InstallationInstructions
©
2017TheVollrathCompanyL.L.C.PartNo.350719-1ml3/30/17
SpringLoadedIn-CounterCupDispenser
ThankyouforpurchasingthisVollrathequipment.Beforeoperatingthe
equipment,readandfamiliarizeyourselfwiththefollowingoperating
andsafetyinstructions.SAVETHESEINSTRUCTIONSFORFUTURE
REFERENCE.Savetheoriginalboxandpackaging.Usethispackaging
toshiptheequipmentifrepairsareneeded.
SAFETYPRECAUTIONS
Toensuresafeoperation,readthefollowingstatementsandunderstand
theirmeaning.Thismanualcontainssafetyprecautionswhichare
explainedbelow.Pleasereadcarefully.
Warningisusedtoindicatethepresenceofahazardthatwillorcan
causeseverepersonalinjuryordeath.
Cautionisusedtoindicatethepresenceofahazardthatwillorcan
causeminorormajorpersonalinjuryifthecautionisignored.
NOTICE:Noticeisusedtonoteinformationthatisimportantbutnot
hazard-related.
TOOLSYOUWILLNEED
•#2PhillipsScrewdriver
•Drill
•¹⁄₈"DrillBit(For#29PilotHole)
•SabreSaworHandRouter
•3#8x1.00"PanHeadPhillipsScrews(included)
CHOOSETHECORRECTSPRING
Thedispenserincludestwospringsfordifferentapplications.Seethe
chartbelow.Thelighterweightdispenserisfactoryinstalled.See
“ChangeDefaultSpring(Optional)”onpage3.
INSTALLATION
MounttheDispenser
1.Cuttheappropriatediameteropeninginthemountingsurface.
2.Liftthebezeltoremoveitfromthetubetorevelthemountingholes
andthecomponentsthatcanbeadjustedtoaccommodatedifferent
cupdiameters.
WARNING
CAUTION
MountingDispensingUseThisSpring
Vertical
PaperorPlasticHeavierWeight
FoamLighterWeight
HorizontalPaper,PlasticorFoamLighterWeight
Angled
PaperorPlasticHeavierWeight
FoamLighterWeight
ItemNo.ForCupRimDiameterCutoutDiameter
CADJ-12¹⁄₂–3¹⁄₂"(6.4–8.9cm)4(10.2)
CADJ-23–3⁷⁄₈"(7.6–9.8cm)4¹⁄₂(11.4)
CADJ-33–4⁵⁄₈"(7.6–11.7cm)5¹⁄₄(13.3)
CADJ-44¹⁄₂–5¹⁄₄"(11.4–13.3cm)5³⁄₄(14.6)
