.................................................................................................... 10
4 Installation of machine ............................................................................................................. 11
5 Assemble the Pre-stretch Unit.................................................................................................. 12
5 Control Panel................................................................................................................................ 13
1 Description of key pad’s function on the control panel............................................................ 14
2 Wrapping function control........................................................................................................ 16
3 Status indication ....................................................................................................................... 18
4 Breakdown indication............................................................................................................... 20
5 Motion indication ..................................................................................................................... 21
6 Film Loading................................................................................................................................ 23
7 Film Tension Adjust ..................................................................................................................... 24
8 Operation Procedure .................................................................................................................. 25
9 Maintenance................................................................................................................................. 26
1 Installing and removing turntable ............................................................................................ 26
2 Adjusting tightness of turntable chain ...................................................................................... 27
10 Electrical .................................................................................................................................... 28
10-1 Parts list of electrical components ...................................................................................... 28
10-2 EMC component list........................................................................................................... 33
10-3 Electrical wiring diagram ................................................................................................... 34
11 Troubleshooting.......................................................................................................................... 46
-1-1 Power indication hasn’t lighted on...................................................................................... 46
-1-2 There isn’t DC12 Volt. On power supply PD-25A ............................................................. 47
i
