Table of ContentsRev. 5/8/2019ZLTT MANUAL
Table of ContentsCopyright 2019Vestil Manufacturing Co.Page 1 of 15
ZLTT-Series Tilting Tables
Instruction Manual
Receiving instructions:
After delivery, remove the packaging from the product. Inspect the product closely to determine whether it
sustained damage during transport. If damage is discovered, record a complete description of it on the bill of lading. If
the product is undamaged, discard the packaging.
NOTE:
The end-user is solely responsible for confirming that product design, use, and maintenance comply with laws,
regulations, codes, and mandatory standards applied where the product is used.
Replacement Parts and Technical Service:
For answers to questions not addressed in these instructions and to order replacement parts, labels, and
accessories, call our Technical Service and Parts Department at (260) 665-7586. The department can also be
contacted online at http://www.vestilmfg.com/parts_info.htm.
Table of Contents
Specifications…………..…………….…………………..……………………………………………………..………………… 2
Signal Words….……………………..…………………………………………………………………………..………………... 2
Hazards……………………………………………………………..…………………..…………………………………………. 3
Hydraulic circuit diagram………………………………………..……………………………….....……………………………. 3
ZLTT-4452 Exploded View and Bill of Materials……………………………………………..……………….……………….. 4
ZLTT-5252 Exploded View and Bill of Materials………………………………………………………………………………. 5
ZLTT-4472 Exploded View and Bill of Materials………………………………………………………………………………. 6
ZLTT-5272 Exploded View and Bill of Materials………………………………………………………………………………. 7
115VAC, Single-Phase Electric Circuit Diagram……………….....………………….………………..……………………… 8
208-230VAC, Single-Phase Electric Circuit Diagram…………………………………………………………………………. 8
3-Phase Electric Circuit Diagram……………………………………………………………………………………………….. 9
Installation…………………………………………………………………………………………………………………………. 9
Loading the Table………………………………………………………………………………………..…………………..…… 10
Sequence of Operation…..………………..……………………………………………..…………...…………………………. 10
Operating the Table………………………………………………………………………………………………………………. 10-11
Hydraulic System Issues and Solutions……………………………………………………………………………................. 11-12
Record of Original Condition…………………………………………………………………………………………………….. 12
Inspections & Maintenance…………………………………………………………………………..………………………….. 12-13
Troubleshooting……………………………………………………………………………………..…………………………….. 13-14
Labeling Diagram……...…………………………………………………………………………..………………………..……. 14
Limited Warranty…...……………………………………………………………………………………………………………... 15
11
Vestil Manufacturing Corp.
2999 North Wayne Street, P.O. Box 507, Angola, IN 46703
Telephone: (260) 665-7586 -or-Toll Free (800) 348-0868
Fax: (260) 665-1339
Web: www.vestilmfg.come-mail: info@vestil.com
